SKF W 6002-2RS1 15x32x9 mm Stainless Steel Deep Groove Ball Bearing

Technical Specification

The numerical performance values should be checked against the current SKF product data before use in engineering calculations.

Bearing Design and Construction

The SKF W 6002-2RS1 belongs to SKF's stainless steel deep groove ball bearing range.

Its construction consists of an inner ring, outer ring, a single row of balls, a cage and two contact seals.

The deep raceway geometry allows the bearing to support radial loads and axial loads acting in both directions, within the manufacturer's permissible operating limits.

Stainless Steel Construction

The W prefix identifies the stainless steel bearing range.

Stainless steel provides increased resistance to corrosion compared with conventional chromium bearing steel, making this bearing construction relevant to equipment exposed to moisture or other potentially corrosive conditions.

However, stainless steel is not universally corrosion-proof.

Corrosion resistance depends on the chemical environment, operating temperature, exposure duration and maintenance conditions.

The W designation alone should not be interpreted as confirmation of AISI 304 or AISI 316 stainless steel. The exact material grade should be verified against SKF material specifications.

Double-Sided 2RS1 Contact Seals

The bearing incorporates contact seals on both sides.

These seals help:

• Reduce the ingress of dust and external contaminants.

• Retain lubricant inside the bearing.

• Protect the rolling contact surfaces.

• Reduce exposure of internal components to environmental contamination.

The 2RS1 sealing arrangement does not guarantee complete waterproofing or compatibility with every chemical environment.

The seal material and lubricant must be suitable for the intended operating conditions.

SKF W 6002-2RS1 Designation Explained

W – Stainless Steel Bearing

The W prefix identifies SKF's stainless steel deep groove ball bearing design.

6002 – Bearing Series and Size

The 6002 designation identifies a single-row deep groove ball bearing with nominal dimensions of 15x32x9 mm.

2RS1 – Double-Sided Contact Seals

The 2RS1 suffix indicates contact seals installed on both sides of the bearing.

CN – Normal Radial Internal Clearance

The bearing is identified with normal radial internal clearance.

The absence of a C3 suffix means that greater-than-normal clearance should not be assumed.

Load Ratings and Operating Performance

Dynamic Load Rating

The basic dynamic load rating is used in bearing fatigue life calculations under standardized reference conditions.

Actual bearing life depends on applied loads, lubrication, contamination, operating temperature and installation accuracy.

Static Load Rating

The basic static load rating relates to a defined level of permanent deformation at the rolling contacts under standardized loading conditions.

It should not be interpreted as an unrestricted permissible operating load.

Limiting Speed

The limiting speed represents an operating constraint associated with bearing design and lubrication.

The permissible continuous operating speed may be lower depending on load, temperature, cooling and other installation conditions.

SKF W 6002-2RS1 vs SKF 6002-2RS1

Both bearings have the same nominal dimensions but differ in material construction and load ratings.

The stainless steel version has a lower basic dynamic load rating than the conventional steel version.

Identical dimensions do not automatically establish technical interchangeability.

Bearing Selection and Operating Conditions

Selecting the SKF W 6002-2RS1 requires evaluation of mechanical loads, operating speed, environmental exposure and mounting requirements.

Important considerations include:

• Radial and axial load conditions.

• Required fatigue life.

• Operating speed and temperature.

• Shaft and housing fits.

• Effective internal clearance after installation.

• Corrosion resistance requirements.

• Seal and lubricant compatibility.

• Exposure to moisture and contaminants.

Where chemical exposure is expected, the compatibility of both the stainless steel bearing components and the sealing materials must be evaluated.

Industrial Applications

Stainless steel deep groove ball bearings are used in equipment requiring improved resistance to corrosion.

General application categories include:

• Food processing machinery.

• Packaging equipment.

• Industrial conveyor systems.

• Machinery operating in humid environments.

• Compact industrial drives.

• Rotating mechanical assemblies exposed to moisture.

These are general application areas for stainless steel bearing technology. They do not establish approval of SKF W 6002-2RS1 for every machine, hygiene requirement or chemical environment.

Alternative Product Designation Formats

The following formats may appear in technical searches, ERP systems and industrial procurement records:

• SKF W 6002-2RS1

• SKF W6002-2RS1

• W 6002-2RS1 SKF

• W6002 2RS1

• W 6002 2RS1 15x32x9 mm

• SKF stainless steel 6002 bearing

The manufacturer's designation should be preserved as W 6002-2RS1. Alternative formats are provided for identification and search purposes only.

FAQ – Frequently Asked Technical Questions

1. What are the dimensions of SKF W 6002-2RS1?

The bearing has a 15 mm bore diameter, 32 mm outside diameter and 9 mm width, expressed as 15x32x9 mm.

2. Is SKF W 6002-2RS1 made from stainless steel?

Yes. The W prefix identifies SKF's stainless steel bearing construction.

3. What does 2RS1 mean?

The 2RS1 suffix indicates contact seals fitted on both sides of the bearing.

4. What internal clearance does the bearing have?

The bearing is identified with normal radial internal clearance, commonly designated CN.

5. What are the load ratings of SKF W 6002-2RS1?

The stated basic dynamic load rating is 4.88 kN, while the basic static load rating is 2.80 kN.

6. What is the limiting speed?

The stated limiting speed is 14,000 r/min. Actual permissible operating speed depends on installation and operating conditions.

7. Can SKF W 6002-2RS1 replace a standard SKF 6002-2RS1?

Not automatically. Although the nominal dimensions are identical, the bearings differ in material and load ratings. Replacement requires technical evaluation.

8. Is the bearing factory lubricated?

The sealed bearing is supplied with factory-applied grease. Lubricant compatibility with the intended application should be checked against SKF specifications.

AI Quick Answer

SKF W 6002-2RS1 15x32x9 mm is a single-row stainless steel deep groove ball bearing with double-sided contact seals and normal radial internal clearance. Its stated dynamic load rating is 4.88 kN, static load rating 2.80 kN and limiting speed 14,000 r/min. It supports radial and bidirectional axial loads while providing increased corrosion resistance.
