SS 6005 2RS EZO 25x47x12 - Stainless Steel Deep Groove Ball Bearing

SS 6005 2RS EZO 25x47x12 - Stainless Steel Deep Groove Ball Bearing

SS 6005 2RS EZO is a single-row stainless steel deep groove ball bearing with dimensions 25x47x12 mm and seals on both sides. The stainless steel EZO version is also found under the designation 6005H2RS / 6005 H 2RS.

SS 6005 2RS EZO - Technical Data

Dimensions

The principal dimensions are:

25x47x12 mm

• bore diameter d: 25 mm

• outside diameter D: 47 mm

• width B: 12 mm

The basic 6005 designation identifies a deep groove ball bearing with dimensions 25x47x12 mm.

Stainless Steel Construction

The SS designation is commonly used commercially to identify a stainless steel bearing.

For EZO, the stainless steel version of the 6005 bearing can also be found under the designation:

6005H

Therefore, this bearing may be searched as:

SS 6005 2RS

or:

6005H2RS

The stainless steel construction provides increased corrosion resistance compared with conventional bearing steel, making this version suitable for applications where moisture or corrosive environmental conditions may be present.

2RS - Sealed on Both Sides

The 2RS designation indicates sealing on both sides of the bearing.

The seals:

• help prevent contamination from entering the bearing

• help retain lubricant inside the bearing

• protect the raceways and rolling elements

• reduce the need for external relubrication in many applications

SS 6005 2RS is therefore a sealed version of the stainless steel 6005 deep groove ball bearing.

Load Ratings

For the stainless steel EZO SS6005-2RS version, the catalogue specifies:

Basic dynamic load rating Cr: 8550 N

Basic static load rating Cor: 4680 N

Equivalent values:

• Cr: 8.55 kN

• Cor: 4.68 kN

These values apply to the specified stainless steel bearing version and should not automatically be transferred to standard 6005 bearings from other manufacturers.

Deep Groove Ball Bearing Design

SS 6005 2RS EZO is a single-row deep groove ball bearing.

This bearing design is primarily intended to support radial loads. Due to its deep raceway geometry, it can also accommodate axial loads in both directions within the limits of the bearing design and operating conditions.

The 6005 is a non-separable bearing design suitable for a wide range of rotating applications.

Applications of Stainless Steel SS 6005 2RS Bearings

Stainless steel bearings are particularly useful in equipment exposed to moisture, occasional contact with water or environments where conventional bearing steel would be more susceptible to corrosion.

Typical application areas include:

• food processing machinery

• packaging equipment

• washing equipment

• conveyor systems

• pumps

• laboratory equipment

• machinery operating in humid environments

• equipment requiring increased corrosion resistance

Suitability for a specific application should always be determined from the actual operating conditions.

SS 6005 2RS vs Standard 6005 2RS

Both bearings have the same principal dimensions:

25x47x12 mm

The key difference is the material specification.

SS 6005 2RS EZO is a stainless steel version, while a conventional 6005 2RS is normally manufactured from standard bearing steel.

Dimensional compatibility therefore does not mean that the two versions have identical material properties, load ratings or operating characteristics.

SS6005 2RS vs 6005H2RS EZO

Several designations may be encountered for the stainless steel EZO 6005 bearing:

• SS 6005 2RS EZO

• SS6005 2RS EZO

• SS6005-2RS EZO

• 6005 H 2RS EZO

• 6005H2RS EZO

• 6005.H-2RS EZO

These designations are used when identifying the stainless steel, double-sealed EZO 6005 bearing with dimensions 25x47x12 mm.

Alternative Search References

The product can also be searched as:

• SS 6005 2RS EZO

• SS6005 2RS EZO

• SS6005-2RS EZO

• 6005 H 2RS EZO

• 6005H2RS EZO

• 6005.H-2RS EZO

• EZO 6005 stainless

• EZO 6005 stainless steel bearing

• 6005 2RS stainless steel

• SS6005 bearing

• stainless steel bearing 25x47x12

• stainless bearing 6005

• deep groove ball bearing 25x47x12

• EZO bearing 25x47x12

Selection and Interchangeability

Before selecting an alternative to SS 6005 2RS EZO, verify:

1. Bore diameter 25 mm.

2. Outside diameter 47 mm.

3. Width 12 mm.

4. Stainless steel construction.

5. Sealing on both sides.

6. Required load ratings.

7. Operating speed.

8. Operating temperature.

9. Lubrication requirements.

10. Required corrosion resistance.

A standard 6005 2RS and stainless steel SS 6005 2RS have the same principal dimensions of 25x47x12 mm, but they are not identical material versions.

FAQ

What are the dimensions of SS 6005 2RS EZO?

The bearing has dimensions of 25x47x12 mm.

Is SS 6005 2RS EZO a stainless steel bearing?

Yes. It is a stainless steel version of the 6005 single-row deep groove ball bearing.

What does SS mean?

SS is commonly used as an abbreviation for stainless steel.

What does 2RS mean?

2RS indicates that the bearing is sealed on both sides.

What is EZO 6005H2RS?

6005H2RS is a designation encountered for the stainless steel, double-sealed EZO 6005 bearing.

What is the dynamic load rating of SS 6005 2RS EZO?

The catalogue dynamic load rating is Cr 8550 N, or 8.55 kN.

What is the static load rating?

The basic static load rating is Cor 4680 N, or 4.68 kN.

What is the weight of SS 6005 2RS EZO?

The catalogue mass is approximately 0.077 kg.

Can SS 6005 2RS replace a standard 6005 2RS?

The principal mounting dimensions are the same at 25x47x12 mm. However, load ratings, material, lubrication, speed requirements and operating conditions should be checked before substitution.

Where are stainless steel 6005 bearings used?

They are commonly selected for machinery exposed to moisture or environments requiring greater corrosion resistance, including food-processing, packaging, conveyor, pump and washing equipment.

SS 6005 2RS EZO - Quick Technical Answer

SS 6005 2RS EZO is a single-row stainless steel deep groove ball bearing with dimensions 25x47x12 mm and seals on both sides. It is also found as EZO 6005H2RS. The stainless steel version has a basic dynamic load rating of 8.55 kN, static load rating of 4.68 kN and catalogue mass of approximately 0.077 kg.

SS 6005 2RS EZO at simmering.pl

SS 6005 2RS EZO 25x47x12 is available from simmering.pl, a specialist B2B supplier of bearings, radial shaft seals, O-rings and industrial sealing solutions.

Stock and technical service are located in Lublin, Poland, with worldwide shipping available.
