CORTECO 19016638 ACM RHTC 35x49x6 mm - Toyota Rotary Shaft Seal

CORTECO 19016638 ACM RHTC 35x49x6 mm - Toyota Rotary Shaft Seal

CORTECO 19016638 ACM RHTC 35x49x6 mm is a radial rotary shaft seal used in selected automotive applications, particularly Toyota engine applications. It is manufactured from ACM (polyacrylate rubber) and has a 35 mm inside diameter, 49 mm outside diameter and 6 mm width. CORTECO specifies the RHTC profile, right-hand twist and an additional dust lip. The product is also encountered as CORTECO 19016638B.

CORTECO 19016638 - Technical Data

What Does CORTECO 19016638 ACM RHTC Mean?

The complete designation identifies a specific CORTECO rotary shaft seal.

CORTECO - manufacturer and brand specialising, among other product groups, in automotive and industrial sealing technology.

19016638 - CORTECO reference number for this specific product.

19016638B - reference also encountered in current parts catalogues and distribution channels.

82016638 - trade number associated with this product.

ACM - polyacrylate rubber used as the elastomer material.

RHTC - CORTECO profile designation assigned to this specific seal construction.

35x49x6 mm - nominal dimensions: 35 mm inside diameter, 49 mm outside diameter and 6 mm width.

The complete combination of dimensions, material, profile and construction should be considered when identifying the product. Another 35x49x6 mm oil seal should not automatically be considered interchangeable with CORTECO 19016638.

CORTECO 19016638 Dimensions

The nominal dimensions are:

35x49x6 mm

where:

35 mm - inside diameter

49 mm - outside diameter

6 mm - seal width

The inside diameter corresponds to the nominal dimension of the mating rotating component, while the outside diameter corresponds to the nominal housing bore.

Dimensions alone are not sufficient to establish interchangeability.

The ACM material, RHTC profile, directional sealing geometry, dust lip and OE application should also be checked.

ACM - Polyacrylate Rubber

CORTECO specifies ACM, or polyacrylate rubber, for reference 19016638.

ACM is an elastomer used in technical rotary shaft sealing systems, particularly in automotive applications operating with compatible oils and lubricants.

However, the general properties of ACM should not be treated as the exact operating specification of this individual CORTECO seal.

Actual suitability depends on the specific elastomer compound, operating medium, temperature, shaft surface speed and design of the complete sealing system.

For this reason, no unverified exact temperature, pressure or rotational speed limits are assigned to CORTECO 19016638.

CORTECO RHTC Profile

CORTECO identifies this seal with the RHTC profile.

The profile is an integral part of the technical specification and should be considered when identifying the product or selecting an alternative.

For CORTECO 19016638B, catalogue data also confirms a right-hand twist.

Two seals with identical 35x49x6 mm dimensions can therefore have different functional constructions.

The individual letters in RHTC should not be decoded according to another manufacturer's nomenclature. Seal profile designations can be manufacturer-specific.

Right-Hand Twist

CORTECO 19016638B is specified with a right-hand twist.

Directional sealing features are associated with defined rotational conditions of the mating shaft.

This characteristic is important when selecting a replacement seal.

A 35x49x6 mm seal with a different twist direction or without directional sealing geometry may have identical basic dimensions but may not be technically equivalent to CORTECO 19016638.

Additional Dust Lip

CORTECO 19016638B is specified with an additional dust lip.

The auxiliary lip forms an additional barrier between the primary sealing area and the external environment.

It helps reduce the ingress of dust, dirt and other contaminants toward the primary sealing lip.

This is another important construction feature to consider when comparing CORTECO 19016638 with other 35x49x6 mm shaft seals.

Construction and Operating Principle

CORTECO 19016638 is a radial rotary shaft seal designed to operate between a rotating component and a stationary housing.

The primary sealing lip works against the shaft surface and helps retain lubricant within the protected assembly.

The additional dust lip provides secondary protection against contamination from the external side.

