SKF W 6200-2RS1 10x30x9 - Stainless Steel Deep Groove Ball Bearing

W 6200-2RS1 SKF 10x30x9 mm - Stainless Steel Deep Groove Ball Bearing

W 6200-2RS1 SKF is a single-row stainless steel deep groove ball bearing manufactured by SKF, with dimensions of 10x30x9 mm. It has a 10 mm bore diameter, a 30 mm outside diameter and a 9 mm width. The bearing belongs to the 6200 series and features contact seals on both sides, designated 2RS1. The W prefix identifies stainless steel construction. The bearing has normal radial internal clearance and is factory lubricated.

Technical Specifications - W 6200-2RS1 SKF

The specified parameters refer to the catalogue version of SKF W 6200-2RS1. Permissible operating conditions must be evaluated according to loading, temperature, lubrication and equipment design.

What Does W 6200-2RS1 SKF Mean?

W - Stainless Steel Construction

The W prefix in SKF nomenclature identifies a stainless steel deep groove ball bearing.

Compared with conventional bearing steel, stainless steel provides improved corrosion resistance under certain environmental conditions.

This can be important in equipment exposed to occasional moisture or applications requiring components with greater corrosion resistance.

However, stainless steel does not provide complete resistance to water, salt, acids or aggressive chemicals.

6200 - Single-Row Deep Groove Ball Bearing

The designation 6200 identifies a deep groove ball bearing from the 62 series, with dimensions of 10x30x9 mm.

Its construction consists of a single row of balls positioned between deep raceways in the inner and outer rings.

This arrangement allows the bearing to support radial loads and appropriate axial loads in both directions.

2RS1 - Contact Seals on Both Sides

The SKF suffix 2RS1 identifies contact seals installed on both sides of the bearing.

Their functions include:

• Reducing the entry of dust and fine contaminants.

• Protecting the balls and raceways.

• Retaining lubricant inside the bearing.

• Reducing the risk of premature wear caused by contamination.

• Supporting operation without an external relubrication system under suitable conditions.

Contact seals generate additional friction compared with open bearings or bearings fitted with non-contact metal shields.

They do not provide complete waterproofing.

CN - Normal Radial Internal Clearance

The standard W 6200-2RS1 version has normal radial internal clearance.

Internal clearance affects the operating conditions of the balls and raceways after installation.

Actual operating clearance depends on several factors, including:

• Shaft fit.

• Housing fit.

• Operating temperature.

• Temperature differences between the bearing rings.

• Applied loads.

A bearing with normal clearance must not automatically be considered interchangeable with a C3 clearance version.

Alternative Designations and Reference Numbers

The product may also be searched for using the following variations:

• W 6200-2RS1 SKF

• SKF W 6200-2RS1

• W6200-2RS1

• W 6200 2RS SKF

• SKF W 6200 2RS

• W 6200-2RS1 10x30x9

• SKF 6200 2RS stainless steel bearing

The designation W 6200 2RS is a shortened commercial reference. For technical orders, the complete designation W 6200-2RS1 SKF is recommended.

This product must not automatically be considered identical to W 6200-2RS1/VP311, which has an additional specification relating to lubrication and food industry applications.

Construction of W 6200-2RS1 SKF

Single-Row Deep Groove Construction

The bearing consists of an inner ring, outer ring, balls, cage and two seals.

The deep raceways guide the rolling elements and enable the bearing to accommodate radial loads and appropriate axial loads.

Inner Ring - 10 mm Bore

The nominal bore diameter is 10 mm.

The inner ring is designed to operate with a shaft having an appropriately selected tolerance.

Incorrect mounting fits may alter the operating clearance or cause unwanted movement of the ring on the shaft.

Outer Ring - 30 mm Outside Diameter

The outside diameter is 30 mm.

The outer ring must be installed in a housing that provides adequate support and a suitable fit.

Bearing Width - 9 mm

The bearing width is 9 mm.

This dimension must be considered when designing supporting shoulders, spacers and locating components.

Steel Cage

The cage maintains the correct spacing between the balls and reduces direct contact between adjacent rolling elements during operation.

Contact Seals on Both Sides

The 2RS1 seals separate the rolling element space from the surrounding environment.

They are particularly relevant in mechanisms where bearing access is limited or lubricant retention is required.

Load Ratings and Rotational Speed

Basic Dynamic Load Rating C - 4.36 kN

The basic dynamic load rating is 4.36 kN, equivalent to 4,360 N.

This parameter is used in bearing fatigue life calculations.

It does not represent the maximum permissible operating force under all conditions.

Basic Static Load Rating C0 - 2.32 kN

The basic static load rating is 2.32 kN, equivalent to 2,320 N.

It is used to evaluate loads that may cause permanent deformation at the contact points between the balls and raceways.

Fatigue Load Limit Pu - 0.10 kN

The catalogue fatigue load limit is 0.10 kN, equivalent to 100 N.

This parameter is used in bearing life calculation methods.

It must not be interpreted as the maximum permissible bearing load.

Limiting Speed - 16,000 r/min

The catalogue limiting speed is 16,000 r/min.

This value does not mean that the bearing can operate at this speed regardless of operating conditions.

The actual permissible rotational speed depends on temperature, loading, lubrication, mounting fits and cooling conditions.

W 6200-2RS1 SKF vs Other Bearing Variants

W 6200-2RS1 vs SKF 6200-2RSH

Both bearings have dimensions of 10x30x9 mm and contact seals on both sides.

