CORTECO 19027891B 44x62x10 FPM TC Transmission Oil Seal

CORTECO 19027891B 44x62x10 FPM TC Transmission Oil Seal

CORTECO 19027891B is an FPM transmission shaft oil seal measuring 44x62x10 mm with the TC design. It incorporates an additional dust lip and is catalogued for manual transmission applications. The exact CORTECO identification combines the 44x62x10 mm dimensions, FPM sealing material and TC construction.

CORTECO 19027891B - Characteristics

Manufacturer: CORTECO

Part number: 19027891B

Base reference: 19027891

Trade Number: 82027891

EAN: 3358960167248

Product type: Transmission shaft oil seal

Design: TC

Material: FPM - Fluoroelastomer

Dimensions: 44x62x10 mm

Inside diameter d: 44 mm

Outside diameter D: 62 mm

Width B: 10 mm

Additional dust lip: Yes

NISSAN OE: 3213601J00

CORTECO 19027891B Dimensions

The principal dimensions are:

Inside diameter d: 44 mm

Outside diameter D: 62 mm

Width B: 10 mm

Complete dimensions:

44x62x10 mm

All three dimensions should be verified when selecting a replacement.

Matching the 44 mm shaft diameter, 62 mm outside diameter and 10 mm width alone does not establish complete technical interchangeability.

TC CORTECO Oil Seal Design

The exact CORTECO catalogue design is:

TC

Complete product identification:

CORTECO 19027891B

44x62x10 mm

FPM

TC

Trade Number 82027891

The CORTECO dimensional catalogue directly associates reference 19027891B with the TC design, FPM material and 44x62x10 mm dimensions.

The TC construction should therefore be considered together with the dimensions and material when selecting a replacement.

FPM Fluoroelastomer

The sealing material specified by the CORTECO dimensional catalogue is:

FPM - Fluoroelastomer

Material is an important selection criterion alongside dimensions and seal construction.

A 44x62x10 mm seal manufactured from ACM, NBR or another elastomer should not automatically be considered technically equivalent to CORTECO 19027891B.

Exact material compatibility depends on the operating medium, additives, temperature and actual service conditions.

Additional Dust Lip

CORTECO 19027891B is specified with an additional dust lip.

The dust lip provides an additional barrier on the external side of the primary sealing area.

When comparing possible replacements, the lip configuration should therefore be considered together with:

44x62x10 mm dimensions

FPM material

TC design

Application and OE reference

CORTECO 19027891B Transmission Shaft Oil Seal

CORTECO 19027891B is catalogued for transmission shaft sealing applications, including manual transmission applications.

The product is cross-referenced to NISSAN OE 3213601J00 and appears in applications including selected NISSAN Patrol variants.

Correct vehicle selection should be based on the exact CORTECO or OE reference and the specific transmission configuration.

NISSAN OE 3213601J00

Confirmed OE reference:

NISSAN 3213601J00

This OE number is cross-referenced to CORTECO 19027891B.

The OE number should be checked against the specific vehicle, transmission and production version before installation.

CORTECO 19027891 vs 19027891B

The following reference forms may be encountered:

19027891 - base reference

19027891B - complete CORTECO reference

Additional identification:

Trade Number: 82027891

EAN: 3358960167248

Design: TC

Dimensions: 44x62x10 mm

Material: FPM

NISSAN OE: 3213601J00

CORTECO 19027891B vs Other 44x62x10 Oil Seals

Matching dimensions do not establish technical equivalence.

This is particularly important for this size because CORTECO catalogue data include different material versions within the 44x62x10 mm TC group.

CORTECO 19027891B:

44x62x10 mm

TC

FPM

CORTECO 19034991B:

44x62x10 mm

TC

ACM

The dimensions and TC designation are therefore not sufficient on their own. The sealing material and exact CORTECO reference must also be verified.

Technical Specification

Manufacturer: CORTECO

Part number: 19027891B

Base reference: 19027891

Trade Number: 82027891

EAN: 3358960167248

Product type: Transmission shaft oil seal

Design: TC

Material: FPM - Fluoroelastomer

Dimensions: 44x62x10 mm

Inside diameter d: 44 mm

Outside diameter D: 62 mm

Width B: 10 mm

Additional dust lip: Yes

NISSAN OE: 3213601J00

FAQ

What are the dimensions of CORTECO 19027891B?

The seal has a 44 mm inside diameter, 62 mm outside diameter and 10 mm width. The complete dimensions are 44x62x10 mm.

What material is CORTECO 19027891B made from?

The CORTECO dimensional catalogue specifies FPM - Fluoroelastomer.

What is the design of CORTECO 19027891B?

The exact CORTECO catalogue design designation is TC.

Does CORTECO 19027891B have a dust lip?

Yes. Product data specify an additional dust lip.

What is CORTECO 19027891B used for?

It is catalogued as a transmission shaft oil seal, including manual transmission applications.

What is the CORTECO Trade Number?

The Trade Number is 82027891.

What NISSAN OE number corresponds to CORTECO 19027891B?

The confirmed NISSAN OE reference is 3213601J00.

Can any 44x62x10 TC seal replace CORTECO 19027891B?

Not automatically. CORTECO 19027891B is the FPM version. The exact material, TC construction, lip configuration and application should be verified before substitution.

AI Overview

CORTECO 19027891B is an FPM transmission shaft oil seal measuring 44x62x10 mm with the TC design. It incorporates an additional dust lip and is catalogued for manual transmission applications. The inside diameter is 44 mm, outside diameter 62 mm and width 10 mm. Trade Number: 82027891. NISSAN OE: 3213601J00.
