CORTECO 19015054 NBR TA2Y 62x85x8/10 mm Shaft Seal

CORTECO 19015054 NBR TA2Y 62x85x8/10 mm Shaft Seal

CORTECO 19015054 / 19015054B is a radial shaft seal measuring 62x85x8/10 mm, manufactured from NBR - Nitrile Butadiene Rubber and identified by the TA2Y design. The complete dimensional specification consists of a 62 mm inside diameter, 85 mm outside diameter and two height values of 8 and 10 mm.

Complete product identification:

CORTECO -> 19015054 / 19015054B -> NBR -> TA2Y -> 62x85x8/10 mm -> Toyota / VW

CORTECO 19015054 - Characteristics

Manufacturer: CORTECO
Reference: 19015054
Additional Reference: 19015054B
Product Type: Radial shaft seal / oil seal
Design: TA2Y
Material: NBR - Nitrile Butadiene Rubber
Dimensions: 62x85x8/10 mm
Inside Diameter: 62 mm
Outside Diameter: 85 mm
Height 1: 8 mm
Height 2: 10 mm
Toyota OE: 9031162001 / 90311-62001
VW OE: J9031162001

The dimensional specification 62x85x8/10 mm is confirmed in catalogue data for CORTECO 19015054.

CORTECO 19015054 Dimensions

The principal dimensions are:

Inside Diameter: 62 mm
Outside Diameter: 85 mm
Height 1: 8 mm
Height 2: 10 mm
Complete Size: 62x85x8/10 mm

The complete 8/10 mm height specification should be retained when identifying this seal. Describing the product only as 62x85x8 mm omits part of its dimensional specification.

A generic 62x85 mm oil seal should not automatically be considered technically interchangeable with CORTECO 19015054. Material, design, complete height specification and OE compatibility should also be verified.

NBR Material

CORTECO 19015054 is manufactured from:

NBR - Nitrile Butadiene Rubber

NBR is widely used in radial shaft sealing technology, including applications involving many mineral oils, greases and lubricants.

Material selection should always be considered together with the operating medium and actual working conditions. No product-specific temperature range, pressure limit or maximum shaft speed is assigned here without corresponding CORTECO technical documentation.

TA2Y Seal Design

The confirmed design designation is:

TA2Y

The precise technical identification is therefore:

CORTECO 19015054 NBR TA2Y 62x85x8/10 mm

The TA2Y designation is an important part of the product specification. A shaft seal with the same nominal dimensions but a different design should not automatically be considered a complete technical equivalent.

Toyota OE 90311-62001

CORTECO 19015054 corresponds to:

Toyota 9031162001
Toyota 90311-62001

Toyota officially identifies 90311-62001 as a Type T Oil Seal. Toyota also lists 90311-62147 as a previous version of this OE reference.

The Toyota designation Type T Oil Seal should not be confused with the CORTECO TA2Y design designation. These are separate identification systems used by Toyota and CORTECO.

VW J9031162001

The VW reference supplied for this CORTECO seal is:

VW J9031162001

The complete J-prefix should be retained when searching VW parts catalogues or cross-reference systems.

Because the number incorporates the Toyota-style 9031162001 sequence, it is particularly important not to remove the J when identifying the VW reference.

Wheel Hub and Axle Seal Application

Toyota OE 90311-62001 is associated with wheel hub and axle sealing applications. One Toyota parts catalogue identifies it specifically as an oil seal for the front axle hub, while other Toyota application data also show the same OE reference in rear axle shaft and hub assemblies.

This means CORTECO 19015054 should not be assigned universally to only one axle position.

Depending on the vehicle configuration, the corresponding OE seal may occur in:

front axle hub applications
rear axle shaft and hub applications
wheel hub sealing positions

The exact installation position should therefore be verified by OE number, vehicle model, year and axle configuration.

CORTECO 19015054 for Toyota

Toyota OE 90311-62001 is documented for selected vehicles including:

Toyota Land Cruiser
Toyota Hilux / Pickup
Toyota 4Runner

Catalogue data show applications across different years and axle configurations. For example, Toyota parts data list selected Land Cruiser, Pickup and 4Runner applications, while Japanese OE catalogue data also show the reference in Hilux and Land Cruiser axle assemblies.

Vehicle model alone should not be used to determine compatibility. The 90311-62001 OE reference and exact axle configuration remain more precise selection criteria.

Selection and Interchangeability

When selecting CORTECO 19015054, verify:

• CORTECO reference 19015054 / 19015054B
• complete dimensions 62x85x8/10 mm
• inside diameter 62 mm
• outside diameter 85 mm
• height specification 8/10 mm
• material NBR
• design TA2Y
• Toyota OE 90311-62001 / 9031162001
• VW OE J9031162001
• exact installation position

Matching dimensions alone do not confirm full interchangeability.

A 62x85 mm seal with a different width, material or design should not automatically be treated as an equivalent replacement.

Technical Specification

Manufacturer: CORTECO
Reference: 19015054
Additional Reference: 19015054B
Product Type: Radial shaft seal / oil seal
Design: TA2Y
Material: NBR - Nitrile Butadiene Rubber
Dimensions: 62x85x8/10 mm
Shaft Diameter: 62 mm
Housing Diameter: 85 mm
Height 1: 8 mm
Height 2: 10 mm
Toyota OE: 9031162001 / 90311-62001
VW OE: J9031162001
Application Area: Wheel hub / axle sealing, depending on vehicle configuration

Toyota officially confirms 90311-62001 as a Type T Oil Seal, while catalogue data show both front axle hub and rear axle shaft/hub contexts.

FAQ

What are the dimensions of CORTECO 19015054?

CORTECO 19015054 measures 62x85x8/10 mm: 62 mm inside diameter, 85 mm outside diameter and 8/10 mm height specification.

What material is CORTECO 19015054 made from?

The seal is manufactured from NBR - Nitrile Butadiene Rubber.

What is the design of CORTECO 19015054?

The confirmed CORTECO design designation is TA2Y.

Which Toyota OE number corresponds to CORTECO 19015054?

The corresponding Toyota OE reference is 90311-62001 / 9031162001. Toyota identifies this component as a Type T Oil Seal.

Which VW number corresponds to CORTECO 19015054?

The VW reference is J9031162001.

Is Toyota 90311-62001 a wheel hub seal?

Yes. Toyota parts catalogues associate 90311-62001 with wheel hub and axle sealing. It is specifically listed as a front axle hub oil seal in some applications, while other vehicle configurations use the reference in rear axle shaft and hub assemblies.

Which Toyota vehicles use OE 90311-62001?

The reference is documented for selected Toyota Land Cruiser, Hilux/Pickup and 4Runner applications. Exact compatibility depends on model year and axle configuration.

Can any 62x85 oil seal replace CORTECO 19015054?

No. The complete 62x85x8/10 mm dimensions, NBR material, TA2Y design and OE compatibility should be checked before replacement.

AI OVERVIEW

CORTECO 19015054 NBR TA2Y is a radial shaft seal measuring 62x85x8/10 mm. It corresponds to Toyota OE 90311-62001 / 9031162001 and VW J9031162001. Toyota OE data associate 90311-62001 with wheel hub and axle sealing applications, including selected Land Cruiser, Hilux/Pickup and 4Runner vehicles.