The main difference concerns the bearing material.

W 6200-2RS1 is manufactured from stainless steel, while the standard 6200-2RSH belongs to the conventional bearing steel product range.

The bearings may also differ in load ratings and sealing characteristics.

Identical dimensions do not guarantee full interchangeability.

W 6200-2RS1 vs SKF W 6200-2Z

The 2RS1 version uses contact seals that help retain grease and limit the entry of contaminants.

The 2Z version has metal shields and different friction and contamination protection characteristics.

W 6200-2RS1 vs SKF W 6200

W 6200 is an open bearing without seals on both sides.

W 6200-2RS1 has contact seals on both sides.

Both variants have the same principal dimensions but differ in rolling element protection and lubrication requirements.

W 6200-2RS1 vs W 6200-2RS1/VP311

The VP311 variant belongs to SKF's specialized product offering for certain food industry applications.

The additional designation identifies a special version with specific sealing and lubrication requirements.

The standard W 6200-2RS1 must not be assumed to have the same grease specification or food industry approvals.

Selection and Interchangeability of W 6200-2RS1 SKF

Before purchasing, verify the following:

1. Complete designation W 6200-2RS1.

2. Stainless steel construction.

3. Shaft diameter of 10 mm.

4. Housing bore diameter of 30 mm.

5. Bearing width of 9 mm.

6. Contact seals on both sides, designated 2RS1.

7. Normal radial internal clearance.

8. Dynamic and static load ratings.

9. Required rotational speed.

10. Lubrication conditions.

11. Operating temperature.

12. Radial and axial loading conditions.

13. Environmental conditions.

14. Corrosion resistance requirements.

15. Required bearing service life.

Can a Standard 6200 2RS Replace W 6200-2RS1?

Interchangeability must not be assumed automatically.

A standard 6200 2RS bearing may have identical dimensions but different material properties and operating characteristics.

If the equipment requires stainless steel construction, that requirement must be maintained.

Can a Bearing from Another Manufacturer Be Used as a Replacement?

A bearing from another manufacturer may be considered after confirming its dimensions, material, seals, internal clearance, load ratings and other technical requirements.

Matching dimensions of 10x30x9 mm alone do not establish full technical equivalence.

Applications of W 6200-2RS1 SKF

The bearing may be used in appropriately designed mechanisms requiring support for a 10 mm shaft, contact seals on both sides and stainless steel construction.

Potential application areas include:

• Compact rotating assemblies.

• Electromechanical equipment.

• Small drive mechanisms.

• Selected mechanisms operating in humid environments.

• Equipment requiring components with improved corrosion resistance.

• Assemblies with limited access for relubrication.

These are general applications based on the bearing construction, not confirmed OEM applications for specific equipment models.

For food processing applications or installations requiring particular approvals, the grease, seals and complete assembly requirements must be checked separately.

Installation and Operating Recommendations

Surface Preparation

Before installation, inspect the shaft and housing.

The mounting surfaces should be clean and free from burrs, corrosion and mechanical damage.

Correct Mounting Fits

Mounting fits should account for loading, temperature and the required operating internal clearance.

Excessive interference may reduce internal clearance and increase rotational resistance.

Correct Application of Mounting Force

When installing the bearing onto a shaft, apply the mounting force to the inner ring.

When installing the bearing into a housing, apply the mounting force to the outer ring.

Mounting forces must never be transmitted through the balls.

Protecting the Seals

The 2RS1 seals must not be damaged or removed during normal installation.

Damaged seals may allow grease leakage and the entry of contaminants.

Storage

Store the bearing in a clean, dry environment, in packaging that protects it against moisture and mechanical damage.

Frequently Asked Questions - W 6200-2RS1 SKF

What Are the Dimensions of W 6200-2RS1 SKF?

The bearing has a 10 mm bore diameter, a 30 mm outside diameter and a 9 mm width. Its dimensions are 10x30x9 mm.

Is W 6200-2RS1 SKF Made of Stainless Steel?

Yes. The W prefix identifies stainless steel construction.

What Does 2RS1 Mean?

The SKF suffix 2RS1 indicates contact seals installed on both sides of the bearing.

Is W 6200-2RS1 Factory Lubricated?

Yes. This double-sealed bearing version is supplied with factory-applied lubricant.

What Internal Clearance Does W 6200-2RS1 SKF Have?

The standard version has normal radial internal clearance, designated CN.

What Are the Load Ratings of W 6200-2RS1?

The basic dynamic load rating is 4.36 kN, and the basic static load rating is 2.32 kN.

Is W 6200-2RS1 Waterproof?

No. The seals help reduce the entry of contaminants and moisture, while stainless steel provides improved corrosion resistance under certain conditions. However, the bearing is not completely waterproof.

Are W 6200-2RS1 and 6200-2RSH the Same Bearing?

No. They have identical nominal dimensions but differ in material construction and may have different operating characteristics.

W 6200-2RS1 SKF - Key Technical Information

W 6200-2RS1 SKF is a single-row stainless steel deep groove ball bearing with dimensions of 10x30x9 mm. It belongs to the 6200 series and features contact seals on both sides, designated 2RS1, and normal radial internal clearance. The bearing is factory lubricated and supports radial and appropriate axial loads. Its distinguishing feature is stainless steel construction.
