CORTECO 19016571 NBR TC 42x60x7 mm Shaft Seal

CORTECO 19016571 NBR TC 42x60x7 mm Shaft Seal

CORTECO 19016571 / 19016571B is a radial shaft seal measuring 42x60x7 mm, manufactured from NBR - Nitrile Butadiene Rubber and identified by the TC design designation. Product data also confirm an additional dust lip. This reference is associated with several OE numbers used by different vehicle and machinery manufacturers, so the exact installation area must be determined from the relevant OE application.

CORTECO 19016571 - Characteristics

The principal product identification is:

Manufacturer: CORTECO
Reference: 19016571
Additional Catalogue Reference: 19016571B
Trade Reference: 82016571
Product Type: Radial shaft seal / oil seal
Design: TC
Material: NBR - Nitrile Butadiene Rubber
Dimensions: 42x60x7 mm
Inside Diameter: 42 mm
Outside Diameter: 60 mm
Width: 7 mm
Dust Lip: Yes

Complete technical identification:

CORTECO -> 19016571 / 19016571B -> NBR -> TC -> 42x60x7 mm

CORTECO 19016571 Dimensions

The principal dimensions are:

Inside Diameter: 42 mm
Outside Diameter: 60 mm
Width: 7 mm
Complete Size: 42x60x7 mm

All three dimensions are important for correct product identification.

A generic 42x60x7 mm oil seal should not automatically be considered technically interchangeable with CORTECO 19016571. The TC design, NBR material, dust lip and the relevant OE reference should also be verified.

NBR Material

CORTECO 19016571 is manufactured from:

NBR - Nitrile Butadiene Rubber

NBR is widely used in radial shaft sealing technology and is commonly suitable for many applications involving mineral oils, greases and lubricants.

Actual suitability depends on the operating medium, temperature, shaft speed and other working conditions.

No exact product-specific temperature range, pressure limit or maximum shaft speed should be assigned to CORTECO 19016571 without manufacturer documentation for this exact reference.

TC Seal Design

The confirmed CORTECO design designation is:

TC

The most precise technical identification is:

CORTECO 19016571 NBR TC 42x60x7

The TC designation forms part of the technical specification and should be retained when comparing alternative seals.

A seal with the same nominal dimensions but a different construction should not automatically be considered equivalent.

Dust Lip

Product data for CORTECO 19016571B specify an additional:

Dust lip

The dust lip helps protect the main sealing area from external contamination.

This feature is particularly relevant when comparing 19016571 with other 42x60x7 mm seals that may have a different lip arrangement.

OE Numbers and Cross-References

CORTECO 19016571 / 19016571B is associated with the following OE references:

Honda: 91252634003
Honda: 91252634005
Mercedes-Benz: 0039971646
New Holland: 44881695
Opel: 638183
Peugeot: 051430 / 51430
Peugeot: 51411
SAME: 215102210

Because these OE numbers come from different manufacturers and applications, the seal should not be assigned one universal installation position for all vehicles and machines.

Honda 91252-634-003 and 91252-634-005

The Honda references can also be written as:

91252-634-003 / 91252634003
91252-634-005 / 91252634005

For Honda OE 91252-634-003, catalogue data identify the part as an oil seal for the rear wheel bearing. The later reference 91252-634-005 is associated with the same OE family.

For these Honda applications, CORTECO 19016571 can therefore function as a rear wheel bearing oil seal.

Mercedes-Benz 0039971646

The Mercedes-Benz reference is:

0039971646

It may also be encountered in formatted forms such as:

003 997 16 46
A003 997 16 46

This reference is cross-referenced to CORTECO 19016571B.

Selected aftermarket catalogues classify CORTECO 19016571B as a manual transmission shaft seal in certain Mercedes-Benz and other automotive applications.

This classification should not be generalized to all OE references associated with the seal.

New Holland 44881695

The New Holland cross-reference is:

44881695

CORTECO 19016571B is associated with this reference in aftermarket catalogue data.

