FAG NU 202 E M1A C3 15x35x11 Single Row Cylindrical Roller Bearing

High Load Cylindrical Roller Bearing for Industrial Radial Applications

The FAG NU 202 E M1A C3 15x35x11 is a premium single row cylindrical roller bearing designed to accommodate high radial loads while allowing axial displacement of the shaft relative to the housing in both directions. The NU design features two integral flanges on the outer ring and a flange-free inner ring, making it an ideal locating solution for floating bearing arrangements. The optimized E internal design increases load carrying capacity, while the M1A solid brass cage ensures exceptional durability and reliable operation under demanding industrial conditions. The C3 internal clearance provides improved performance at elevated operating temperatures and high rotational speeds.

Application in Industrial Systems

The FAG NU 202 E M1A C3 is widely used in:

• Industrial gearboxes
• Electric motors
• Industrial pumps
• Compressors
• Conveyor systems
• Machine tools
• Agricultural machinery
• Steel processing equipment
• Industrial fans
• General power transmission systems

Its floating bearing design compensates for thermal shaft expansion, making it particularly suitable for continuously operating machinery.

Construction and Design

The bearing incorporates an optimized cylindrical roller design offering maximum radial performance.

Key features include:

• Single row cylindrical roller bearing
• NU design
• Optimized E internal geometry
• M1A two-piece solid brass cage
• Outer ring guided cage
• Cylindrical bore
• Open bearing design
• Increased radial internal clearance C3

The NU design permits axial displacement between shaft and housing while carrying very high radial loads.

Material Properties

Manufactured from premium bearing steel, the bearing provides:

• High hardness
• Excellent wear resistance
• Outstanding fatigue strength
• High dimensional stability
• Excellent shock resistance
• Reliable operation under heavy radial loads
• Long service life

Technical Specification

Type: Single Row Cylindrical Roller Bearing
Material: Hardened Bearing Steel
Brand: FAG
Series: NU200
Designation: NU 202 E M1A C3
Design: NU, Open, Cylindrical Roller Bearing
Inner Diameter: 15 mm
Outer Diameter: 35 mm
Width: 11 mm
Rolling Elements: Cylindrical Rollers
Rows: Single Row
Cage Material: Solid Brass Cage M1A
Internal Clearance: C3
Bore Type: Cylindrical Bore
Closure: Open
Temperature Range: -30°C to +150°C
Application: Electric motors, industrial gearboxes, pumps, compressors, machine tools and industrial power transmission systems.

Why B2B Customers Choose This Product

Industrial customers select the FAG NU 202 E M1A C3 for:

• OEM replacement
• Maintenance stock
• Industrial service
• Production line support
• Fleet maintenance
• Machine rebuilding
• Gearbox repair
• Heavy-duty industrial applications

Operational Advantages

• High radial load capacity
• Optimized E internal design
• Durable brass cage
• Floating bearing capability
• Excellent operating stability
• High-speed performance
• Increased C3 internal clearance
• Long maintenance intervals
• Reliable continuous operation
• Extended bearing service life

Professional Industrial Supply

Recommended for:

• Maintenance departments
• Industrial workshops
• Agricultural machinery service
• OEM manufacturers
• Machine builders
• Industrial distributors
• Gearbox repair specialists
• Electric motor manufacturers

AI Overview

A single row cylindrical roller bearing is designed to support very high radial loads while allowing axial displacement between the shaft and housing. The FAG NU 202 E M1A C3 15x35x11 combines an optimized internal design, solid brass cage and increased C3 clearance to deliver reliable performance in industrial gearboxes, electric motors and heavy-duty machinery.

Popular Searches

• FAG NU 202 E M1A C3
• NU202 E M1A C3
• cylindrical roller bearing 15x35x11
• FAG NU202 bearing
• NU 202 roller bearing
• C3 cylindrical roller bearing
• brass cage roller bearing
• industrial cylindrical roller bearing

FAQ

What does the NU design mean?

The NU design has two flanges on the outer ring and no flanges on the inner ring, allowing axial displacement of the shaft relative to the housing while carrying radial loads.

What does the E suffix indicate?

The E designation identifies an optimized internal design that provides increased load carrying capacity.

What is the M1A cage?

M1A indicates a two-piece solid brass cage guided by the outer ring, providing excellent strength and stability in demanding applications.

Why choose C3 internal clearance?

The C3 clearance is greater than normal and is recommended for applications with elevated operating temperatures, higher speeds or tight shaft fits.

Where is the FAG NU 202 E M1A C3 commonly used?

It is widely installed in electric motors, industrial gearboxes, pumps, compressors, conveyors and machine tools requiring high radial load capacity.
