6222 CT 110x200x38 mm - Single-Row Deep Groove Ball Bearing

6222 CT 110x200x38 mm - Single-Row Deep Groove Ball Bearing

6222 CT is a single-row deep groove ball bearing with dimensions 110x200x38 mm. It has a 110 mm bore diameter, 200 mm outside diameter and 38 mm width. The 6222 dimensional series is widely used for rotating shafts requiring radial load support combined with the ability to accommodate axial loads in both directions.

6222 CT - Technical Data

Dimensions

6222 CT: 110x200x38 mm

• d: 110 mm

• D: 200 mm

• B: 38 mm

These dimensions correspond to the standard 6222 deep groove ball bearing dimensional series.

6222 Deep Groove Ball Bearing Design

The 6222 belongs to the family of single-row deep groove ball bearings.

Deep groove ball bearings have deep, continuous raceway grooves with close conformity between the raceways and balls. This design makes them suitable primarily for radial loads while also allowing axial loads to be carried in both directions.

The single-row construction provides a compact and versatile bearing arrangement for rotating machinery.

Radial and Axial Loads

A 6222 deep groove ball bearing is primarily designed to support radial loads.

Due to its raceway geometry, it can also accommodate axial loads acting in either direction.

This combination makes the 6222 series suitable for bearing arrangements where both radial forces and moderate axial forces may occur.

Actual permissible loads depend on the exact manufacturer and bearing execution.

What Does 6222 Mean?

The designation 6222 identifies the bearing's dimensional series and bore size.

For this bearing:

• bearing designation: 6222

• bore diameter: 110 mm

• outside diameter: 200 mm

• width: 38 mm

The additional CT marking should be retained as part of the complete product identification:

6222 CT

It should not be interpreted as a universal bearing suffix without documentation from the specific manufacturer.

Why the CT Suffix Matters

The complete designation of the offered bearing is:

6222 CT

Suffix systems are not always identical between bearing manufacturers.

For this reason, CT should not automatically be treated as equivalent to standard suffixes such as:

• Z

• 2Z

• RS

• 2RS

• RSR

• 2RSR

• C3

When replacing an existing 6222 CT bearing, compare the complete designation and physical execution of the original bearing.

6222 CT vs 6222

Both designations share the same basic dimensional series:

110x200x38 mm

However, the additional CT marking may identify a specific manufacturer execution.

Therefore, dimensional compatibility alone should not be used to confirm complete interchangeability.

Before replacement, verify:

• complete bearing designation

• bearing construction

• closure or seal arrangement, if present

• internal clearance, if specified

• required operating conditions

• original bearing markings

6222 CT vs 6222 2RS

A 6222 2RS bearing generally identifies a 6222 bearing equipped with seals on both sides.

The designation 6222 CT should not automatically be interpreted as equivalent to 6222 2RS.

Although both may have the same principal dimensions of 110x200x38 mm, the exact bearing execution must be verified before substitution.

6222 CT vs 6222 2Z

A 6222 2Z bearing generally identifies a deep groove ball bearing with shields on both sides.

The designation 6222 CT is not automatically equivalent to 6222 2Z.

The same dimensions do not guarantee identical sealing, shielding, lubrication or operating characteristics.

Selection and Interchangeability

Before replacing a 6222 CT bearing, verify:

1. Designation 6222 CT.

2. Bore diameter 110 mm.

3. Outside diameter 200 mm.

4. Width 38 mm.

5. Bearing type - single-row deep groove ball bearing.

6. Exact closure or sealing arrangement.

7. Internal clearance, if specified.

8. Manufacturer-specific suffix meaning.

9. Operating conditions of the bearing arrangement.

A standard 6222 bearing should not automatically be considered a direct replacement for a 6222 CT solely because the dimensions are identical.

Typical Engineering Applications

The 6222 dimensional series is suitable for bearing arrangements using a 110 mm shaft and 200 mm housing bore.

Deep groove ball bearings of this size can be encountered in industrial rotating equipment, electric machinery, drive systems and general mechanical engineering.

The suitability of 6222 CT for a particular machine should always be determined from the original bearing designation and technical requirements of the bearing position.

Installation

Before installing a 6222 CT bearing:

• verify the shaft and housing dimensions

• inspect the shaft and housing seats

• remove contamination and burrs

• keep the bearing clean

• apply installation force only through the ring being fitted

• never transmit mounting force through the rolling elements

• use suitable bearing mounting tools

• verify the required fit and operating clearance

Correct installation is essential for bearing service life and reliable operation.

FAQ

What are the dimensions of the 6222 CT bearing?

The 6222 CT bearing has dimensions of 110x200x38 mm: 110 mm bore diameter, 200 mm outside diameter and 38 mm width.

What type of bearing is 6222 CT?

6222 CT is based on the 6222 single-row deep groove ball bearing dimensional series.

What is the bore diameter of 6222 CT?

The bore diameter is 110 mm.

What is the outside diameter of 6222 CT?

The outside diameter is 200 mm.

What is the width of 6222 CT?

The bearing width is 38 mm.

Can a 6222 bearing carry axial load?

A single-row deep groove ball bearing is primarily designed for radial loads but can also accommodate axial loads in both directions.

Is 6222 CT the same as 6222 2RS?

This should not be assumed. The dimensions may be identical, but CT and 2RS are different suffix designations. The exact construction must be verified before replacement.

Is 6222 CT the same as 6222 2Z?

Not automatically. A 6222 2Z designation specifies shields on both sides, while the exact meaning of CT depends on the manufacturer-specific designation system.

Can another 110x200x38 mm bearing replace 6222 CT?

Dimensions alone are not sufficient to establish interchangeability. The bearing type, complete designation, closure arrangement, internal clearance and operating requirements should also be checked.

6222 CT - Quick Technical Answer

6222 CT is a single-row deep groove ball bearing with dimensions 110x200x38 mm. It has a 110 mm bore, 200 mm outside diameter and 38 mm width. The 6222 series supports radial loads and axial loads in both directions. The CT suffix should be verified against the specific manufacturer's designation system before selecting an equivalent.

6222 CT at simmering.pl

6222 CT 110x200x38 mm is available from simmering.pl, a specialist supplier of bearings, radial shaft seals, O-rings and industrial sealing solutions.

Stock and technical service are located in Lublin, Poland.

For B2B enquiries and bearing identification, specify the complete designation:

6222 CT - 110x200x38 mm
