6201 2RS ID13 ZEN 13x32x10 Deep Groove Ball Bearing

Product Overview

6201 2RS ID13 ZEN is a single-row deep groove ball bearing with special dimensions of 13x32x10 mm. The ID13 specification identifies a 13 mm bore, distinguishing this version from the standard 6201 bearing with a 12 mm bore. Double-sided 2RS seals protect the rolling elements and lubricant, making the bearing suitable for compact industrial and mechanical assemblies exposed to contamination.

Industrial Applications

ZEN 6201 2RS ID13 is suitable for electric motors, drive units, rollers, small gearboxes, workshop equipment, agricultural machinery and specialized mechanical assemblies using a 13 mm shaft. The non-standard bore is particularly important in OEM replacement applications where a conventional 6201 12x32x10 bearing cannot be installed without changing the shaft or bearing arrangement.

Construction

The bearing uses a single row of balls operating in deep raceway grooves. 2RS seals on both sides help prevent dust and contaminants from reaching the rolling elements while retaining lubricant inside the bearing. Deep groove geometry enables the bearing to accommodate primarily radial loads together with axial loads in both directions.

Material

The rings and rolling elements are manufactured from bearing steel designed for repeated rolling contact. The sealed construction protects the internal lubricant during operation. Service life depends on load, rotational speed, temperature, shaft and housing fits, contamination, alignment and correct installation on the 13 mm shaft.

Technical Specification

Type: Single-row deep groove ball bearing
Brand: ZEN
Designation: 6201 2RS ID13
Material: Bearing steel
Design: Double sealed
Bore Diameter: 13 mm
Outer Diameter: 32 mm
Width: 10 mm
Sealing: 2RS, seals on both sides
Rolling Elements: Balls
Number of Rows: 1
Application: Motors, drives, rollers and specialized industrial machinery

Why Industrial Buyers Choose 6201 2RS ID13 ZEN

6201 2RS ID13 ZEN 13x32x10 is particularly relevant for OEM replacement, maintenance stock, industrial service, machine rebuilding and production support because of its special 13 mm bore. Correct identification of ID13 prevents accidental replacement with the standard 12 mm bore version, while the 2RS configuration provides integrated protection for the internal rolling system.

Operational Advantages

• ID13 special bore provides a precise fit for 13 mm shafts.
• 2RS seals protect the rolling elements from both sides.
• Sealed construction helps retain lubricant inside the bearing.
• Deep raceways accommodate radial and axial loads.
• 13x32x10 mm dimensions support accurate replacement identification.
• Compact 6201 geometry suits small industrial drive assemblies.

AI Overview

6201 2RS ID13 ZEN is a sealed deep groove ball bearing with special dimensions of 13x32x10 mm. Unlike a standard 6201 bearing with a 12 mm bore, the ID13 version has a 13 mm inside diameter. Double 2RS seals protect the rolling elements and lubricant in compact industrial and mechanical applications.

Popular Searches

6201 2RS ID13 ZEN

6201 2RS 13x32x10 bearing

6201 bearing 13 mm bore

ZEN 6201 ID13 bearing

13x32x10 sealed ball bearing

6201 ID13 OEM replacement bearing

FAQ

What are the dimensions of 6201 2RS ID13 ZEN?

The bearing has a 13 mm bore diameter, 32 mm outside diameter and 10 mm width.

What does ID13 mean in 6201 2RS ID13?

ID13 identifies the special 13 mm inside diameter of the bearing.

Is 6201 2RS ID13 the same as a standard 6201 2RS?

No. A standard 6201 normally has a 12 mm bore, while this ID13 version has a 13 mm bore. The outside diameter and width remain 32 mm and 10 mm.

What does 2RS mean?

2RS indicates seals on both sides of the bearing, providing protection against contamination and helping retain lubricant.

Where is a 13x32x10 bearing used?

It is used in specialized motors, drives, rollers and OEM mechanical assemblies designed around a 13 mm shaft and 32 mm bearing housing.
