CORTECO 19034606 FPM RWDR-K7 10HHR 85x140x17 mm Cassette Shaft Seal

CORTECO 19034606 FPM RWDR-K7 10HHR 85x140x17 mm Cassette Shaft Seal

CORTECO 19034606 / 19034606B is an FPM cassette shaft seal measuring 85x140x17 mm, with a construction identified by CORTECO as RWDR-K7 10HHR / CASSETTA 10HHR. The CORTECO commercial number is 82034606. The product is catalogued for IVECO applications, with confirmed OE reference IVECO 93160765.

Technical Data - CORTECO 19034606

CORTECO 19034606 - Precise Product Identification

The complete product designation is:

CORTECO 19034606 FPM RWDR-K7 10HHR 85x140x17 mm

Current reference:

CORTECO 19034606B

Commercial number:

82034606

Material:

FPM

Construction:

RWDR-K7 / CASSETTA

Construction designation:

10HHR

Dimensions:

85x140x17 mm

Confirmed OE reference:

IVECO 93160765

EAN:

3358960341860

When selecting this product, the 85x140x17 mm dimensions alone are not sufficient. The cassette construction and the RWDR-K7 10HHR designation are important parts of the product identification.

CORTECO 19034606 Dimensions

Catalogue dimensions:

• inner diameter: 85 mm
• outer diameter: 140 mm
• width: 17 mm

Complete dimensions:

85x140x17 mm

CORTECO catalogues include other sealing products with similar 85x140 mm nominal diameters but different widths, materials and constructions.

For this reason, searching only for:

85x140x17 oil seal

is not sufficient to confirm interchangeability.

FPM - Fluoroelastomer

CORTECO 19034606 is manufactured from:

FPM - fluoroelastomer / fluorocarbon rubber

FPM is widely used in demanding technical sealing systems.

Typical characteristics associated with fluoroelastomers include:

• very good resistance to many oils,
• good resistance to many fuels and lubricants,
• good ageing resistance,
• good resistance to many chemical media,
• suitability for demanding sealing environments.

Actual performance depends on the specific FPM compound, operating medium, temperature, speed and complete sealing system.

A universal operating temperature range should therefore not be assigned to CORTECO 19034606 solely from generic FPM material data.

RWDR-K7 10HHR - CORTECO Construction

In CORTECO dimensional catalogues, this product is identified as:

RWDR-K7 10HHR

Older CORTECO listings also describe the same reference as:

CASSETTA 10HHR

This is an important distinction when identifying the product.

CORTECO 19034606 should not be treated merely as a conventional radial oil seal measuring 85x140x17 mm.

The designations:

RWDR-K7

CASSETTA

and:

10HHR

are important parts of the seal's technical identification.

Individual elements of the K7 or 10HHR designation should not be decoded using another manufacturer's nomenclature without appropriate CORTECO technical documentation.

What Is a Cassette Shaft Seal?

For CORTECO 19034606, the catalogue classification:

CASSETTA / RWDR-K7

identifies a specialised sealing construction rather than a conventional oil seal selected only by three nominal dimensions.

This is particularly important when sourcing a replacement.

An alternative product should correspond not only to:

85x140x17 mm

but also to the required construction and operating conditions of the original assembly.

A conventional radial shaft seal with the same nominal dimensions is therefore not automatically interchangeable.

CORTECO 19034606 and IVECO 93160765

The confirmed OE reference is:

IVECO 93160765

The product is catalogued for IVECO drivetrain-related applications. In aftermarket catalogues, it is associated with shaft/differential sealing in drive axle assemblies.

Important search references include:

CORTECO 19034606

CORTECO 19034606B

CORTECO 82034606

IVECO 93160765

For installation in a specific IVECO vehicle, compatibility should be verified according to the vehicle model, axle version and relevant parts catalogue.

CORTECO 19034606 vs Standard 85x140x17 Oil Seal

A conventional radial shaft seal measuring:

85x140x17 mm

is not automatically interchangeable with CORTECO 19034606.

The following should be compared:

• 85 mm inner diameter,
• 140 mm outer diameter,
• 17 mm width,
• FPM material,
• RWDR-K7 / CASSETTA construction,
• 10HHR designation,
• OE reference,
• intended application.

