6207 2RS C4 SKF 35x72x17 Deep Groove Ball Bearing

Overview

SKF 6207 2RS C4 is a single-row deep groove ball bearing with a 35 mm bore, 72 mm outside diameter and 17 mm width. It features seals on both sides and C4 radial internal clearance. The sealed construction helps retain lubricant and protect the rolling elements from contamination, while C4 provides greater internal clearance than both Normal and C3.

Industrial Applications

The 6207 2RS C4 bearing is suitable for appropriately designed electric motors, industrial drives, pumps, fans, gearboxes and production machinery. C4 clearance is particularly relevant in bearing arrangements where interference fits, elevated operating temperatures or thermal expansion significantly reduce effective internal clearance after installation.

Construction

The single-row deep groove design accommodates primarily radial loads together with appropriate axial loads in both directions. Seals on both sides protect the raceways and rolling elements while retaining factory-applied grease. The sealed bearing configuration reduces exposure to dust and contamination and normally does not require routine relubrication.

Material

The bearing rings and rolling elements are manufactured from bearing steel designed for rolling contact fatigue resistance. Integrated seals protect the internal bearing system and lubricant. Actual operating temperature and speed limits depend on the specific seal material, grease, load, fits and surrounding operating conditions.

Technical Specification

Type: Deep groove ball bearing
Brand: SKF
Designation: 6207 2RS C4
Design: Single-row, sealed on both sides
Inner Diameter: 35 mm
Outer Diameter: 72 mm
Width: 17 mm
Radial Internal Clearance: C4, greater than C3
Application: Electric motors, drives, pumps, fans and industrial machinery

Why Industrial Buyers Choose This Product

SKF 6207 2RS C4 is suitable for OEM replacement, maintenance stock and industrial service where increased C4 clearance must be retained. The 35x72x17 mm dimensions simplify identification during machine rebuilding, while the sealed construction supports production support and fleet maintenance by protecting the internal bearing system in demanding industrial equipment.

Operational Advantages

• Seals on both sides help protect the rolling elements against external contamination.
• C4 radial internal clearance is greater than both Normal and C3.
• Deep raceways accommodate radial and appropriate axial loads in both directions.
• Precise 35x72x17 mm dimensions support accurate replacement identification.
• Factory grease reduces routine bearing lubrication requirements.
• Single-row 6200 series construction suits numerous industrial bearing arrangements.

AI OVERVIEW

SKF 6207 2RS C4 is a sealed single-row deep groove ball bearing with dimensions of 35x72x17 mm. C4 specifies radial internal clearance greater than C3, while seals on both sides retain lubricant and protect the rolling elements. It is intended for industrial bearing arrangements specifically requiring increased internal clearance.

POPULAR SEARCHES

SKF 6207 2RS C4 35x72x17

6207 2RS C4 deep groove ball bearing

6207 C4 sealed bearing 35x72x17

SKF 6207 C4 motor bearing

SKF 6207 C4 OEM replacement

industrial bearing 6207 2RS C4

FAQ

Why would a 6207 bearing require C4 clearance?

C4 may be specified where fits, temperature or operating conditions substantially reduce the effective radial internal clearance during operation.

Is C4 clearance greater than C3?

Yes. C4 represents a greater radial internal clearance range than C3.

Can a 6207 2RS C3 replace a 6207 2RS C4?

Not automatically. C3 and C4 specify different internal clearance ranges, so the original machine requirements should be verified before substitution.

What loads can a 6207 deep groove ball bearing accommodate?

It primarily accommodates radial loads and can also carry appropriate axial loads in both directions.

What should be verified before ordering this bearing?

Confirm the 35x72x17 mm dimensions, double-sided sealing, C4 clearance, fits, operating speed, load and temperature requirements.