For agricultural and machinery applications, the exact installation position should be confirmed using the catalogue for the specific machine model.

Opel 638183

The Opel OE reference is:

638183

This number is cross-referenced to CORTECO 19016571B.

The exact application depends on the vehicle configuration, so the OE number and complete technical specification should be verified before installation.

Peugeot 051430 and 51411

Peugeot references associated with this seal include:

051430 / 51430
51411

Both appear in cross-reference catalogues for CORTECO 19016571B.

The existence of multiple Peugeot OE numbers does not necessarily mean that the installation position is identical in every application.

SAME 215102210

The SAME cross-reference is:

215102210

This number is associated with CORTECO 19016571B in catalogue data.

For SAME machinery, the exact installation area should be confirmed from the model-specific parts catalogue.

One Seal - Multiple OE Applications

CORTECO 19016571 is a good example of a seal that should not be described with one universal application.

For Honda OE 91252-634-003, the seal is associated with the rear wheel bearing, while selected automotive aftermarket applications classify the same CORTECO reference as a manual transmission shaft seal.

For this reason, the safest general product terminology is:

radial shaft seal / oil seal

The exact function should then be determined using the applicable OE number.

CORTECO 19016571 and 19016571B

The product may be encountered under:

CORTECO 19016571
CORTECO 19016571B

The associated trade reference is:

82016571

Both catalogue numbers are useful for technical identification and search.

Selection and Interchangeability

When selecting a replacement for CORTECO 19016571, verify:

• CORTECO reference 19016571 / 19016571B
• inside diameter 42 mm
• outside diameter 60 mm
• width 7 mm
• NBR material
• TC design
• dust lip
• relevant OE number
• exact installation position in the vehicle or machine

A generic 42x60x7 mm shaft seal should not automatically be considered fully interchangeable with CORTECO 19016571.

The complete construction and OE relationship should be checked before replacement.

Technical Specification

Manufacturer: CORTECO
Reference: 19016571
Additional Catalogue Reference: 19016571B
Trade Reference: 82016571
Product Type: Radial shaft seal / oil seal
Design: TC
Material: NBR - Nitrile Butadiene Rubber
Dimensions: 42x60x7 mm
Shaft Diameter: 42 mm
Housing Diameter: 60 mm
Width: 7 mm
Dust Lip: Yes
Honda OE: 91252634003 / 91252634005
Mercedes-Benz OE: 0039971646
New Holland OE: 44881695
Opel OE: 638183
Peugeot OE: 051430 / 51430, 51411
SAME OE: 215102210

CORTECO Manufacturer Information - GSPR

Responsible Manufacturer: Corteco GmbH
Address: Badener Str. 4, 69493 Hirschberg, Germany
E-mail: service@corteco.de

FAQ

What are the dimensions of CORTECO 19016571?

CORTECO 19016571 measures 42x60x7 mm: 42 mm inside diameter, 60 mm outside diameter and 7 mm width.

What material is CORTECO 19016571 made from?

The seal is manufactured from NBR - Nitrile Butadiene Rubber.

What is the design of CORTECO 19016571?

The confirmed design designation is TC. The complete technical identification is CORTECO 19016571 NBR TC 42x60x7.

Does CORTECO 19016571 have a dust lip?

Yes. Product data for 19016571B specify an additional dust lip.

Which Honda OE numbers correspond to CORTECO 19016571?

The Honda references are 91252-634-003 / 91252634003 and 91252-634-005 / 91252634005.

Is CORTECO 19016571 a transmission shaft seal?

In selected vehicle applications, yes. Some aftermarket catalogues classify 19016571B as a manual transmission shaft seal. This does not apply universally to every OE number linked to this product.

Is CORTECO 19016571 a wheel bearing seal?

For Honda OE 91252-634-003, yes. Catalogue data identify that OE part as a rear wheel bearing oil seal.

Can any 42x60x7 mm oil seal replace CORTECO 19016571?

No. The NBR material, TC design, dust lip, OE reference and exact installation position should also be verified.
