CORTECO 19035293 ACM HTC9 35x58x9.5/13.5 mm Automatic Transmission Shaft Seal

CORTECO 19035293 ACM HTC9 35x58x9.5/13.5 mm Automatic Transmission Shaft Seal

CORTECO 19035293 / 19035293B is an ACM shaft seal with CORTECO profile HTC9 and full catalogue dimensions 35x58x9.5/13.5 mm. The product is catalogued as an automatic transmission shaft seal for SUZUKI applications. The CORTECO commercial number is 82035293, and the confirmed OE reference is SUZUKI 27441-60G10.

Technical Data - CORTECO 19035293

CORTECO 19035293 - Precise Product Identification

The complete product designation is:

CORTECO 19035293 ACM HTC9 35x58x9.5/13.5 mm

Current reference:

CORTECO 19035293B

Commercial number:

82035293

Material:

ACM

Profile:

HTC9

Complete dimensions:

35x58x9.5/13.5 mm

Confirmed OE reference:

SUZUKI 27441-60G10

Alternative OE format:

2744160G10

EAN:

3358960427564

When selecting a replacement, retain the complete 35x58x9.5/13.5 mm dimensions. Reducing the designation to 35x58x9.5 mm may omit an important feature of the seal geometry.

CORTECO 19035293 Dimensions

Catalogue dimensions:

• inner diameter: 35 mm
• outer diameter: 58 mm
• basic width: 9.5 mm
• overall / second width: 13.5 mm

Complete catalogue designation:

35x58x9.5/13.5 mm

For this product, the 9.5/13.5 mm dimension is particularly important.

The dimensions should not be simplified to:

35x58x9.5 mm

or:

35x58x10 mm

unless interchangeability is explicitly confirmed by reliable technical documentation.

ACM - Polyacrylate Rubber

CORTECO 19035293 is manufactured from:

ACM - polyacrylate rubber

ACM elastomers are used in various automotive sealing applications, including components operating in oil-lubricated drivetrain systems.

Typical characteristics associated with ACM materials include:

• good resistance to many oils,
• good ageing resistance,
• suitability for oil-lubricated systems,
• use in automotive sealing applications,
• use in drivetrain sealing systems.

Actual performance depends on the specific ACM compound, operating medium, temperature, shaft speed and complete sealing system.

A universal operating temperature range should therefore not be assigned to this specific CORTECO reference solely from generic ACM material data.

CORTECO HTC9 Profile

The confirmed CORTECO construction designation is:

HTC9

The profile is an important part of the technical identification of CORTECO 19035293.

The individual letters and number in the HTC9 designation should not automatically be decoded using another seal manufacturer's nomenclature.

For technical purchasing and replacement selection, retain the complete designation:

CORTECO 19035293 ACM HTC9 35x58x9.5/13.5 mm

Why Is the 9.5/13.5 mm Dimension Important?

CORTECO specifies two width values for this seal:

9.5 mm

and:

13.5 mm

This means that the product should not be identified merely as a simple 35x58x9.5 mm radial shaft seal.

The complete geometry can affect how the seal is positioned and how it interfaces with the surrounding components.

For this reason, the H1, technical specification and product identification should retain the complete dimension:

35x58x9.5/13.5 mm

CORTECO 19035293 - Automatic Transmission Shaft Seal

CORTECO 19035293B is catalogued as an:

automatic transmission shaft seal

The reference is associated with:

SUZUKI

Precise seal selection is particularly important in automatic transmission applications.

A replacement should not be selected solely by shaft and housing diameters.

The following should also be considered:

• complete width,
• HTC9 profile,
• ACM material,
• seal construction,
• OE reference,
• specific transmission version.

CORTECO 19035293 and SUZUKI 27441-60G10

The confirmed OE reference is:

SUZUKI 27441-60G10

The same reference may also be written without separators:

2744160G10

The product may therefore be searched as:

SUZUKI 27441-60G10

SUZUKI 2744160G10

27441-60G10 oil seal

27441-60G10 transmission seal

2744160G10 shaft seal

as well as by the CORTECO references:

CORTECO 19035293

CORTECO 19035293B

CORTECO 82035293

Compatibility should be confirmed for the specific vehicle and automatic transmission version before installation.

CORTECO 19035293 vs Standard 35x58 Oil Seal

The dimensions:

35x58 mm

alone are not sufficient to identify CORTECO 19035293.

Seals within the same dimensional group may differ in:

• width,
• material,
• profile,
• construction,
• intended application.

For CORTECO 19035293, retain:

35x58x9.5/13.5 mm

and:

ACM HTC9

These are important parts of the technical product identification.

Can a 35x58x10 Oil Seal Replace CORTECO 19035293?

This should not be assumed.

