CORTECO 19036714 FPM BF 31x38x9.8/11.6 mm Automatic Transmission Shaft Seal

CORTECO 19036714 FPM BF 31x38x9.8/11.6 mm Automatic Transmission Shaft Seal

CORTECO 19036714 is a specialized automatic transmission shaft seal manufactured from FPM fluoroelastomer, with CORTECO profile BF and catalogue dimensions 31x38x9.8/11.6 mm. The current aftermarket reference is 19036714B, while the CORTECO commercial number is 82036714. Confirmed OE references include VAG 01V409400B for AUDI, VW, SKODA and SEAT, and ZF 0734319604.

Technical Data - CORTECO 19036714

CORTECO 19036714 - Precise Product Identification

The complete technical identification is:

CORTECO 19036714 FPM BF 31x38x9.8/11.6 mm

Current aftermarket catalogues may list the product as:

CORTECO 19036714B

CORTECO commercial number:

82036714

Profile:

BF

Material:

FPM

CORTECO catalogue documentation also identifies the construction as:

RWDR-KOMBI

For purchasing, technical identification and replacement selection, the complete CORTECO reference or confirmed OE number should be used whenever possible.

CORTECO 19036714 Dimensions

CORTECO catalogue dimensions are:

• inner diameter: 31 mm
• outer diameter: 38 mm
• height 1: 9.8 mm
• height 2: 11.6 mm

Complete dimension:

31x38x9.8/11.6 mm

Some aftermarket databases may round the first height value to 10 mm. For precise technical identification, the CORTECO catalogue format:

31x38x9.8/11.6 mm

is preferable.

FPM Fluoroelastomer

CORTECO 19036714 is manufactured from FPM, a fluoroelastomer used in technical sealing applications.

FPM materials are widely used in demanding sealing systems involving oils, lubricants, elevated temperatures and other challenging operating conditions.

For this specific CORTECO seal, however, an exact operating temperature range should not be assigned solely from general FPM material properties.

Seal selection should consider:

• operating fluid,
• operating temperature,
• rotational speed,
• lubrication conditions,
• transmission design,
• transmission manufacturer requirements,
• OE reference.

CORTECO BF Profile

The confirmed CORTECO profile designation is:

BF

This is an important part of the technical product identification and should be considered when selecting an equivalent seal.

The individual letters in BF should not be interpreted using another manufacturer's nomenclature because profile designation systems are not universal across seal manufacturers.

CORTECO documentation for this reference also uses the construction designation:

RWDR-KOMBI

For this reason, the nominal 31x38 mm diameters alone are not sufficient for selecting a replacement.

Automatic Transmission Shaft Seal

CORTECO 19036714B is catalogued as a shaft sealing ring for an automatic transmission.

The product appears in parts catalogues for selected VAG vehicles and is also associated with a ZF transmission reference.

Compatibility with a particular vehicle or transmission should always be confirmed using the OE number and exact transmission version.

AUDI 01V409400B

A confirmed OE reference associated with CORTECO 19036714B is:

AUDI 01V409400B

The OE number is an important identification point, particularly when selecting a seal for a specific automatic transmission.

Volkswagen 01V409400B

The corresponding Volkswagen OE reference is:

VW 01V409400B

The same VAG part number is used across several Volkswagen Group brands.

SKODA 01V409400B

The confirmed SKODA reference is:

SKODA 01V409400B

Aftermarket catalogue data associates this seal with selected vehicle and transmission configurations.

Exact compatibility should always be verified before installation.

SEAT 01V409400B

The product is also cross-referenced as:

SEAT 01V409400B

Compatibility with a specific SEAT vehicle depends on the transmission and vehicle configuration.

ZF 0734319604

An especially important reference for transmission-based product identification is:

ZF 0734319604

It may also be written as:

ZF 0734 319 604

The ZF reference is particularly useful when identifying the seal according to the transmission manufacturer rather than the vehicle manufacturer.

CORTECO 19036714 vs 19036714B

Two CORTECO reference formats may be encountered:

CORTECO 19036714

and the current aftermarket reference:

CORTECO 19036714B

The associated commercial number is:

82036714

When searching for the product, all three numbers can be useful.

The key technical specification remains:

FPM BF 31x38x9.8/11.6 mm

Alternative References and Search Terms

This product may be searched as:

CORTECO 19036714

19036714 CORTECO

CORTECO 19036714B

19036714B CORTECO

CORTECO 82036714

82036714 CORTECO

CORTECO BF 31x38x9.8/11.6

CORTECO 19036714 FPM

CORTECO 19036714 BF

CORTECO 19036714 31x38

19036714 FPM BF

BF oil seal 31x38

Simmerring 31x38x9.8/11.6

Oil seal 31x38x9.8/11.6

Automatic transmission shaft seal 31x38

Automatic gearbox seal 31x38

Transmission oil seal 31x38

VAG 01V409400B

AUDI 01V409400B

VW 01V409400B

SKODA 01V409400B

SEAT 01V409400B

ZF 0734319604

ZF 0734 319 604

Searching by the CORTECO, VAG or ZF reference provides more precise identification than searching by dimensions alone.

