SKF W 6007-2RS1 35x62x14 mm - Stainless Steel Bearing

W 6007-2RS1 SKF 35x62x14 mm - Stainless Steel Single Row Deep Groove Ball Bearing

SKF W 6007-2RS1 is a stainless steel single row deep groove ball bearing measuring 35x62x14 mm. It belongs to the SKF W 6000 stainless steel bearing series and features two RS1 contact seals, normal radial internal clearance and factory grease lubrication. Its deep raceway grooves enable it to accommodate radial loads and axial loads in both directions. The prefix W distinguishes this corrosion-resistant execution from the standard SKF 6007-2RS1 bearing manufactured from conventional bearing steel.

Technical Specifications - SKF W 6007-2RS1

These specifications refer specifically to the stainless steel SKF W 6007-2RS1 execution, not the standard SKF 6007-2RS1 bearing manufactured from conventional bearing steel.

A reference speed is not specified for this sealed execution.

What Does SKF W 6007-2RS1 Mean?

W - Stainless Steel Bearing

The prefix W identifies a stainless steel bearing in SKF's designation system.

This is the most important distinction between SKF W 6007-2RS1 and the standard SKF 6007-2RS1.

Stainless steel provides improved corrosion resistance compared with conventional bearing steel.

However, stainless steel does not guarantee complete resistance to all chemicals, chlorides, seawater or aggressive cleaning agents.

Actual corrosion resistance depends on the operating environment, temperature, exposure duration and maintenance conditions.

6007 - Bearing Series and Dimensions

The designation 6007 identifies a single row deep groove ball bearing from the 6000 dimensional series.

The bore code 07 corresponds to a nominal bore diameter of 35 mm.

Its boundary dimensions are:

• Bore diameter: 35 mm.

• Outside diameter: 62 mm.

• Width: 14 mm.

2RS1 - Two Contact Seals

The suffix 2RS1 indicates two RS1 contact seals, one fitted on each side of the bearing.

The seals help:

• Reduce the entry of contaminants.

• Retain lubricant inside the bearing.

• Protect the raceways and rolling elements.

• Reduce the need for external relubrication under normal operating conditions.

Unlike non-contact metal shields, RS1 contact seals operate in contact with the mating ring surface.

This affects friction and permissible rotational speed.

Normal Radial Internal Clearance

The standard SKF W 6007-2RS1 execution has normal radial internal clearance.

It must not be confused with a C3 execution, which has increased radial internal clearance.

Alternative Designations and Search References

Common written variations include:

• SKF W 6007-2RS1

• W6007-2RS1 SKF

• SKF W6007 2RS1

• W 6007 2RS1

• SKF W6007-2RS1 35x62x14

• SKF 6007 2RS1 stainless steel bearing

The complete designation W 6007-2RS1 should be preserved when ordering.

Omitting the W prefix may result in selecting a bearing manufactured from a different material.

Construction of SKF W 6007-2RS1

SKF W 6007-2RS1 consists of an inner ring, an outer ring, a single row of balls, a cage and two contact seals.

Its deep raceway grooves enable the bearing to accommodate radial loads and axial loads acting in both directions.

The bearing is factory lubricated with grease, which is retained by the RS1 contact seals.

Under normal operating conditions, an external lubrication system is not required.

However, sealed construction does not mean unlimited grease service life.

Lubricant performance changes with operating temperature, loading, rotational speed and time.

The bearing's service life must therefore be evaluated according to the complete operating conditions.

Corrosion Resistance - Why Choose a Stainless Steel Bearing?

SKF W 6007-2RS1 is intended for consideration in bearing arrangements where conventional bearing steel may be exposed to corrosion.

Potential operating environments include:

• Machinery exposed to elevated humidity.

• Equipment subject to occasional water exposure.

• Industrial installations requiring improved material corrosion resistance.

• Rotating mechanisms operating in environments where conventional bearing steel requires additional corrosion protection.

Stainless Steel vs Conventional Bearing Steel

Standard bearing steel provides mechanical properties suitable for many industrial applications but requires effective corrosion protection.

Stainless steel bearings provide greater resistance to certain corrosive environments.

However, stainless steel is not automatically suitable for every food-processing, pharmaceutical or chemical application.

Such applications may also require verification of:

• Lubricant suitability.

• Seal material compatibility.

• Chemical resistance.

• Cleaning procedures.

• Applicable hygiene requirements.

• Potential contact with processed products.

The bearing's stainless steel construction alone does not establish food-contact approval or compliance with a specific hygiene standard.

SKF W 6007-2RS1 Load Ratings

Basic Dynamic Load Rating C - 13.8 kN

The basic dynamic load rating is used to calculate rolling bearing fatigue life under dynamic loading conditions.

It is not an unconditional maximum permissible operating load.

Actual bearing life depends on equivalent dynamic load, lubrication conditions, operating temperature and contamination.

Basic Static Load Rating C0 - 10.2 kN

The basic static load rating is used to assess the risk of permanent deformation at the rolling element and raceway contacts.

It is relevant for stationary bearings, slow rotation and applications involving high static loads.

Fatigue Load Limit Pu - 0.44 kN

The fatigue load limit is used in SKF bearing life calculation methods.

It must not be interpreted as the maximum permissible load acting on the bearing.

Limiting Speed - 6,700 rpm

SKF specifies a limiting speed of 6,700 rpm for W 6007-2RS1.

This value reflects restrictions associated with the bearing design, including its contact seals.

The actual permissible operating speed depends on:

• Bearing load.

• Operating temperature.

• Lubricant properties.

• Shaft and housing fits.

