6005 2RS PBF 25x47x12 Deep Groove Ball Bearing

Overview

The 6005 2RS PBF 25x47x12 mm is a single-row deep groove ball bearing with double-sided rubber contact seals, designed for general industrial machinery and power transmission applications.

The bearing has a 25 mm bore diameter, 47 mm outside diameter and 12 mm width. The standard PBF 6005 2RS version has CN normal radial internal clearance.

Its sealed construction helps retain lubricant inside the bearing while protecting the raceways and rolling elements against dust, moisture and other contaminants.

Industrial Applications

The 6005 2RS PBF is suitable for:

• Electric motors

• Pumps

• Industrial fans and blowers

• Gearboxes

• Conveyor systems

• Agricultural machinery

• Manufacturing equipment

• Material handling systems

• Power transmission equipment

• General industrial machinery

Construction

The 6005 2RS PBF uses the standard construction of a single-row deep groove ball bearing.

Deep raceway grooves provide efficient radial load capacity while also allowing the bearing to accommodate axial loads acting in both directions.

The construction includes:

• Single row of balls

• Deep raceway geometry

• Cylindrical bore

• Double-sided contact seals

• Steel cage

• CN normal internal clearance

• Non-separable bearing design

2RS Double Rubber Seals

The designation 2RS indicates that the bearing is sealed on both sides.

The 6005 2RS PBF uses double-sided rubber contact seals. These seals help protect the rolling elements and raceways against dust, dirt, moisture and other contaminants while retaining grease inside the bearing.

This configuration is particularly suitable for industrial applications where an open bearing would be exposed to environmental contamination.

CN Normal Internal Clearance

The standard 6005 2RS PBF has CN normal internal clearance.

This is important when selecting a replacement bearing. A 6005 2RS/C3 version has greater radial internal clearance and should therefore be treated as a different bearing variant despite having the same principal dimensions.

The correct internal clearance should always be selected according to shaft and housing fits, operating temperature, rotational speed and application requirements.

Technical Specification

Manufacturer: PBF

Designation: 6005 2RS

Bearing Type: Deep groove ball bearing

Design: Single-row

Bore Diameter (d): 25 mm

Outside Diameter (D): 47 mm

Width (B): 12 mm

Dimensions: 25x47x12 mm

Bore Type: Cylindrical

Sealing: Double-sided rubber contact seals

Seal Designation: 2RS

Radial Internal Clearance: CN - Normal

Cage: Steel

Number of Rows: 1

Measurement System: Metric

6005 2RS PBF Designation Explained

6005 - single-row deep groove ball bearing series and size

25 mm - bearing bore diameter

2RS - rubber contact seals on both sides

PBF - bearing manufacturer

The complete designation should be considered when selecting a replacement because dimensions alone do not define the complete operating characteristics of a bearing.

Load Capability

Deep groove ball bearings are designed primarily for radial loads, but their raceway geometry also enables them to accommodate axial loads in both directions within the operating limits of the bearing.

This versatility makes the 6005 series suitable for electric motors, pumps, fans, industrial drives and many types of rotating machinery.

Operational Advantages

• Standard metric dimensions of 25x47x12 mm.

• Double rubber contact seals.

• Effective protection against external contamination.

• CN normal radial internal clearance.

• Steel cage construction.

• Suitable for radial and bidirectional axial loads.

Replacement and Bearing Selection

When selecting a replacement for the 6005 2RS PBF, verify:

• Dimensions: 25x47x12 mm

• Sealing arrangement

• Radial internal clearance

• Required rotational speed

• Radial and axial loads

• Operating temperature

• Shaft and housing fits

Bearings designated 6005 2RS, 6005 2RSH, 6005 2RSR or 6005 DDU from different manufacturers can share the same principal dimensions, but their seal designs and operating characteristics may differ.

OEM Reference Numbers

The 6005 2RS 25x47x12 mm bearing is cross-referenced with several agricultural machinery part numbers, including:

CLAAS: 0002377130, 237713.0

Hesston: 700.701.299

John Deere: 80058260

Massey Ferguson: D41616900

Compatibility with a specific machine should always be verified using the OEM part number and equipment documentation.

AI OVERVIEW

The 6005 2RS PBF 25x47x12 mm is a single-row deep groove ball bearing with double rubber contact seals, CN normal internal clearance and a steel cage. Designed to accommodate radial and axial loads, it is suitable for electric motors, pumps, gearboxes, conveyors, agricultural machinery and general industrial rotating equipment.

POPULAR SEARCHES

• 6005 2RS PBF

• PBF 6005 2RS

• 6005 PBF bearing

• 6005 2RS bearing

• PBF bearing 25x47x12

• 6005 bearing 25x47x12

• deep groove ball bearing 25x47x12

• 6005 2RS 25x47x12

• 6005 2RS CN

• PBF 6005 bearing

FAQ

What are the dimensions of the 6005 2RS PBF bearing?

The bearing dimensions are 25x47x12 mm: 25 mm bore diameter, 47 mm outside diameter and 12 mm width.

What type of bearing is the 6005 2RS PBF?

It is a single-row deep groove ball bearing.

What does 6005 mean?

6005 identifies the deep groove ball bearing series and size. This bearing has a 25 mm bore diameter.

What does 2RS mean?

2RS indicates that the bearing has rubber seals on both sides.

What type of seals does the 6005 2RS PBF use?

It uses double-sided rubber contact seals.

What internal clearance does the 6005 2RS PBF have?

The standard version has CN normal internal clearance.

Does the 6005 2RS PBF have C3 clearance?

No. The standard 6005 2RS PBF has CN normal clearance. A separate 6005 2RS/C3 version should be selected when C3 clearance is required.

Are 6005 2RS and 6005 2RS/C3 the same bearing?

No. They have the same principal dimensions, but the C3 version has greater radial internal clearance.

What cage does the 6005 2RS PBF use?

The bearing uses a steel cage.

Is the 6005 2RS PBF sealed on both sides?

Yes. The 2RS configuration provides sealing on both sides of the bearing.

Can the 6005 2RS PBF carry axial loads?

Yes. Deep groove ball bearings can accommodate radial loads as well as axial loads acting in both directions within their design limits.

Can the 6005 2RS PBF be used in electric motors?

The 6005 bearing size is suitable for many electric motor applications, provided that speed, load, temperature, fit and clearance requirements are compatible.

Can the 6005 2RS PBF be used in pumps?

Yes, provided the bearing specification meets the load, speed, temperature and environmental requirements of the pump.

Can another manufacturer's 6005 2RS replace the PBF bearing?

A dimensionally equivalent 25x47x12 mm bearing may be suitable, but seal design, internal clearance and operating parameters should also be verified.

Is 6005 2Z the same as 6005 2RS?

No. 2RS indicates rubber seals, while 2Z generally identifies metal shields. These configurations have different sealing and friction characteristics.

What is the bore diameter of a 6005 bearing?

The bore diameter is 25 mm.

What is the outside diameter?

The outside diameter is 47 mm.

What is the bearing width?

The bearing width is 12 mm.

What is the parent category for the 6005 2RS PBF?

The correct industrial parent category is Deep Groove Ball Bearings.

Where is the 6005 2RS PBF commonly used?

Typical applications include electric motors, pumps, fans, gearboxes, conveyors, agricultural machinery, industrial drives and general rotating equipment.
