NKE NU 2309 E TVP3 Single Row Cylindrical Roller Bearing 45x100x36 mm

AI Overview

The NKE NU 2309 E TVP3 is a single row cylindrical roller bearing designed to support high radial loads in industrial machinery and mechanical equipment. Featuring a 45 mm bore, 100 mm outside diameter and 36 mm width, this bearing uses the NU design with two flanges on the outer ring and no flanges on the inner ring, allowing axial displacement between the shaft and housing. The TVP3 designation identifies a glass fibre reinforced polyamide cage.

Weight: Approximately 1.3 kg

Product Description

The NKE NU 2309 E TVP3 is a precision single row cylindrical roller bearing developed for applications requiring high radial load capacity and reliable operation. Compared with ball bearings of similar dimensions, cylindrical roller bearings provide greater radial load capability because the rollers create a line contact with the raceways instead of point contact.

The NU design incorporates two integral flanges on the outer ring, while the inner ring has no flanges. This arrangement allows axial displacement between the shaft and housing, making the bearing suitable for applications where thermal expansion or shaft elongation must be accommodated without introducing additional internal stresses.

The bearing features a TVP3 cage manufactured from glass fibre reinforced polyamide. This cage accurately guides the cylindrical rollers, maintains proper spacing between rolling elements and contributes to smooth operation under normal operating conditions. The open bearing design allows lubrication to be selected according to the machine manufacturer's maintenance schedule and application requirements.

With standardized dimensions of 45x100x36 mm, the NU 2309 E TVP3 is easily identified during maintenance, repair and spare parts management. The internationally recognized designation simplifies bearing selection for OEM equipment, industrial maintenance departments and MRO operations.

This bearing is widely used in industrial machinery, power transmission systems, production equipment, industrial automation and mechanical engineering applications where high radial load capacity and axial displacement capability are required.

Bearing Selection

Before selecting NKE NU 2309 E TVP3, verify:

• Shaft diameter: 45 mm
• Housing bore diameter: 100 mm
• Bearing width: 36 mm
• Bearing type: Single row cylindrical roller bearing
• NU internal design
• Internal clearance
• Lubrication method
• Operating conditions
• Radial load requirements
• Required axial displacement capability

Final bearing selection should always follow the equipment manufacturer's technical documentation.

Applications

The NKE NU 2309 E TVP3 is intended for general industrial machinery and mechanical engineering applications. The NU design is particularly suitable where high radial loads must be supported while allowing axial displacement of the shaft relative to the housing. Final application should always comply with the machine manufacturer's technical specifications.

Why do engineers choose this model?

• High radial load carrying capacity.
• NU design allows axial displacement between shaft and housing.
• TVP3 glass fibre reinforced polyamide cage.
• Standard dimensions of 45x100x36 mm.
• Open bearing design for application-specific lubrication.
• Easy identification using the NU 2309 E TVP3 designation.
• Suitable for OEM equipment, industrial maintenance and MRO.
• Reliable cylindrical roller bearing design for demanding industrial applications.

FAQ

What type of bearing is NKE NU 2309 E TVP3?
It is a single row cylindrical roller bearing.

What does the NU design mean?
The outer ring has two flanges, while the inner ring has no flanges, allowing axial displacement.

What are the bearing dimensions?
45 mm bore, 100 mm outside diameter and 36 mm width.

What does TVP3 indicate?
It identifies a glass fibre reinforced polyamide cage.

Is this a sealed bearing?
No. It is supplied as an open bearing.

What loads is it designed to carry?
It is primarily intended for high radial loads.