CORTECO 19035293 has catalogue dimensions:

35x58x9.5/13.5 mm

A standard 35x58x10 mm seal differs not only in nominal width but may also have completely different geometry and profile.

Selecting a replacement solely from the 35x58 mm shaft and housing diameters may therefore result in an incorrect part.

Can NBR Replace ACM?

Not automatically.

The specified material for this reference is:

ACM

NBR and ACM belong to different elastomer families and have different material characteristics.

Before changing the material, verify:

• transmission fluid / operating medium,
• operating temperature,
• shaft speed,
• automatic transmission requirements,
• seal profile,
• complete geometry,
• manufacturer's requirements.

Dimensional compatibility alone does not confirm material compatibility.

Can FPM Replace ACM?

This should not be assumed either.

FPM has different material characteristics from ACM. A material offering high resistance to certain operating media is not automatically a technically correct replacement.

For CORTECO 19035293, the complete product specification should be considered:

ACM + HTC9 + 35x58x9.5/13.5 mm + automatic transmission application

Material substitution should therefore only be made when technical compatibility has been confirmed.

Alternative References and Search Terms

This product may be searched as:

CORTECO 19035293

CORTECO 19035293B

CORTECO 82035293

19035293 CORTECO

19035293B CORTECO

CORTECO 19035293 ACM

CORTECO 19035293 HTC9

CORTECO HTC9 35x58x9.5/13.5

ACM HTC9 35x58x9.5/13.5

Simmerring 35x58x9.5/13.5

Oil seal 35x58x9.5/13.5

ACM oil seal 35x58x9.5/13.5

HTC9 oil seal

Shaft seal 35x58x9.5/13.5

Radial shaft seal 35x58x9.5/13.5

Transmission shaft seal 35x58x9.5/13.5

Automatic transmission seal 35x58x9.5/13.5

Automatic transmission oil seal 35x58x9.5/13.5

SUZUKI 27441-60G10

SUZUKI 2744160G10

27441-60G10 oil seal

27441-60G10 transmission seal

2744160G10 shaft seal

How to Select a Replacement for CORTECO 19035293

Verify:

• reference: 19035293 / 19035293B
• commercial number: 82035293
• inner diameter: 35 mm
• outer diameter: 58 mm
• basic width: 9.5 mm
• overall / second width: 13.5 mm
• complete dimensions: 35x58x9.5/13.5 mm
• material: ACM
• profile: HTC9
• complete seal construction,
• automatic transmission application.

For SUZUKI applications, also verify:

OE 27441-60G10

Selection by the complete CORTECO reference or confirmed OE number is more reliable than selection based solely on dimensions.

Installation Recommendations

Before installation, carefully clean the shaft, housing and mating surfaces.

Check:

• shaft surface condition,
• sealing lip contact area,
• housing condition,
• absence of burrs,
• absence of sharp edges,
• absence of corrosion,
• absence of excessive wear,
• correct seal orientation.

Protect the sealing elements against cutting, folding or deformation during installation.

The seal should be installed evenly using an appropriate installation tool.

For automatic transmission applications, follow the installation procedure specified for the particular transmission assembly.

FAQ

What are the dimensions of CORTECO 19035293?

The complete catalogue dimensions are 35x58x9.5/13.5 mm.

What material is CORTECO 19035293 made from?

The material is ACM - polyacrylate rubber.

What profile does CORTECO 19035293 have?

The CORTECO profile is HTC9.

What is the current CORTECO reference?

The current aftermarket reference is CORTECO 19035293B.

What is the CORTECO commercial number?

The commercial number is 82035293.

What is the SUZUKI OE reference?

The confirmed OE reference is SUZUKI 27441-60G10, also written as 2744160G10.

What is the EAN?

The EAN is 3358960427564.

Is CORTECO 19035293 an automatic transmission seal?

Yes. The reference is catalogued as an automatic transmission shaft seal.

Can the dimensions be simplified to 35x58x9.5?

This is not recommended. The complete catalogue designation is 35x58x9.5/13.5 mm, and both width values are relevant to correct product identification.

Can a 35x58x10 oil seal be used instead?

This should not be assumed. CORTECO 19035293 has the HTC9 profile, ACM material and complete dimensions of 35x58x9.5/13.5 mm.

Can NBR be used instead of ACM?

Not automatically. Material compatibility, seal profile, complete geometry, transmission fluid and operating conditions must be verified before using a different seal.

CORTECO 19035293 - Quick Answer

CORTECO 19035293 / 19035293B is an ACM HTC9 automatic transmission shaft seal with complete dimensions of 35x58x9.5/13.5 mm. The CORTECO commercial number is 82035293, EAN 3358960427564, and the confirmed OE reference is SUZUKI 27441-60G10 / 2744160G10. Replacement selection should retain the complete 9.5/13.5 mm geometry rather than relying only on the 35x58 mm diameters.
