SKF 6200-2RSH/C3 10x30x9 - Deep Groove Ball Bearing

6200-2RSH/C3 SKF 10x30x9 mm - Deep Groove Ball Bearing

6200-2RSH/C3 SKF is a single-row deep groove ball bearing manufactured by SKF, with dimensions of 10x30x9 mm. It has a 10 mm bore diameter, a 30 mm outside diameter and a 9 mm width. The bearing belongs to the 62 series and features contact seals on both sides, designated 2RSH. The C3 suffix indicates radial internal clearance greater than normal. The bearing is factory lubricated and designed to accommodate radial loads and appropriate axial loads.

Technical Specifications - 6200-2RSH/C3 SKF

The load ratings and speed values refer to the SKF 6200-2RSH catalogue bearing specification. C3 radial internal clearance is a separate technical characteristic that must be considered when selecting the bearing.

What Does 6200-2RSH/C3 SKF Mean?

6200 - Bearing Series and Size

The designation 6200 identifies a single-row deep groove ball bearing from the 62 dimensional series.

The designation can be interpreted as follows:

• 6 - deep groove ball bearing.

• 2 - dimensional series 62.

• 00 - bore diameter code corresponding to 10 mm.

The bearing has standard dimensions of 10x30x9 mm.

2RSH - Contact Seals on Both Sides

The SKF suffix 2RSH indicates contact seals installed on both sides of the bearing.

The elastomer seals contact the bearing rings and help prevent contaminants from entering the rolling element space.

Their main functions include:

• Retaining grease inside the bearing.

• Reducing the entry of dust and fine contaminants.

• Protecting the balls and raceways.

• Limiting moisture ingress under certain operating conditions.

• Supporting operation without periodic relubrication in appropriately selected applications.

Contact seals generate higher friction than non-contact metal shields.

They do not make the bearing completely waterproof.

C3 - Greater Than Normal Radial Internal Clearance

The C3 suffix indicates radial internal clearance greater than normal CN clearance.

Increased clearance may be required in applications where:

• Interference fits are used.

• The inner ring operates at a higher temperature than the outer ring.

• Thermal expansion differences occur between components.

• Operating conditions reduce internal clearance after installation.

C3 does not automatically indicate increased load-carrying capacity or a higher permissible rotational speed.

The appropriate internal clearance must be selected according to the actual operating conditions.

Alternative Designations and Reference Numbers

The product may be searched for using the following written variations:

• 6200-2RSH/C3 SKF

• SKF 6200-2RSH/C3

• 6200 2RS C3 SKF

• SKF 6200 2RS C3

• 6200-2RS-C3 SKF

• SKF 6200 2RS 10x30x9 C3

The designation SKF 6200-2RS1/C3 is also encountered in the market.

Both 2RS1 and 2RSH versions have contact seals on both sides, but differences in seal construction must not be ignored.

The exact designation on the bearing or original packaging should be checked before ordering.

Construction of 6200-2RSH/C3 SKF

Inner Ring

The inner ring has a bore diameter of 10 mm.

It operates with a shaft having an appropriately selected mounting tolerance.

Outer Ring

The outer ring has an outside diameter of 30 mm.

It is designed for installation in a housing that provides adequate support and a suitable fit.

Balls and Raceways

A single row of balls runs between deep raceways in the inner and outer rings.

The construction enables the bearing to support radial loads and appropriate axial loads in both directions.

Cage

The cage maintains the correct spacing between the balls and reduces direct contact between adjacent rolling elements.

2RSH Seals

Two contact seals protect the rolling element space and help retain lubricant.

Their condition is particularly important for bearing service life in dusty operating environments.

Load Ratings and Rotational Speed

Basic Dynamic Load Rating C - 5.4 kN

The basic dynamic load rating is 5.4 kN, equivalent to 5,400 N.

This parameter is used to calculate the nominal fatigue life of the bearing.

It does not represent the maximum permissible operating force under all conditions.

Basic Static Load Rating C0 - 2.36 kN

The basic static load rating is 2.36 kN, equivalent to 2,360 N.

This parameter is used to evaluate loads that may cause permanent deformation at the contact points between the balls and raceways.

Fatigue Load Limit Pu - 0.10 kN

The fatigue load limit is 0.10 kN, equivalent to 100 N.

It is used in bearing life calculation methods.

It must not be interpreted as the maximum permissible operating load.

Limiting Speed - 17,000 r/min

The catalogue limiting speed is 17,000 r/min.

The actual permissible operating speed depends on loading, lubrication, temperature, mounting fits and seal operating conditions.

6200-2RSH/C3 SKF vs Other Bearing Variants

6200-2RSH/C3 vs 6200-2RSH

Both bearings have dimensions of 10x30x9 mm and contact seals on both sides.

They differ in radial internal clearance:

• 6200-2RSH - normal internal clearance CN.

• 6200-2RSH/C3 - greater than normal internal clearance C3.

