CORTECO 19035135 ACM TC 15x24x5 Rotary Shaft Oil Seal
2 pcs.
€2.10
(net)
Price for: 1pcs.
Available from simmering.pl
The product is available from the simmering.pl Warehouse & Store, located in Lublin, Smoluchowskiego 1, Building 4. We offer fast 24-hour dispatch, professional technical support, shipping throughout Poland and delivery across the European Union.
Product Summary
The CORTECO 19035135 ACM TC 15x24x5 is a premium rotary shaft oil seal made from high-quality ACM (polyacrylate rubber). Its TC double lip design with a spring-loaded primary sealing lip and auxiliary dust lip provides reliable protection against oil leakage and contaminants. Ideal for engines, gearboxes, transmissions, pumps and industrial drive systems operating at elevated temperatures.
Double Lip ACM Rotary Shaft Seal for High-Temperature Oil Applications
The CORTECO 19035135 is a 15 × 24 × 5 mm rotary shaft oil seal manufactured from ACM (polyacrylate rubber) in the TC double lip design. It features a spring-loaded primary sealing lip and an auxiliary dust lip, providing reliable sealing performance while protecting the system against external contaminants. Thanks to the excellent heat resistance and oil compatibility of ACM material, this oil seal is particularly suitable for automotive transmissions, engines, industrial drives and other applications operating with lubricating oils at elevated temperatures.
Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | CORTECO |
| Part Number | 19035135 |
| Product Type | Rotary Shaft Oil Seal |
| Design | TC – Double Lip |
| Material | ACM (Polyacrylate Rubber) |
| Shaft Diameter (d) | 15 mm |
| Outside Diameter (D) | 24 mm |
| Width (B) | 5 mm |
| Primary Lip | Spring-loaded |
| Auxiliary Dust Lip | Yes |
Product Description
The CORTECO 19035135 ACM TC rotary shaft seal is designed to prevent lubricant leakage while protecting rotating shafts from dust, dirt and moisture. The primary sealing lip, energized by a garter spring, maintains constant contact with the shaft surface, ensuring reliable sealing throughout the service life of the component.
The additional dust lip improves protection against external contamination, helping extend the life of both the oil seal and the rotating assembly.
Manufactured from ACM (polyacrylate rubber), this seal provides excellent resistance to heat, oxidation and ageing while maintaining very good compatibility with mineral oils and transmission lubricants. These characteristics make ACM a preferred sealing material for automotive drivetrains and industrial power transmission equipment operating at elevated temperatures.
Key Features
- Original CORTECO OEM quality
- TC double lip design
- Spring-loaded primary sealing lip
- Additional dust protection lip
- High resistance to elevated temperatures
- Excellent resistance to mineral oils
- Very good ageing resistance
- Good oxidation resistance
- Long service life
- Precision manufacturing
Typical Applications
The CORTECO 19035135 oil seal is commonly used in:
- Internal combustion engines
- Automotive transmissions
- Gearboxes
- Industrial drives
- Pumps
- Agricultural machinery
- Industrial equipment
- Power transmission systems
- OEM manufacturing
- Maintenance and repair (MRO)
Seal selection should always follow the equipment manufacturer's engineering specifications.
Why Choose ACM Material?
ACM (polyacrylate rubber) is specifically developed for sealing applications involving lubricating oils and elevated operating temperatures. Compared with conventional NBR compounds, ACM provides significantly better resistance to thermal ageing and oxidation, making it particularly suitable for modern automotive and industrial powertrain systems.
FAQ
What does TC mean?
TC indicates a double lip rotary shaft oil seal with a spring-loaded primary sealing lip and an auxiliary dust lip.
What are the seal dimensions?
The seal measures 15 mm × 24 mm × 5 mm.
What material is used?
The seal is manufactured from ACM (polyacrylate rubber).
What is ACM suitable for?
ACM is especially suitable for applications involving mineral oils, transmission lubricants and elevated operating temperatures.
Does the seal include a garter spring?
Yes. The primary sealing lip is equipped with a garter spring to maintain constant sealing pressure.
Where is the CORTECO 19035135 commonly used?
Typical applications include engines, gearboxes, transmissions, pumps and industrial power transmission equipment.
19035135
2 pcs.
Data sheet
- Diameter in. (mm)
- 15
- Diameter out. (mm)
- 24
- Height (mm)
- 5
- Mark
- CORTECO
