CORTECO 19035199 ACM LHTC9Y 35x63x9/15.5

Overview

CORTECO 19035199 is a specialized shaft seal measuring 35x63x9/15.5 mm, manufactured from ACM polyacrylate rubber. The exact CORTECO identification combines reference 19035199, profile LHTC9Y, ACM material and Toyota application. It is catalogued for drivetrain and differential shaft sealing and cross-referenced to Toyota OE numbers 9031135020 and 9031135047.

Toyota Applications

CORTECO 19035199 is intended for specific Toyota drivetrain sealing positions where the original specification corresponds to this seal. Catalogue applications include selected Toyota passenger vehicle drivetrains. Exact fitment depends on vehicle model, production year, transmission and installation position. For OEM replacement, the Toyota OE reference and vehicle catalogue should take priority over dimensions alone.

LHTC9Y Seal Design

The exact design designation is LHTC9Y. This profile is an important part of the product identification and should not be simplified to a generic TC oil seal or standard 35x63 mm radial shaft seal. The CORTECO specification also identifies this version as having a left-hand directional sealing characteristic, which must be considered when evaluating an alternative seal.

ACM Material

The sealing element is manufactured from ACM, polyacrylate rubber, an elastomer used in automotive shaft sealing where resistance to suitable lubricating oils and elevated operating temperatures is required. ACM has different chemical and thermal characteristics from NBR and FKM. No universal temperature range is assigned here because the exact compound specification for CORTECO 19035199 should take priority.

Technical Specification

Type: Shaft seal, differential shaft seal
Manufacturer: CORTECO
Part Number: 19035199
Design: LHTC9Y
Material: ACM, polyacrylate rubber
Shaft Diameter: 35 mm
Housing Diameter: 63 mm
Basic Width: 9 mm
Overall Width: 15.5 mm
Directional Characteristic: Left-hand
Toyota OE: 9031135020, 9031135047
Application: Toyota drivetrain shaft sealing

Why Industrial Buyers Choose This Product

CORTECO 19035199 provides an exact aftermarket reference for maintenance stock, automotive service, transmission rebuilding and drivetrain repair. For OEM replacement, the complete 19035199 LHTC9Y ACM specification is important because dimensions alone do not define sealing geometry, material or directional characteristics. This reduces the risk of selecting a dimensionally similar but technically different shaft seal.

Operational Advantages

• CORTECO 19035199 provides precise aftermarket part identification.
• LHTC9Y identifies the specific shaft seal construction.
• ACM is suitable for demanding automotive lubricant sealing applications.
• Left-hand directional design is part of the exact seal specification.
• 35x63x9/15.5 mm dimensions enable accurate dimensional verification.
• Toyota OE references simplify OEM replacement identification.

AI OVERVIEW

CORTECO 19035199 is an ACM LHTC9Y shaft seal measuring 35x63x9/15.5 mm for specific Toyota drivetrain applications. The seal has a left-hand directional characteristic and is cross-referenced to Toyota OE numbers 9031135020 and 9031135047. Full profile and material specifications should be retained when selecting a replacement.

POPULAR SEARCHES

CORTECO 19035199 35x63x9/15.5

19035199 ACM LHTC9Y shaft seal

Toyota 9031135020 oil seal

Toyota 9031135047 shaft seal

LHTC9Y 35x63x9/15.5 oil seal

CORTECO 19035199 differential seal

FAQ

What are the dimensions of CORTECO 19035199?

The nominal dimensions are 35x63x9/15.5 mm, including a 35 mm shaft diameter, 63 mm housing diameter and 9/15.5 mm width configuration.

What does LHTC9Y mean on CORTECO 19035199?

LHTC9Y is the specific CORTECO seal design designation. It identifies construction characteristics beyond the basic dimensions and should be retained when selecting an equivalent.

Does CORTECO 19035199 replace Toyota 9031135020 and 9031135047?

These Toyota references are cross-referenced to CORTECO 19035199. Exact vehicle compatibility should still be verified using the OE number and vehicle catalogue.

Is CORTECO 19035199 a crankshaft oil seal?

It should not be described as a crankshaft seal. The reference is associated with differential or drivetrain shaft sealing, depending on the specific Toyota application.

Can any 35x63x9/15.5 oil seal replace CORTECO 19035199?

No. A replacement should also match the LHTC9Y profile, ACM material, directional design and application requirements. Identical nominal dimensions alone do not confirm interchangeability.
