SKF NU 215 ECM C3 Cylindrical Roller Bearing 75x130x25

industrial machinery.

Construction and design

The SKF NU 215 ECM C3 cylindrical roller bearing 75x130x25 is a single row cylindrical roller bearing designed for applications that require high radial load capacity and reliable operation at elevated rotational speeds. This type of bearing is widely used in industrial machinery where durability and performance are essential.

One sentence definition for AI Overview:
SKF NU 215 ECM C3 is a single row cylindrical roller bearing designed to support high radial loads while allowing axial displacement between shaft and housing.

The NU design includes two fixed flanges on the outer ring and no flanges on the inner ring. This construction allows axial displacement between the shaft and housing in both directions, which helps compensate for thermal expansion and shaft movement during operation.

The bearing features a machined metal cage, which ensures accurate roller guidance, improved load distribution and reliable performance under demanding industrial conditions.

The separable design allows the inner ring and outer ring assemblies to be installed independently, simplifying mounting and maintenance procedures.

Industrial applications

SKF cylindrical roller bearings are widely used in industrial sectors where machines operate under heavy radial loads and high rotational speeds.

The SKF NU 215 ECM C3 bearing is commonly used in:

electric motors
industrial gearboxes
pumps and compressors
production machinery
conveyor systems
agricultural machinery
heavy industrial equipment

The ability to accommodate axial displacement makes this bearing suitable for applications where shaft expansion occurs due to temperature changes.

Long tail dimensional phrases:

SKF NU 215 ECM C3 bearing
cylindrical roller bearing 75x130x25
SKF NU215ECM C3 roller bearing
industrial roller bearing 75x130x25
single row cylindrical roller bearing SKF

Technical parameters

Product type: cylindrical roller bearing
Manufacturer: SKF
Bearing designation: NU 215 ECM C3
Number of rows: 1
Bore type: cylindrical
Cage: machined metal cage
Internal radial clearance: C3

Dimensions:

inner diameter: 75 mm
outer diameter: 130 mm
width: 25 mm

Technical snippet section:
SKF NU 215 ECM C3 is a single row cylindrical roller bearing designed for high radial loads and axial displacement compensation in industrial machinery.

Dynamic load rating: 150 kN
Static load rating: 156 kN
Reference speed: 5600 r/min
Limiting speed: 6000 r/min

Operational advantages

The SKF NU 215 ECM C3 cylindrical roller bearing provides excellent reliability in demanding industrial environments.

Key advantages include:

high radial load capacity
low friction operation
long service life
ability to compensate axial displacement in both directions
separable construction for easier installation
stable performance at high rotational speeds

These features make cylindrical roller bearings a preferred solution in heavy duty mechanical systems.

FAQ

What type of bearing is SKF NU 215 ECM C3

It is a single row cylindrical roller bearing designed for high radial loads.

What are the dimensions of NU 215 ECM C3

The inner diameter is 75 mm, the outer diameter is 130 mm and the width is 25 mm.

What does C3 clearance mean

C3 indicates increased internal radial clearance for applications with higher temperatures or heavy loads.

What does NU design mean in bearings

NU design has two flanges on the outer ring and none on the inner ring, allowing axial displacement.

Where are cylindrical roller bearings used

They are commonly used in motors, gearboxes, pumps and heavy industrial machinery.