For CORTECO 19016638, the directional characteristics of the RHTC profile are also important.

Correct operation therefore depends not only on the 35x49x6 mm dimensions but also on installation orientation, direction of rotation, condition of the mating surface and compatibility of the ACM material with the operating conditions.

CORTECO 19016638 - Front-End Application

Catalogue data for CORTECO 19016638B specifies a front-end installation position.

Depending on the specific engine application, the product is catalogued as a camshaft seal or shaft seal.

The installation position should not be determined from dimensions alone.

For vehicle applications, the OE number, engine version and exact installation position should always be checked.

CORTECO 19016638 - Toyota Applications

CORTECO 19016638B is widely catalogued for selected Toyota applications.

Depending on the specific vehicle and engine, the product is used in shaft or camshaft sealing positions at the front end of the engine.

OE references associated with CORTECO 19016638B include:

TOYOTA 9031135003

TOYOTA 9031135008

TOYOTA 9031135013

TOYOTA 9031135017

TOYOTA 9031135022

Additional OE references may appear in extended application catalogues for specific Toyota engines and vehicles.

For accurate selection, the original OE number should be compared with the CORTECO reference.

Toyota OE 9031135003

One of the OE references associated with CORTECO 19016638B is:

TOYOTA 9031135003

This number provides an important identification point when searching for the corresponding replacement seal.

If the vehicle documentation or removed component specifies 9031135003, CORTECO 19016638B can be checked as the corresponding aftermarket reference.

Toyota OE 9031135008

Another associated OE reference is:

TOYOTA 9031135008

This number appears in parts catalogues as an OE reference corresponding to CORTECO 19016638B.

Compatibility should still be confirmed for the exact engine and installation position.

Toyota OE 9031135013

CORTECO 19016638B is also associated with:

TOYOTA 9031135013

When identifying an automotive shaft seal, the OE reference can provide a more precise selection criterion than dimensions alone.

Toyota OE 9031135017

Another associated reference is:

TOYOTA 9031135017

OE identification helps distinguish seals that may have similar dimensions but different construction or intended applications.

Toyota OE 9031135022

CORTECO 19016638B is also associated with:

TOYOTA 9031135022

When searching for the product, both the CORTECO reference and Toyota OE number can therefore be useful identification terms.

Vehicle Applications

CORTECO 19016638B appears in catalogues for numerous engine applications.

Selected Toyota vehicle families associated with this type of seal include:

Toyota Avensis

Toyota Carina

Toyota Celica

Toyota Corolla

Toyota Corona

Toyota Cressida

Toyota MR2

Toyota Paseo

Toyota Starlet

Toyota Supra

Toyota Tercel

Toyota Yaris

Selected applications from other vehicle manufacturers may also appear in parts catalogues.

A vehicle family name alone does not confirm compatibility. Different engines, production years and configurations can use different shaft seals.

Final selection should therefore be based on the OE reference and exact vehicle or engine specification.

CORTECO 19016638 vs Other 35x49x6 mm Shaft Seals

The nominal dimensions 35x49x6 mm are not sufficient to establish complete interchangeability.

CORTECO 19016638 has the specific combination:

35x49x6 mm

ACM

RHTC

right-hand twist

additional dust lip

front-end application

defined OE references

Other 35x49x6 mm shaft seals may use different elastomer materials, profiles or sealing geometries.

For this reason, dimensions should never be the only replacement criterion.

Alternative Designations and Search References

The product may be identified or searched using variants such as:

CORTECO 19016638

19016638 CORTECO

CORTECO 19016638B

19016638B CORTECO

CORTECO 82016638

82016638 CORTECO

CORTECO 19016638 ACM

CORTECO 19016638 RHTC

CORTECO 19016638 ACM RHTC

CORTECO 19016638 35x49x6

CORTECO 19016638B 35x49x6

CORTECO RHTC 35x49x6

CORTECO Simmerring 35x49x6

CORTECO oil seal 35x49x6

CORTECO rotary shaft seal 35x49x6

radial shaft seal 35x49x6

camshaft oil seal 35x49x6

camshaft seal 35x49x6

Toyota oil seal 35x49x6

Toyota camshaft seal 35x49x6

CORTECO 19016638 Toyota

CORTECO 19016638 9031135003

CORTECO 19016638 9031135008

CORTECO 19016638 9031135013

CORTECO 19016638 9031135017

CORTECO 19016638 9031135022

The safest identification method is to compare the complete CORTECO reference, OE number, dimensions, elastomer material, profile and installation position.