• Heat dissipation.

• Operating environment.

The limiting speed of the open W 6007 bearing or the shielded W 6007-2Z execution must not automatically be applied to W 6007-2RS1.

SKF W 6007-2RS1 vs Other Stainless Steel Variants

All three executions have the same boundary dimensions of 35x62x14 mm.

However, their protective arrangements, lubrication requirements and limiting speeds differ.

SKF W 6007-2RS1 vs SKF 6007-2RS1

The primary difference is the bearing material.

SKF W 6007-2RS1 is manufactured from stainless steel.

SKF 6007-2RS1 is the conventional bearing steel execution.

Although their boundary dimensions are identical, the bearings may have different load ratings, corrosion resistance and operating characteristics.

They should not be considered automatically interchangeable.

SKF W 6007-2RS1 vs SKF W 6007-2Z

SKF W 6007-2RS1 incorporates two contact seals, while SKF W 6007-2Z has two metal shields.

The non-contact shield design generates less sealing friction but provides a different level of contamination protection.

Selection depends on rotational speed, humidity, contamination exposure and lubrication requirements.

SKF W 6007-2RS1 vs SKF W 6007-2RS1/VP311

SKF also offers the W 6007-2RS1/VP311 execution.

The VP311 variant is associated with specific food-industry requirements, including distinctive blue seals.

The properties and application-specific characteristics of the VP311 execution must not automatically be attributed to the standard W 6007-2RS1 bearing.

Bearing Selection and Interchangeability

Before ordering SKF W 6007-2RS1, verify:

• Complete SKF designation W 6007-2RS1.

• Stainless steel construction.

• Bore diameter of 35 mm.

• Outside diameter of 62 mm.

• Bearing width of 14 mm.

• Two RS1 contact seals.

• Required radial internal clearance.

• Radial and axial operating loads.

• Rotational speed.

• Operating temperature.

• Shaft and housing fits.

• Corrosive substances present in the operating environment.

• Lubricant and seal compatibility.

• Hygiene or food-contact requirements, where applicable.

Identical boundary dimensions do not guarantee complete technical interchangeability.

A conventional bearing steel version or a stainless steel bearing from another manufacturer may have different load ratings, sealing arrangements or operating characteristics.

Applications of SKF W 6007-2RS1

SKF W 6007-2RS1 can be considered for machinery and equipment operating in environments where improved corrosion resistance is required compared with conventional bearing steel.

Potential application categories include:

• Industrial production equipment.

• Conveyor and material-handling mechanisms.

• Rotating shaft assemblies exposed to humidity.

• Machinery requiring sealed stainless steel bearings.

• Equipment operating in environments where corrosion protection is an important design consideration.

For food-processing or pharmaceutical applications, additional verification of lubricant suitability, sealing materials and applicable hygiene requirements may be necessary.

Specific machine models or OEM applications should not be attributed to SKF W 6007-2RS1 without supporting manufacturer documentation.

Installation and Operating Recommendations

Preparation Before Installation

Inspect and clean the shaft, housing and mating surfaces.

Contamination or damage to the mounting surfaces can affect bearing seating and operating performance.

Correct Mounting Force

When mounting the bearing onto a shaft, apply mounting force to the inner ring.

When pressing the bearing into a housing, apply force to the outer ring.

Never transmit mounting force through the balls.

Protection of RS1 Contact Seals

Protect the contact seals against mechanical damage during installation.

Do not remove the seals unless specifically required by an approved maintenance procedure.

Lubrication

SKF W 6007-2RS1 is supplied with factory-applied grease.

The standard sealed execution is not intended for routine relubrication.

Storage

Store the bearing in its original packaging in a clean, dry environment.

Protect it against contamination, moisture and mechanical damage.

Frequently Asked Questions - SKF W 6007-2RS1

What are the dimensions of SKF W 6007-2RS1?

The bearing has a 35 mm bore diameter, 62 mm outside diameter and 14 mm width. Its dimensions are 35x62x14 mm.

What does the W prefix mean in SKF bearing designations?

The W prefix identifies the stainless steel execution. This distinguishes the bearing from the standard SKF 6007-2RS1 manufactured from conventional bearing steel.

What does 2RS1 mean?

The suffix 2RS1 indicates two contact seals, fitted on both sides of the bearing.

Is SKF W 6007-2RS1 corrosion resistant?

Yes. Its stainless steel construction provides improved corrosion resistance compared with conventional bearing steel. However, resistance depends on the specific environment and substances involved.

What is the load rating of SKF W 6007-2RS1?

The basic dynamic load rating is 13.8 kN, and the basic static load rating is 10.2 kN.

What is the maximum rotational speed of SKF W 6007-2RS1?

The SKF catalogue limiting speed is 6,700 rpm. Actual permissible operating speed must be determined according to the operating conditions.

Is SKF W 6007-2RS1 factory lubricated?

Yes. The bearing is supplied with factory-applied grease, and its two contact seals help retain the lubricant.

Can SKF 6007-2RS1 be replaced with SKF W 6007-2RS1?

Not automatically. Both bearings have the same dimensions, but their materials and technical performance may differ. The replacement must be checked against the application's requirements.

SKF W 6007-2RS1 - Key Technical Information

SKF W 6007-2RS1 is a stainless steel single row deep groove ball bearing measuring 35x62x14 mm, equipped with two RS1 contact seals and factory grease lubrication. Its basic dynamic load rating is 13.8 kN, static load rating 10.2 kN and limiting speed 6,700 rpm. Stainless steel construction improves corrosion resistance but does not guarantee compatibility with every chemical environment.