Is Every 31x38 Seal Interchangeable?

No.

CORTECO 19036714B is a specialized transmission sealing component with a specific construction.

Replacement selection should consider the complete specification:

31x38x9.8/11.6 mm + FPM + BF + seal construction + automatic transmission application

Another seal with nominal 31x38 mm diameters may differ in:

• width or height,
• geometry,
• sealing lip design,
• construction,
• elastomer material,
• intended function within the transmission.

Dimensions alone do not confirm interchangeability.

Can NBR Replace FPM?

CORTECO 19036714 should not automatically be replaced with an NBR seal.

The confirmed original specification is:

FPM

NBR and FPM are different elastomer groups with different material characteristics.

Changing the material may affect chemical resistance, temperature capability and seal durability.

For an automatic transmission application, the seal material should be compatible with the operating fluid and conditions specified by the transmission manufacturer.

How to Select a Replacement for CORTECO 19036714

When selecting an alternative seal, verify:

• inner diameter 31 mm,
• outer diameter 38 mm,
• heights 9.8/11.6 mm,
• FPM material,
• BF profile,
• seal construction,
• installation position within the transmission,
• operating fluid,
• temperature,
• rotational speed,
• OE reference.

For VAG applications, compare:

01V409400B

For identification according to the transmission manufacturer, compare:

ZF 0734319604

Matching the OE reference is significantly more reliable than selecting a seal solely from its nominal dimensions.

Vehicle Applications

Aftermarket catalogues associate CORTECO 19036714B with selected versions of vehicles including:

• Audi A4 B5,
• Audi A4 B6,
• Audi A4 B7,
• Audi Allroad C5,
• Skoda Superb I,
• Volkswagen Passat B5,
• Volkswagen Passat B5.5.

This does not mean that the seal fits every engine or transmission version used in these vehicle families.

Before ordering for a specific vehicle, verify the OE reference, exact transmission type and vehicle configuration.

Why Is the ZF Reference Important?

Automatic transmissions can be used by several vehicle manufacturers and across multiple vehicle models.

For this reason, a transmission manufacturer's reference can be particularly valuable when identifying internal transmission components.

For CORTECO 19036714B, the confirmed ZF reference is:

0734319604

This provides an additional identification route alongside the VAG number:

01V409400B

Installation Recommendations

Before installation, check:

• condition of the mating surface,
• condition of the seal housing,
• correct seal orientation,
• absence of mechanical damage,
• cleanliness of the installation area,
• compatibility with the transmission service documentation.

Because this is a specialized automatic transmission seal, installation depth, lubrication procedure and other transmission-specific assembly instructions should not be assumed without the relevant service documentation.

FAQ

What are the dimensions of CORTECO 19036714?

The CORTECO catalogue specifies 31x38x9.8/11.6 mm.

What material is CORTECO 19036714 made from?

The seal is manufactured from FPM fluoroelastomer.

What profile does CORTECO 19036714 have?

The confirmed CORTECO profile is BF.

What is the current CORTECO reference?

The current aftermarket reference is 19036714B.

What is the CORTECO commercial number?

The commercial number is 82036714.

What is CORTECO 19036714 used for?

The product is catalogued as a shaft sealing ring for an automatic transmission.

What is the VAG OE number?

The confirmed VAG reference is 01V409400B, associated with AUDI, VW, SKODA and SEAT.

What is the ZF reference?

The confirmed ZF reference is 0734319604.

Is 0734 319 604 the same reference?

Yes. 0734 319 604 is an alternative formatting of ZF reference 0734319604.

Are 31x38 mm dimensions enough to select a replacement?

No. The complete dimensions 31x38x9.8/11.6 mm, FPM material, BF profile, seal construction and transmission application should all be considered.

Can a standard radial shaft seal replace CORTECO 19036714?

Not automatically. CORTECO 19036714B is a specialized automatic transmission sealing component. A standard oil seal with similar diameters may have a different geometry, height, material and sealing construction.

CORTECO 19036714 - Quick Answer

CORTECO 19036714 / 19036714B is an FPM BF automatic transmission shaft seal with catalogue dimensions 31x38x9.8/11.6 mm. Its CORTECO commercial number is 82036714. Confirmed OE references include VAG 01V409400B for AUDI, VW, SKODA and SEAT and ZF 0734319604. Replacement selection should consider the complete seal construction and OE reference, not dimensions alone.

Available from simmering.pl, a specialist B2B supplier of radial shaft seals, transmission seals, O-rings, V-rings and bearings. Products are shipped worldwide from stock in Poland.
