SKF 6204‑2Z/C3 | Single-Row Deep Groove Ball Bearing 20x47x14 mm - Double Shielded, C3 Clearance

SKF 6204‑2Z/C3 | Single-Row Deep Groove Ball Bearing 20x47x14 mm - Double Shielded, C3 Clearance

The SKF 6204‑2Z/C3 is a premium single-row deep groove ball bearing designed for maximum performance and longevity:

• Dimensions: Bore 20 mm, Outer Diameter 47 mm, Width 14 mm

• Sealing: Double metal shields (2Z) ensure protection from contaminants while facilitating heat dissipation

• Internal Clearance: C3 (greater than normal), ideal for high-speed and high-temperature environments

• Performance:

  • Dynamic Load Rating: ~13.5 kN

  • Static Load Rating: ~6.55 kN

  • Reference Speed: ~32,000 RPM, Limiting Speed: ~17,000 RPM

• Material & Construction: High-grade bearing steel, sheet steel cage, deep-groove design ensures low friction, minimal noise, and excellent radial and axial load capability

This robust, maintenance-friendly bearing is engineered for endurance across diverse industrial sectors—from motors and pumps to automation and precision machinery.

🌍 Applications

• Industrial motors & gearboxes

• Pumps, compressors, HVAC systems

• Precision machinery, automation lines

• Agricultural equipment, robotics

• Any high-speed machinery requiring low friction and vibration

❓ FAQ - Frequently Asked Questions

Q1: What does “2Z” mean?
“2Z” refers to steel shields on both sides that protect against dust while allowing heat escape.

Q2: Why is C3 clearance used?
C3 internal clearance accommodates thermal expansion and ensures operational stability at high speeds and elevated temperatures.

Q3: Is this bearing suitable for axial loads?
Yes. Deep groove design supports both radial and moderate axial loads in both directions.

Q4: What is the maximum operating speed?
It’s rated for speeds up to 32,000 RPM (reference) and a limiting speed of 17,000 RPM for heavy-duty use .

Q5: Where is SKF 6204‑2Z/C3 manufactured?
SKF bearings are produced globally, maintaining ISO/DIN standards, and the 6204‑2Z/C3 is available from factory-stock with immediate dispatch.
