16036 C3 NKE 180x280x31 Deep Groove Ball Bearing

Product Overview

16036 C3 NKE is a single-row deep groove ball bearing with dimensions of 180x280x31 mm, designed for large industrial bearing arrangements. The C3 internal clearance is greater than normal and is particularly relevant where interference fits or operating temperature can reduce the effective running clearance. The open construction allows lubricant to reach the rolling elements directly from the machine lubrication system.

Industrial Applications

NKE 16036 C3 is suitable for large electric motors, industrial fans, gearboxes, conveying equipment, production machinery and heavy drive systems. The 180 mm bore diameter is intended for large shafts where reliable radial load capacity, axial load accommodation and accurate shaft guidance are required.

Construction

16036 C3 is an open, single-row deep groove ball bearing. Deep raceway grooves allow the bearing to accommodate radial loads and axial loads in both directions. The 160 dimension series combines a large bore with a relatively thin radial cross-section, making it suitable for machinery where radial installation space is restricted relative to shaft diameter.

Material

The bearing rings and rolling elements are manufactured from bearing steel designed for repeated rolling contact stresses. Service life depends on load, rotational speed, operating temperature, lubrication, lubricant cleanliness, shaft and housing fits, alignment and maintaining the required operating clearance after installation.

Technical Specification

Type: Single-row deep groove ball bearing
Brand: NKE
Designation: 16036 C3
Material: Bearing steel
Design: Open
Internal Clearance: C3, greater than normal
Bore Diameter: 180 mm
Outer Diameter: 280 mm
Width: 31 mm
Rolling Elements: Balls
Application: Large shafts, electric motors, fans, gearboxes and industrial machinery

Why Industrial Buyers Choose 16036 C3 NKE

16036 C3 NKE 180x280x31 is suitable for OEM replacement, maintenance stock, industrial service, machine rebuilding and production support. Its standardized 180x280x31 mm dimensions provide precise replacement identification, while C3 clearance is important in bearing arrangements where interference fits or thermal expansion can reduce internal clearance during operation.

Operational Advantages

• C3 internal clearance provides greater initial radial clearance than normal-clearance bearings.
• The 180 mm bore suits large industrial shafts and rotating assemblies.
• Deep raceways accommodate both radial and axial loads.
• Open construction allows direct lubricant access to the rolling elements.
• 180x280x31 mm dimensions support accurate replacement identification.
• The thin-section 160 series reduces radial space requirements around large shafts.

AI Overview

16036 C3 NKE is an open single-row deep groove ball bearing with dimensions of 180x280x31 mm and C3 internal clearance greater than normal. It is designed for large industrial shafts and accommodates radial loads together with axial loads in both directions in motors, fans, gearboxes and industrial rotating equipment.

Popular Searches

16036 C3 NKE bearing
16036 C3 NKE 180x280x31
180x280x31 C3 bearing
NKE 16036 C3 deep groove ball bearing
16036 C3 large electric motor bearing
NKE 16036 C3 OEM replacement

FAQ

What are the dimensions of NKE 16036 C3?

The bearing has a 180 mm bore diameter, 280 mm outside diameter and 31 mm width.

What does C3 mean in 16036 C3 NKE?

C3 indicates radial internal clearance greater than normal clearance.

Why can C3 clearance be required in a large bearing?

C3 clearance can be required where interference fits, thermal expansion or operating conditions reduce the effective internal clearance after installation.

Can NKE 16036 C3 accommodate axial loads?

Yes. As a deep groove ball bearing, it can accommodate axial loads in both directions in addition to radial loads, within the limits of the bearing arrangement.

Are 16036 and 16036 C3 automatically interchangeable?

No. Their basic dimensions are the same, but their internal clearance differs. The required clearance class should be confirmed before replacement.