Matching the three nominal dimensions alone does not confirm constructional compatibility.

CORTECO 19034606 vs Other 85x140 Seals

Different CORTECO seals can share the same or similar inner and outer diameters.

They may differ in:

• width,
• profile,
• construction,
• elastomer material,
• intended application.

For this reason, the reference:

19034606 / 19034606B

is an important technical identifier.

The safest replacement strategy is to match the complete CORTECO reference or confirmed OE reference rather than dimensions alone.

Can NBR Replace FPM?

Not automatically.

NBR and FPM belong to different elastomer families.

Changing the sealing material can affect:

• compatibility with the operating medium,
• thermal performance,
• service life,
• behaviour under specific operating conditions.

For a specialised cassette seal, a replacement should not be selected solely by dimensions and elastomer type.

The complete construction must also be compatible with the application.

Alternative References and Search Terms

This product may be searched as:

CORTECO 19034606

CORTECO 19034606B

CORTECO 82034606

19034606 CORTECO

19034606B CORTECO

CORTECO 19034606 FPM

CORTECO 19034606 RWDR-K7

CORTECO RWDR-K7 10HHR

CORTECO CASSETTA 10HHR

FPM RWDR-K7 85x140x17

FPM cassette seal 85x140x17

Simmerring 85x140x17

Oil seal 85x140x17

FPM oil seal 85x140x17

Shaft seal 85x140x17

Cassette seal 85x140x17

Cassette shaft seal 85x140x17

IVECO 93160765

IVECO 93160765 seal

93160765 oil seal

93160765 shaft seal

93160765 cassette seal

How to Select a Replacement for CORTECO 19034606

Verify:

• reference: 19034606 / 19034606B
• commercial number: 82034606
• inner diameter: 85 mm
• outer diameter: 140 mm
• width: 17 mm
• material: FPM
• construction: RWDR-K7 / CASSETTA
• designation: 10HHR
• complete seal geometry.

For IVECO applications, also verify:

OE 93160765

Selection by the complete CORTECO reference or confirmed OE number is more reliable than selection based solely on the 85x140x17 mm dimensions.

Installation Recommendations

Before installation, carefully clean and inspect all mating surfaces.

Check:

• shaft or mating surface condition,
• housing condition,
• absence of burrs,
• absence of sharp edges,
• absence of corrosion,
• absence of excessive wear,
• correct seal orientation.

Because this is a cassette-type sealing construction, the installation procedure should correspond to the specific IVECO assembly and the manufacturer's service instructions.

The seal should be installed evenly without deforming its construction.

Incorrect installation can damage the sealing system before the vehicle or machine is returned to operation.

FAQ

What are the dimensions of CORTECO 19034606?

The catalogue dimensions are 85x140x17 mm.

What material is CORTECO 19034606 made from?

The material is FPM - fluoroelastomer / fluorocarbon rubber.

What construction does CORTECO 19034606 use?

The product is catalogued as RWDR-K7 10HHR and in older CORTECO listings as CASSETTA 10HHR.

What is the current CORTECO reference?

The current reference is CORTECO 19034606B.

What is the CORTECO commercial number?

The commercial number is 82034606.

What is the IVECO OE reference?

The confirmed OE reference is IVECO 93160765.

What is the EAN?

The EAN is 3358960341860.

Is CORTECO 19034606 a cassette seal?

Yes. CORTECO catalogue information identifies this reference as CASSETTA 10HHR / RWDR-K7 10HHR.

Can a standard 85x140x17 oil seal replace it?

This should not be assumed. In addition to dimensions, the replacement must take account of the FPM material, RWDR-K7 / CASSETTA construction and complete product designation.

Is CORTECO 19034606 suitable for IVECO?

The confirmed OE reference is IVECO 93160765. Compatibility with a specific vehicle and axle version should be confirmed using the appropriate IVECO parts catalogue.

CORTECO 19034606 - Quick Answer

CORTECO 19034606 / 19034606B is an FPM RWDR-K7 10HHR cassette shaft seal measuring 85x140x17 mm. Older CORTECO catalogue terminology identifies the construction as CASSETTA 10HHR. The CORTECO commercial number is 82034606, EAN 3358960341860, and the confirmed OE reference is IVECO 93160765. Replacement selection should consider the cassette construction, not dimensions alone.
