3206 2RS MTM (Sealed Double-Row Angular Contact Bearing)

Applications & Specifications

Advantages & Design Features

Main Description

The 3206 2RS MTM is a sealed, double-row angular contact ball bearing designed for industrial and mechanical applications requiring robust sealing and reliable performance. The “2RS” suffix indicates rubber seals on both sides, providing protection against dust and contaminants while retaining lubrication inside the bearing. The “MTM” designation often identifies a specific manufacturing series or tolerance class used by your supply line.

Technical Specifications

Typical dimensions for a 3206 2RS bearing are 30 mm inner diameter (d) x 62 mm outer diameter (D) x 23.8 mm width (B). The double-row angular contact design allows this bearing to support combined radial and axial loads in both directions without needing paired single-row bearings.

Its sealed 2RS design ensures reliable operation in environments where dirt, moisture, or airborne particles may threaten open bearings. These seals help maintain lubricant integrity, reduce maintenance needs, and extend service life.

Applications & Use Cases

Common uses for the 3206 2RS MTM include:

• Gearboxes, transmissions, and reducer units

• Pumps, compressors, and fluid handling systems

• Industrial machinery, conveyors, rotating equipment

• Electric motors, spindles, and drive assemblies

• Environments where moderate protection from contaminants is needed

Because of its capacity to handle radial and axial loads, this bearing is often chosen for assemblies with combined loading conditions, minimizing the need for multiple bearing types.

Advantages & Design Features

• Double rubber seals (2RS) protect internal components from contaminants

• Double-row angular contact geometry handles combined loads in both directions

• Compact full solution — eliminates the need to assemble two single-row angular bearings

• Reduced maintenance thanks to sealed design retaining lubricant

• Lower friction and smooth operation at moderate speeds

• Versatile and reliable in many industrial, agrarian, or utility systems

Searchers globally often use phrases like “3206 2RS bearing”, “3206 2RS MTM”, “sealed angular contact bearing 3206”, “30x62x23.8 sealed bearing”, “double row angular contact 3206 2RS”. By naturally including these variants, the description aligns well with typical online queries without keyword stuffing.

To emphasize the logistics advantage, we note that this product is stocked locally: Warehouse & Store: Lublin, ul. Smoluchowskiego 1, building 4 with 24h dispatch - fast and efficient order processing. This local detail can help improve click-through among users in Poland and neighboring regions.

This description avoids regurgitating standard catalog text, instead focusing on functional benefits, contexts, and decision factors. It aims to stand out among generic listings by clarity and domain relevance.

FAQ

Q1: Will this 3206 2RS MTM fit my shaft and housing?
A1: Yes — if your shaft diameter is about 30 mm, your housing bore about 62 mm, and you can accommodate the 23.8 mm width, this bearing should work. Confirm tolerances before installation.

Q2: What does “2RS” mean, and how does it differ from “ZZ”?
A2: “2RS” indicates rubber seals on both sides, which provide contact sealing against dust and contaminants. “ZZ” is used for metal shields, which are non-contact and offer less protection but lower friction.

Q3: What loads and speeds can this bearing handle?
A3: The 3206 double-row angular contact bearing supports both radial and axial loads (in both directions). Its sealed design may limit air cooling slightly, so speed limits depend on lubrication, load, and thermal conditions.

Q4: Is this bearing suitable for dusty or corrosive environments?
A4: Yes, the 2RS rub­ber seals help guard against ingress of dust and debris. For especially harsh or corrosive environments, consider stainless or hybrid variants.

Q5: How quickly can I receive this bearing?
A5: We stock the 3206 2RS MTM in Lublin, at Warehouse & Store: ul. Smoluchowskiego 1, building 4. With 24h dispatch - fast and efficient order processing, many orders arrive the next business day.
