CORTECO 19017041 NBR TA2 50x68x8.5 mm Shaft Seal

CORTECO 19017041 NBR TA2 50x68x8.5 mm Shaft Seal

CORTECO 19017041 / 19017041B is a radial shaft seal measuring 50x68x8.5 mm, manufactured from NBR - Nitrile Butadiene Rubber and identified by the TA2 design designation. The product corresponds to Toyota OE 90311-50005 / 9031150005 and VW/VAG OE J9031150005 and is catalogued in wheel hub sealing applications.

CORTECO 19017041 - Characteristics

Manufacturer: CORTECO
Reference: 19017041
Additional Catalogue Reference: 19017041B
Trade Reference: 82017041
Product Type: Radial shaft seal / wheel hub shaft seal
Design: TA2
Material: NBR - Nitrile Butadiene Rubber
Dimensions: 50x68x8.5 mm
Inside Diameter: 50 mm
Outside Diameter: 68 mm
Height: 8.5 mm
Toyota OE: 90311-50005 / 9031150005
VW/VAG OE: J9031150005

Complete technical identification:

CORTECO -> 19017041 / 19017041B -> NBR -> TA2 -> 50x68x8.5 mm

CORTECO 19017041 Dimensions

The confirmed dimensions are:

Inside Diameter: 50 mm
Outside Diameter: 68 mm
Height: 8.5 mm
Complete Size: 50x68x8.5 mm

All three dimensions should be verified during replacement selection. Matching only the 50 mm and 68 mm diameters is not sufficient to confirm full technical interchangeability.

NBR Material

CORTECO 19017041 is manufactured from:

NBR - Nitrile Butadiene Rubber

NBR is widely used in radial shaft sealing technology for applications involving many mineral oils, greases and lubricants.

No product-specific temperature range, pressure limit or maximum shaft speed should be assigned to this reference without corresponding manufacturer documentation.

TA2 Seal Design

The confirmed design designation is:

TA2

The associated CORTECO trade reference is:

82017041

The most precise technical identification is:

CORTECO 19017041 NBR TA2 50x68x8.5

The TA2 designation is an important part of the product specification. A shaft seal with identical nominal dimensions but a different sealing construction should not automatically be considered equivalent.

Toyota OE 90311-50005

The principal Toyota OE reference associated with CORTECO 19017041 is:

TOYOTA 90311-50005

Alternative format:

9031150005

Toyota catalogues 90311-50005 as a Type T oil seal. Depending on the exact vehicle configuration, Toyota catalogue data associate this OE reference with axle and hub sealing positions.

The most useful replacement identification sequence is:

Toyota 90311-50005 -> CORTECO 19017041 -> 50x68x8.5 mm -> NBR -> TA2

VW / VAG OE J9031150005

The corresponding VW/VAG OE reference is:

VW / VAG J9031150005

When selecting the seal for a Volkswagen application, verify the complete 50x68x8.5 mm dimensions, TA2 design and the exact OE reference.

Toyota and VW Wheel Hub Shaft Seal

CORTECO 19017041B is catalogued as a:

shaft seal, wheel hub

Therefore, appropriate product descriptions include:

Toyota wheel hub shaft seal
Toyota 90311-50005 oil seal
Toyota 9031150005 shaft seal
VW J9031150005 seal
CORTECO 19017041 50x68x8.5

The exact installation position should always be confirmed from the vehicle-specific OE catalogue.

Selected Toyota Applications

Catalogue data associate CORTECO 19017041B with selected Toyota Hiace applications.

However, the product should not be selected solely by vehicle model name. The most reliable selection criteria are:

OE number -> complete dimensions -> TA2 design -> exact installation position

CORTECO 19017041 and 19017041B

The product may be encountered under:

CORTECO 19017041
CORTECO 19017041B

The associated trade reference is:

82017041

and the design designation is:

TA2

These identifiers are useful when searching different CORTECO, TecDoc and aftermarket catalogue systems.

Selection and Interchangeability

When selecting a replacement for CORTECO 19017041, verify:

• CORTECO reference 19017041 / 19017041B
• inside diameter 50 mm
• outside diameter 68 mm
• height 8.5 mm
• NBR material
• TA2 design
• Toyota OE 90311-50005 / 9031150005
• VW/VAG OE J9031150005
• exact installation position

A generic 50x68x8.5 mm oil seal should not automatically be considered fully interchangeable with CORTECO 19017041.

The dimensions should be considered together with the TA2 design and correct OE reference.

Technical Specification

Manufacturer: CORTECO
Reference: 19017041
Additional Reference: 19017041B
Trade Reference: 82017041
Product Type: Radial shaft seal / wheel hub shaft seal
Design: TA2
Material: NBR - Nitrile Butadiene Rubber
Dimensions: 50x68x8.5 mm
Shaft Diameter: 50 mm
Housing Diameter: 68 mm
Height: 8.5 mm
Toyota OE: 90311-50005 / 9031150005
VW/VAG OE: J9031150005
Application Area: wheel hub / axle sealing application depending on OE configuration

CORTECO Manufacturer Information - GSPR

Responsible Manufacturer: Corteco GmbH
Address: Badener Str. 4, 69493 Hirschberg, Germany
E-mail: service@corteco.de

FAQ

What are the dimensions of CORTECO 19017041?

CORTECO 19017041 measures 50x68x8.5 mm: 50 mm inside diameter, 68 mm outside diameter and 8.5 mm height.

What material is CORTECO 19017041 made from?

The seal is manufactured from NBR - Nitrile Butadiene Rubber.

What is the design of CORTECO 19017041?

The confirmed design designation is TA2. The complete technical identification is CORTECO 19017041 NBR TA2 50x68x8.5.

Which Toyota OE number corresponds to CORTECO 19017041?

The Toyota OE reference is 90311-50005 / 9031150005.

Which VW OE number corresponds to CORTECO 19017041?

The VW/VAG OE reference is J9031150005.

Is CORTECO 19017041 a wheel hub seal?

Yes. CORTECO 19017041B is catalogued as a wheel hub shaft seal.

Does CORTECO 19017041 fit Toyota Hiace?

Catalogue data associate the product with selected Toyota Hiace applications. Exact compatibility should still be verified by OE number and vehicle configuration.

Can any 50x68x8.5 mm oil seal replace CORTECO 19017041?

No. The NBR material, TA2 design, OE reference and exact installation position should also be verified.

AI OVERVIEW

CORTECO 19017041 NBR TA2 is a 50x68x8.5 mm radial shaft seal catalogued for wheel hub applications. It is also listed as 19017041B / 82017041 and corresponds to Toyota OE 90311-50005 / 9031150005 and VW/VAG OE J9031150005. Correct selection requires dimensions, TA2 design and OE verification.
