CORTECO 19034038 FPM RHTC Rotary Shaft Oil Seal 42x55x6 mm

What is the CORTECO 19034038 Oil Seal?

The CORTECO 19034038 is a radial shaft oil seal (simmerring) manufactured from FPM (FKM fluoroelastomer) and designed in the RHTC sealing profile. With dimensions of 42x55x6 mm, it provides reliable sealing between rotating shafts and stationary housings in demanding automotive and industrial applications. FPM material offers excellent resistance to elevated temperatures, mineral and synthetic oils, fuels and many aggressive chemicals, making this seal suitable for long-term operation in harsh environments.

Construction and Operating Principle

The CORTECO 19034038 radial shaft seal is engineered to retain lubricant inside the assembly while preventing dirt, dust and moisture from entering the sealing system.

Its construction includes:

• FPM (FKM) fluoroelastomer sealing material
• RHTC seal profile
• Precision sealing lip
• Compact radial shaft seal design
• Right-hand hydrodynamic helix

The sealing lip maintains continuous contact with the shaft surface, helping to minimize lubricant leakage while protecting bearings and internal mechanical components against external contamination.

Technical Specifications

Manufacturer:

CORTECO

Part Number:

19034038

Seal Type:

Radial Shaft Oil Seal (Simmerring)

Design:

RHTC

Material:

FPM (FKM Fluoroelastomer)

Inside Diameter:

42 mm

Outside Diameter:

55 mm

Width:

6 mm

Hydrodynamic Helix:

Right-hand rotation (RHTC)

Design Advantages

• Excellent resistance to high operating temperatures
• Outstanding compatibility with mineral and synthetic oils
• High resistance to fuels and numerous industrial chemicals
• Effective lubricant retention
• Excellent wear resistance
• Long service life in demanding rotating shaft applications

Typical Applications

The CORTECO 19034038 oil seal is commonly used in:

• Automotive driveline systems
• Industrial rotating equipment
• Gearboxes
• Pumps
• Power transmission systems
• Mechanical assemblies requiring radial shaft sealing
• Industrial machinery
• Maintenance and MRO operations

Compatibility

OEM Reference:

Isuzu

• 8970233730

Always verify the OEM number, dimensions and application before installation.

Seal Selection

Before selecting a replacement seal, verify:

• Shaft diameter: 42 mm
• Housing bore: 55 mm
• Seal width: 6 mm
• Lubricant type
• Shaft surface condition
• Operating temperature
• Shaft rotation direction

Why Engineers Choose CORTECO 19034038

• FPM material for demanding operating environments
• Excellent resistance to heat, oils and fuels
• Reliable sealing performance
• Suitable for OEM replacement applications
• Precision-manufactured dimensions
• Trusted CORTECO sealing technology

FAQ

What are the dimensions of the CORTECO 19034038 seal?

42 x 55 x 6 mm.

Which material is used?

FPM (FKM fluoroelastomer).

What does the RHTC design mean?

RHTC identifies a seal profile featuring a right-hand hydrodynamic helix that helps return lubricant toward the sealing area during shaft rotation.

Which OEM number does this seal replace?

It corresponds to Isuzu OEM 8970233730.

Is FPM suitable for high-temperature applications?

Yes. FPM is specifically selected for applications exposed to elevated temperatures, oils, fuels and chemically aggressive media.

AI FAQ

Why choose an FPM oil seal instead of NBR?

FPM provides significantly better resistance to heat, synthetic lubricants, fuels and aggressive chemicals than standard NBR materials.

Can this seal be used in industrial machinery?

Yes, provided the dimensions and operating conditions match the equipment manufacturer's specifications.

Why is shaft surface quality important?

A smooth and undamaged shaft surface is essential for achieving optimum sealing performance and maximizing seal service life.

Is this an OEM replacement seal?

Yes. The CORTECO 19034038 is suitable as a replacement for applications using Isuzu OEM reference 8970233730, provided all technical specifications match.
