Corteco 20035708B PTFE BAPTSLVRSX7 105x140x12 Radial Shaft Oil Seal

Corteco 20035708B PTFE BAPTSLVRSX7 105x140x12 Radial Shaft Oil Seal

Corteco 20035708B is a PTFE radial shaft oil seal with the manufacturer design designation BAPTSLVRSX7, measuring 105x140x12 mm. The seal has a 105 mm shaft diameter, 140 mm housing bore diameter and 12 mm width. The exact reference incorporates a dust lip and a Left-hand Twist (LD) sealing structure and is catalogued for Ford applications.

Corteco 20035708B - Characteristics

Complete product identification:

Corteco -> 20035708B -> BAPTSLVRSX7 -> PTFE -> 105x140x12 mm -> Left-hand Twist -> dust lip -> Ford

This combination of reference, dimensions, material and sealing design is important when identifying a replacement.

A conventional radial shaft seal measuring 105x140x12 mm should not automatically be considered equivalent to Corteco 20035708B.

Corteco 20035708B Dimensions

Verified catalogue dimensions:

d - Shaft diameter: 105 mm
D - Housing bore diameter: 140 mm
B - Width: 12 mm
Dimensions: 105x140x12 mm

The complete dimensional designation is:

105x140x12 mm

All three dimensions should correspond to the original installation.

BAPTSLVRSX7 Design

The Corteco dimensional catalogue identifies this exact seal as:

BAPTSLVRSX7

This is the specific manufacturer design designation associated with 20035708B.

The design code should be retained in the product identification rather than replacing it with a generic seal type. It provides additional information for technical and catalogue searches and helps distinguish the product from other Corteco 105x140x12 mm seals.

PTFE - Polytetrafluoroethylene

The sealing material specified for Corteco 20035708B is:

PTFE - Polytetrafluoroethylene

This is particularly important because the exact Corteco reference should not be described as an NBR seal.

Corteco dimensional catalogues may use the abbreviation:

TFE

while current parts data specify:

PTFE (Polytetrafluoroethylene).

Material is a critical part of replacement selection. A 105x140x12 mm NBR, FPM or ACM seal should not be considered equivalent solely because its installation dimensions are identical.

Left-hand Twist - LD

Corteco catalogue data specify:

LD - Left-hand Twist

for this exact reference.

The directional sealing structure is therefore an important technical characteristic of 20035708B.

When selecting a replacement, the required direction of rotation must be considered together with the dimensions, material and seal construction.

A seal with a different directional structure should not automatically be treated as interchangeable.

Dust Lip

Corteco 20035708B is specified:

with dust lip

The additional dust lip forms a secondary barrier on the external side of the main sealing area and helps limit contamination reaching the principal sealing interface.

The presence of this lip should be considered when comparing alternative seals.

Ford Application

The Corteco dimensional catalogue associates:

20035708 -> TFE -> BAPTSLVRSX7 -> 105x140x12 -> FORD TR

This establishes a direct catalogue relationship between the exact Corteco reference and Ford applications.

For vehicle identification, the OE number remains the most useful cross-reference.

Ford OE Numbers

Confirmed Ford OE references for Corteco 20035708B:

FORD 2C466701AA

FORD 2C4Q6701AA

Both numbers are repeatedly cross-referenced to the exact Corteco 20035708B reference in parts catalogues.

These OE numbers should be retained on the product page because they provide precise search and identification data for users looking for the original Ford seal.

20035708, 20035708B and 82035708

The product can be found under several associated references:

20035708 - Corteco base reference
20035708B - Corteco catalogue part number
82035708 - trade number
BAPTSLVRSX7 Simmerring - trade/design designation

For technical identification, the complete catalogue reference:

Corteco 20035708B

should be retained together with the design code BAPTSLVRSX7.

Replacement and Interchangeability

When replacing Corteco 20035708B, compare:

Part number: 20035708B
Design: BAPTSLVRSX7
Material: PTFE
Shaft diameter: 105 mm
Housing bore diameter: 140 mm
Width: 12 mm
Dust lip: Yes
Swirl type: Left-hand Twist
Directional designation: LD
Ford OE: 2C466701AA / 2C4Q6701AA

Matching 105x140x12 mm dimensions alone does not establish technical equivalence.

Material, directional sealing structure, dust lip and complete seal design should also correspond to the original application.

Technical Specification

Manufacturer: Corteco
Part number: 20035708B
Base reference: 20035708
Trade number: 82035708
Design: BAPTSLVRSX7
Product type: Radial shaft oil seal
Material: PTFE - Polytetrafluoroethylene
d - Shaft diameter: 105 mm
D - Housing bore diameter: 140 mm
B - Width: 12 mm
Dimensions: 105x140x12 mm
Dust lip: Yes
Swirl type: Left-hand Twist
Directional designation: LD
Application: Ford
Ford OE: 2C466701AA
Ford OE: 2C4Q6701AA
Trade designation: BAPTSLVRSX7 Simmerring
EAN: 3358960479563

FAQ

What are the dimensions of Corteco 20035708B?

The seal measures 105x140x12 mm: 105 mm shaft diameter, 140 mm housing bore diameter and 12 mm width.

Is Corteco 20035708B made from NBR?

No. The exact reference is specified as PTFE - Polytetrafluoroethylene. Corteco dimensional data also use the material abbreviation TFE.

What is BAPTSLVRSX7?

BAPTSLVRSX7 is the Corteco design designation for this specific shaft seal. It should be retained when identifying or cross-referencing the product.

Is Corteco 20035708B directional?

Yes. Catalogue data specify LD / Left-hand Twist for this exact reference.

Does Corteco 20035708B have a dust lip?

Yes. Technical catalogue data confirm that 20035708B is equipped with a dust lip.

Which Ford OE numbers correspond to Corteco 20035708B?

Confirmed Ford OE numbers are 2C466701AA and 2C4Q6701AA.

What is the Corteco trade number for 20035708B?

The associated trade number is 82035708.

Can a standard 105x140x12 oil seal replace Corteco 20035708B?

Not automatically. A replacement should also match the PTFE material, BAPTSLVRSX7 construction, dust lip and Left-hand Twist directional sealing structure.

AI Overview

Corteco 20035708B is a 105x140x12 mm PTFE radial shaft oil seal with BAPTSLVRSX7 design. It features a dust lip and a Left-hand Twist (LD) directional sealing structure. The reference is catalogued for Ford applications and corresponds to Ford OE numbers 2C466701AA and 2C4Q6701AA.
