CORTECO 19016518 NBR TB 54x65x13 mm - Wheel Hub Oil Seal

CORTECO 19016518 NBR TB 54x65x13 mm - Wheel Hub Oil Seal

CORTECO 19016518 NBR TB 54x65x13 mm is a radial shaft seal catalogued as a wheel hub oil seal, used in selected Nissan vehicles and other compatible applications. Manufactured by CORTECO, it features an inside diameter of 54 mm, an outside diameter of 65 mm and a width of 13 mm. The sealing material is NBR (Nitrile Butadiene Rubber), and the construction profile is designated TB. The product is also listed under reference 19016518B.

Product Characteristics

CORTECO 19016518 is a radial shaft seal designed to help retain lubricant and limit the entry of contaminants into appropriately designed wheel hub and shaft assemblies.

Key features:

• Manufacturer: CORTECO.

• Product reference: 19016518.

• Additional catalogue reference: 19016518B.

• Technical designation: TB Simmerring.

• Nominal dimensions: 54x65x13 mm.

• Sealing material: NBR.

• Construction profile: TB.

• Catalogued application: wheel hub oil seal.

• Catalogue installation position: front axle.

• Listed for selected Nissan vehicle applications.

Technical Specifications

The exact sealing lip geometry, presence of a garter spring, outer-case construction and operating limits require confirmation from the product-specific manufacturer's technical drawing.

What Does CORTECO 19016518 NBR TB 54x65x13 Mean?

The complete designation identifies the manufacturer, product reference, material, construction profile and nominal dimensions.

CORTECO - the manufacturer's brand.

19016518 - the product identification number.

NBR - Nitrile Butadiene Rubber, a synthetic elastomer widely used in seals operating with many oils and greases.

TB - the construction profile designation of the rotary shaft seal.

54x65x13 mm - nominal dimensions:

• 54 mm - inside diameter.

• 65 mm - outside diameter.

• 13 mm - width.

Wheel Hub Oil Seal Application

CORTECO 19016518B is catalogued as a front axle wheel hub oil seal.

In this application, the seal forms part of the protection system for a lubricated wheel hub assembly.

Its purpose is to help prevent lubricant loss and reduce contamination entering the sealed area.

Sealing performance depends on several factors:

• Condition of the mating surface.

• Correct installation.

• Proper interference fit.

• Wheel bearing condition.

• Lubricant compatibility.

• Vehicle operating conditions.

• Correct selection for the hub assembly.

A damaged or incorrectly fitted wheel hub seal may contribute to lubricant leakage and contamination of the bearing assembly.

CORTECO 19016518 - Nissan and Other Catalogue Applications

CORTECO 19016518B is associated in replacement-parts catalogues with selected vehicles, including:

These references indicate catalogue associations, not universal compatibility with every version of the listed vehicles.

Correct fitment must be confirmed using the vehicle variant, model year, drivetrain configuration and original equipment part number.

TB Seal Profile - Why Construction Matters

TB is the construction profile designation used for this CORTECO oil seal.

It should not automatically be considered identical to BA, BASL, B1SL or TC profiles.

Different sealing profiles may vary in:

• Sealing lip geometry.

• Outer-case construction.

• Spring arrangements.

• Dust protection features.

• Installation requirements.

• Housing fit.

When selecting a replacement, compare the complete technical designation rather than relying only on the dimensions 54x65x13 mm.

NBR Sealing Material

NBR, or Nitrile Butadiene Rubber, is widely used in automotive and industrial sealing applications.

Typical material characteristics include:

• Good resistance to many mineral oils.

• Compatibility with many mineral-based greases.

• Good mechanical properties.

• Suitability for appropriately designed dynamic sealing applications.

Actual performance depends on the specific NBR compound, temperature and sealing medium.

The exact hardness, permissible pressure, maximum shaft speed and operating temperature range should not be assumed without manufacturer specifications.

How to Select the Correct CORTECO 19016518 Oil Seal

Before ordering, verify:

1. CORTECO reference 19016518 or 19016518B.

2. Inside diameter - 54 mm.

3. Outside diameter - 65 mm.

4. Width - 13 mm.

5. TB construction profile.

6. NBR sealing material.

7. Original equipment part number.

8. Installation position.

9. Wheel hub and bearing assembly design.

10. Compatibility with the vehicle manufacturer's catalogue.

For automotive applications, matching dimensions alone is not sufficient to confirm correct fitment.

Wheel Hub Oil Seal Installation Guidelines

Before installing the CORTECO 54x65x13 mm oil seal, inspect the shaft, mating surface and housing bore.

Check for:

• Wear grooves.

• Corrosion.

• Scratches.

• Sharp edges.

• Contamination.

• Bearing play.

• Incorrect component alignment.

• Damage to the installation bore.

Use an appropriate installation tool to press the seal evenly into position.

Avoid deforming the seal or damaging its sealing surfaces.

Installation orientation and lubrication requirements must follow the vehicle manufacturer's service instructions.

Correct wheel bearing adjustment and the condition of mating components are also important for reliable sealing.

Frequently Asked Questions

What are the dimensions of CORTECO 19016518?

The oil seal measures 54x65x13 mm, with a 54 mm inside diameter, 65 mm outside diameter and 13 mm width.

Is CORTECO 19016518 a wheel hub oil seal?

Yes. Reference 19016518B is listed in replacement-parts catalogues as a wheel hub oil seal.

Which axle is it designed for?

Replacement-parts catalogues indicate a front axle installation position. Exact fitment depends on the vehicle.

Does CORTECO 19016518 fit Nissan Urvan?

The reference is associated with selected Nissan Urvan E23 versions. Compatibility must be verified for the specific vehicle.

Is it compatible with Nissan Pick Up 720?

Nissan Pick Up 720 appears in catalogue application listings. The original equipment part number should be checked before purchase.

What does the TB designation mean?

TB identifies the seal construction profile. Detailed lip and case geometry should be confirmed using manufacturer technical documentation.

What material is used?

The sealing material is NBR, or Nitrile Butadiene Rubber.

Are CORTECO 19016518 and 19016518B the same product?

Both references are associated in catalogues with the CORTECO NBR TB 54x65x13 mm oil seal.

Can any 54x65x13 mm oil seal replace this product?

No. Construction profile, material, sealing geometry and vehicle manufacturer requirements must also be considered.

What is the EAN number?

The catalogue EAN for CORTECO 19016518B is 3358960148551.

Is this seal suitable for mineral oil?

NBR is commonly used with many mineral oils. Compatibility with the specific lubricant and operating conditions must be verified.

Does the seal include a dust lip?

The TB designation alone is not sufficient to establish the exact dust lip arrangement for this specific product without its technical drawing.

CORTECO 19016518 - Key Technical Information

CORTECO 19016518 is an NBR TB wheel hub oil seal measuring 54x65x13 mm. It is also listed under reference 19016518B and commercial number 82816518. Replacement-parts catalogues associate it with selected Nissan vehicles, including Pick Up 720 and Urvan E23. Correct fitment requires verification of the vehicle version, original part reference and seal construction.
