CORTECO 19027770B is an ACM transfer case shaft oil seal measuring 40x58x8 mm with the SC design. Inside diameter: 40 mm, outside diameter: 58 mm, width: 8 mm. Base reference: 19027770. Trade Number: 82027770. Suzuki OE: 0928240002. EAN: 3358960165800.
Warehouse and Store: Lublin, Smoluchowskiego 1 Street, Building 4. 24h Shipping. Available from stock in Poland for delivery across the EU.
CORTECO 19027770B is an ACM radial shaft oil seal measuring 40x58x8 mm with the SC design. The reference is catalogued as a transfer case shaft seal and is associated with Suzuki applications, including the Suzuki Grand Vitara I.
Manufacturer: CORTECO
Part number: 19027770B
Base reference: 19027770
Trade Number: 82027770
Product type: Radial shaft oil seal
Design: SC
Material: ACM - Polyacrylate Rubber
Dimensions: 40x58x8 mm
Inside diameter d: 40 mm
Outside diameter D: 58 mm
Width B: 8 mm
Catalogue application: Transfer case shaft seal
Suzuki OE: 0928240002
EAN: 3358960165800
The principal dimensions are:
Inside diameter d: 40 mm
Outside diameter D: 58 mm
Width B: 8 mm
Complete dimensions: 40x58x8 mm
CORTECO catalogue data directly associate reference 19027770 with the 40x58x8 mm dimensions, ACM material and SC construction.
All three dimensions should be checked together with the material, design and specific installation requirements when selecting a replacement.
Matching dimensions alone do not establish complete technical interchangeability.
The sealing material of CORTECO 19027770B is:
ACM - Polyacrylate Rubber
The elastomer type is an important technical parameter of a radial shaft seal and should be considered together with the dimensions, construction, operating medium and actual service conditions.
An NBR, FPM or other elastomer seal measuring 40x58x8 mm should not automatically be considered technically equivalent to this ACM version.
The CORTECO catalogue design designation is:
SC
Complete identification:
CORTECO 19027770B
Base reference: 19027770
Trade Number: 82027770
Dimensions: 40x58x8 mm
Material: ACM
Design: SC
The SC designation is an important part of the technical identification and should be retained when searching for this exact reference or comparing potential replacements.
Current catalogue data classify CORTECO 19027770B as a:
Transfer case shaft oil seal
The reference is associated with Suzuki applications.
Exact compatibility should be verified using the OE reference, vehicle data and specific installation position.
The Suzuki OE reference associated with CORTECO 19027770B is:
0928240002
Useful identification forms include:
Suzuki 0928240002
CORTECO 19027770B
CORTECO 19027770
CORTECO 82027770
40x58x8 ACM SC
The OE reference provides an important additional identification path when checking compatibility with a specific vehicle or transfer case.
Different forms of the reference can be encountered in catalogues and parts databases:
19027770 - base reference
19027770B - complete CORTECO reference
82027770 - Trade Number
SC - design designation
Suzuki 0928240002 - OE reference
The complete CORTECO reference 19027770B should be used as the primary product identifier.
Different radial shaft oil seals can share the nominal dimensions 40x58x8 mm.
This does not establish technical interchangeability with CORTECO 19027770B.
When comparing a possible replacement, verify:
Dimensions: 40x58x8 mm
Material: ACM
Design: SC
OE reference
Installation position
Transfer case requirements
Operating conditions
Matching dimensions alone are insufficient to confirm interchangeability.
Manufacturer: CORTECO
Part number: 19027770B
Base reference: 19027770
Trade Number: 82027770
Product type: Radial shaft oil seal
Design: SC
Material: ACM - Polyacrylate Rubber
Dimensions: 40x58x8 mm
Inside diameter d: 40 mm
Outside diameter D: 58 mm
Width B: 8 mm
Catalogue application: Transfer case shaft seal
Suzuki OE: 0928240002
EAN: 3358960165800
The seal measures 40x58x8 mm: 40 mm inside diameter, 58 mm outside diameter and 8 mm width.
The sealing material is ACM - Polyacrylate Rubber.
The CORTECO catalogue design designation is SC.
Current catalogue data classify the reference as a transfer case shaft oil seal associated with Suzuki applications.
The associated Suzuki OE reference is 0928240002.
The Trade Number is 82027770.
The EAN is 3358960165800.
Not automatically. The ACM material, SC construction, OE reference, installation position and specific application requirements should also be verified.
CORTECO 19027770B is an ACM transfer case shaft oil seal measuring 40x58x8 mm with the SC design. The reference is associated with Suzuki applications and corresponds to Suzuki OE 0928240002. Base reference: 19027770. Trade Number: 82027770. EAN: 3358960165800.
