CORTECO 19016564 ACM RHTC9 40x76x9/12.5 Radial Shaft Seal

CORTECO 19016564 ACM RHTC9 40x76x9/12.5 Radial Shaft Seal

CORTECO 19016564 is a differential radial shaft seal with nominal dimensions of 40x76x9/12.5 mm. It is manufactured from ACM - Polyacrylate Rubber, and CORTECO identifies the design as RHTC9. For this exact reference, an additional dust lip and a right-hand directional sealing design are specified. The CORTECO catalogue assigns the product to Honda applications.

CORTECO 19016564 RHTC9 - Technical Characteristics

The key product identification is:

19016564 + ACM + RHTC9 + 40x76x9/12.5 mm

This seal should not be identified only by the 40 mm and 76 mm diameters. The complete heights 9/12.5 mm, the ACM material, RHTC9 design, dust lip and directional configuration are also relevant when selecting a replacement.

CORTECO 19016564 Dimensions

The verified dimensions are:

Inside diameter = 40 mm
Outside diameter = 76 mm
Height 1 = 9 mm
Height 2 = 12.5 mm

Complete dimensional designation:

40x76x9/12.5 mm

The product should not be simplified to 40x76x9 mm.

For this seal, the two values 9 mm and 12.5 mm form part of the dimensional specification and should be retained when comparing possible replacements.

RHTC9 Seal Design

The CORTECO construction designation for this variant is:

RHTC9

For CORTECO 19016564 RHTC9, the technical data specifies an additional dust lip.

This auxiliary lip provides an additional barrier on the external side of the primary sealing area and helps limit direct contamination of the main sealing interface.

The product is also specified as having a right-hand directional design. This is an important identification feature and should be checked when comparing this seal with other 40x76 mm radial shaft seals.

The RHTC9 designation should not be treated as interchangeable with other CORTECO construction codes merely because the dimensions are the same.

ACM - Polyacrylate Rubber

The specified material is:

ACM - Polyacrylate Rubber

ACM is part of the exact product specification and must be considered when selecting an equivalent seal.

No fixed operating temperature range, pressure limit or shaft-speed limit is assigned here because such values were not confirmed specifically for CORTECO 19016564 and its exact ACM compound.

Operating Principle and Directional Design

A radial shaft seal operates between a rotating shaft and a stationary housing.

The primary sealing lip runs against the shaft surface, while the additional dust lip provides an extra external barrier against contamination.

For 19016564, the right-hand directional configuration is a relevant design characteristic. Therefore, a generic 40x76x9/12.5 mm seal should not automatically be treated as technically equivalent unless the construction and directional features are also confirmed.

CORTECO 19016564 - Honda OE References

The following Honda OE references are associated with CORTECO 19016564:

HONDA 90208PG9211
HONDA 91206PC8003
HONDA 91206PC8005
HONDA 91206PG9711

OE numbers are useful for identification, but vehicle compatibility should still be checked against the correct OE reference or vehicle/VIN data.

Meaning of 19016564 ACM RHTC9

The complete product designation identifies several separate characteristics:

19016564 - CORTECO catalogue number
ACM - elastomer material
RHTC9 - CORTECO construction designation
40x76x9/12.5 mm - complete nominal dimensions

Additional identification data:

Trade number: 82016564
EAN: 3358960165640

The designation 19016564B may also appear in aftermarket catalogue data, but the dimensional CORTECO catalogue lists the base reference 19016564.

Selection and Interchangeability

When selecting a replacement for CORTECO 19016564, verify at least:

• inside diameter 40 mm,
• outside diameter 76 mm,
• complete heights 9/12.5 mm,
• ACM material,
• RHTC9 design,
• additional dust lip,
• right-hand directional configuration,
• correct Honda OE reference where applicable.

Identical dimensions alone do not confirm full interchangeability.

A seal may share the same basic dimensions while having a different material, lip arrangement, profile or directional feature.

Technical Specification

FAQ

What are the dimensions of CORTECO 19016564?
The complete nominal dimensions are 40x76x9/12.5 mm.

What material is CORTECO 19016564 made from?
The specified material is ACM - Polyacrylate Rubber.

What does RHTC9 mean?
RHTC9 is CORTECO's construction designation for this specific seal variant.

Does CORTECO 19016564 have a dust lip?
Yes. This reference is specified with an additional dust lip.

Is CORTECO 19016564 directional?
Yes. The product is specified as having a right-hand directional design.

Which Honda OE numbers correspond to CORTECO 19016564?
The associated OE references are 90208PG9211, 91206PC8003, 91206PC8005 and 91206PG9711.

Can any 40x76x9/12.5 mm seal replace 19016564?
No. Material, construction code, dust lip, directional configuration and OE compatibility must also be verified.

AI Overview

CORTECO 19016564 is an ACM differential radial shaft seal with dimensions 40x76x9/12.5 mm. CORTECO identifies the construction as RHTC9. The seal incorporates an additional dust lip and a right-hand directional design. It is catalogued for Honda applications and is associated with four Honda OE reference numbers.