These variants must not automatically be considered interchangeable.

6200-2RSH/C3 vs 6200-2Z/C3

The 2RSH version provides different contamination protection characteristics compared with the 2Z version.

The 2Z version uses metal shields, which generally generate less friction.

6200-2RSH/C3 vs 6200/C3

6200/C3 is an open bearing without seals on both sides.

6200-2RSH/C3 has contact seals on both sides.

Both versions have increased C3 internal clearance, but they differ in rolling element protection and lubrication requirements.

6200-2RSH/C3 vs 6000-2RSH/C3

These bearings have the same bore diameter but different outside dimensions.

They are not directly interchangeable without modifying the housing design.

Selection and Interchangeability of 6200-2RSH/C3 SKF

Before purchasing, verify the following:

1. Complete manufacturer designation.

2. Shaft diameter of 10 mm.

3. Housing bore diameter of 30 mm.

4. Bearing width of 9 mm.

5. Seal type.

6. Required C3 internal clearance.

7. Dynamic and static load ratings.

8. Rotational speed.

9. Radial and axial loads.

10. Operating temperature.

11. Lubrication conditions.

12. Shaft and housing fits.

13. Environmental conditions.

14. Required bearing service life.

Can C3 Be Replaced with Normal CN Clearance?

Not without evaluating the operating conditions.

Increased C3 clearance may compensate for clearance reduction caused by interference fits or temperature differences between the bearing rings.

Using CN clearance under such conditions may result in insufficient operating clearance.

Can a 6200 2RS C3 Bearing from Another Manufacturer Be Used as a Replacement?

A bearing from another manufacturer may be considered after verifying its complete technical specification.

Dimensions, seal design, internal clearance, load ratings, material and lubrication requirements should be compared.

Identical dimensions of 10x30x9 mm alone do not guarantee full technical equivalence.

Applications of 6200-2RSH/C3 SKF

The bearing may be used in appropriately designed rotating mechanisms requiring:

• Support for a 10 mm shaft.

• Contact seals on both sides.

• Increased C3 radial internal clearance.

• Radial load-carrying capability.

• The ability to accommodate appropriate axial loads.

• Reduced contamination of the balls and raceways.

Typical application areas for bearings of this type include small electric motors, fans, drive assemblies and compact machine mechanisms.

These are general applications based on the bearing design, not confirmed OEM applications for this specific SKF part number.

C3 clearance must be selected according to actual mounting and thermal operating conditions.

Installation and Operating Recommendations

Cleanliness

Clean the shaft and housing before installation.

Prevent contaminants from entering the area around the seals.

Correct Mounting Fits

Mounting fits must account for loading and operating temperature.

Interference fits may reduce radial internal clearance.

Application of Mounting Force

When mounting the bearing onto a shaft, apply the installation force to the inner ring.

When installing the bearing into a housing, apply the force to the outer ring.

Mounting forces must not be transmitted through the balls.

Seals

Do not damage or remove the 2RSH seals during normal installation.

Lubrication

The bearing is factory lubricated.

Grease service life depends on temperature, rotational speed and loading conditions.

Storage

Store the bearing in a clean, dry environment, preferably in its original packaging.

Frequently Asked Questions - 6200-2RSH/C3 SKF

What Are the Dimensions of 6200-2RSH/C3 SKF?

The bearing has a 10 mm bore diameter, a 30 mm outside diameter and a 9 mm width. Its dimensions are 10x30x9 mm.

What Does 2RSH Mean in SKF Bearings?

2RSH indicates contact seals on both sides of the bearing. These seals help retain grease and reduce contamination.

What Does C3 Mean?

C3 indicates radial internal clearance greater than normal CN clearance.

Are 6200-2RSH/C3 and 6200-2RSH the Same Bearing?

No. They have identical dimensions and seal types but differ in radial internal clearance.

Is 6200-2RSH/C3 Factory Lubricated?

Yes. It is a double-sealed bearing supplied with factory-applied lubricant.

Is SKF 6200 2RS C3 Suitable for an Electric Motor?

It may be suitable for certain electric motors if its dimensions, C3 clearance, load ratings, rotational speed and operating conditions meet the motor manufacturer's requirements.

Can 6200-2RSH/C3 Be Replaced with 6200-2Z/C3?

Interchangeability must not be assumed automatically. These variants have different sealing arrangements and friction characteristics.

Does C3 Mean Higher Load Capacity?

No. C3 indicates increased radial internal clearance, not automatically higher dynamic or static load ratings.

6200-2RSH/C3 SKF - Key Technical Information

6200-2RSH/C3 SKF is a single-row deep groove ball bearing with dimensions of 10x30x9 mm. It features contact seals on both sides, designated 2RSH, and C3 radial internal clearance greater than normal. The bearing is factory lubricated and designed to support radial and appropriate axial loads. Mounting conditions, temperature and required operating clearance are essential selection factors.