Cross-Reference Numbers

Cross-reference catalogues associate CORTECO 19016638B with references including:

AJUSA 15012800

ELRING 010.360

PAYEN NJ353

VICTOR REINZ 81-53247-00

Cross-reference numbers can assist with product identification, but they should not be treated as independent proof of complete technical interchangeability.

Before replacing the CORTECO seal with another manufacturer's product, compare the complete specification, construction and intended application.

Selection and Interchangeability

Before purchasing or replacing CORTECO 19016638 / 19016638B, verify:

• complete CORTECO reference,
• dimensions 35x49x6 mm,
• ACM elastomer material,
• RHTC profile,
• right-hand twist,
• additional dust lip,
• installation position,
• OE number of the original seal,
• engine and vehicle configuration,
• condition of the mating shaft surface,
• operating lubricant,
• requirements of the specific application.

Identical dimensions do not automatically mean complete interchangeability.

A 35x49x6 mm seal with a different profile, material or directional sealing geometry may be a technically different product.

Installation of CORTECO 19016638

Before installation, carefully clean the housing bore and mating shaft surface.

The sealing lip contact area should be free from corrosion, sharp edges, burrs and deep wear grooves that could damage the seal or cause leakage.

Install the seal squarely and evenly using an installation tool suitable for its diameter and construction.

Protect the primary sealing lip and additional dust lip against cutting, folding or deformation during assembly.

Because CORTECO 19016638B has a directional RHTC construction with right-hand twist, the correct installation orientation and rotational conditions should also be verified before assembly.

FAQ - CORTECO 19016638 ACM RHTC 35x49x6 mm

What are the dimensions of CORTECO 19016638?

The nominal dimensions are 35x49x6 mm: 35 mm inside diameter, 49 mm outside diameter and 6 mm width.

What material is CORTECO 19016638 made from?

CORTECO specifies ACM, or polyacrylate rubber.

What does RHTC mean in CORTECO 19016638?

RHTC is the CORTECO profile designation assigned to this specific seal. Catalogue data for 19016638B also confirms a right-hand twist.

Does CORTECO 19016638 have a dust lip?

Yes. Catalogue data for CORTECO 19016638B specifies an additional dust lip.

Where is CORTECO 19016638 installed?

Catalogue data specifies a front-end installation position. Depending on the specific engine application, the product may be catalogued as a camshaft seal or shaft seal.

Which Toyota OE numbers correspond to CORTECO 19016638?

Commonly associated Toyota OE references include 9031135003, 9031135008, 9031135013, 9031135017 and 9031135022.

Are CORTECO 19016638 and 19016638B the same type of seal?

Reference 19016638 is the base CORTECO product number, while current catalogues also use 19016638B. The associated specification includes ACM, RHTC and dimensions of 35x49x6 mm.

Can any 35x49x6 mm oil seal replace CORTECO 19016638?

No automatic interchangeability should be assumed. Material, profile, directional sealing geometry, dust lip, installation position and OE reference should also be compared.

CORTECO 19016638 ACM RHTC 35x49x6 mm - Key Information

CORTECO 19016638 is an ACM radial rotary shaft seal with dimensions of 35x49x6 mm and CORTECO RHTC profile. It features right-hand twist and an additional dust lip. The product is also encountered as CORTECO 19016638B, trade number 82016638, and is catalogued for selected Toyota engine applications, including front-end shaft and camshaft sealing positions.
