608 ZZ MGK 8x22x7 - Deep Groove Ball Bearing

608 ZZ MGK 8x22x7 - Deep Groove Ball Bearing

608 ZZ MGK is a single-row deep groove ball bearing with dimensions 8x22x7 mm, equipped with metal shields on both sides. The 608 size belongs to a widely used group of miniature deep groove ball bearings designed for compact rotating mechanisms, small electric motors, rollers and other mechanical applications.

608 ZZ MGK - Technical Data

608 ZZ MGK Dimensions

The principal dimensions are:

8x22x7 mm

where:

• d: 8 mm - bore diameter

• D: 22 mm - outside diameter

• B: 7 mm - bearing width

Complete product identification:

608 ZZ MGK 8x22x7

608 Deep Groove Ball Bearing Design

MGK 608 ZZ is a single-row deep groove ball bearing.

Deep groove ball bearings have deep raceways and are primarily designed to accommodate radial loads. Their geometry also allows them to accommodate axial loads in both directions within the operating limits of the bearing design.

The compact dimensions of the 608 bearing make it suitable for many small rotating mechanisms.

What Does ZZ Mean?

The suffix:

ZZ

indicates metal shields on both sides of the bearing.

The alternative designation:

2Z

is also commonly used for a similar double-shielded configuration.

The metal shields help to:

• limit the ingress of dust and small contaminants

• protect the raceways and rolling elements

• retain lubricant inside the bearing

• protect internal bearing components without using contact rubber seals

608 ZZ vs 608 2RS

The:

608 ZZ

and:

608 2RS

bearings have the same principal dimensions:

8x22x7 mm

However, they differ in their closure design.

608 ZZ

Uses metal shields on both sides.

608 2RS

Uses elastomer seals on both sides.

The closure type affects contamination protection, friction and operating characteristics. A replacement should therefore not be selected solely by matching dimensions.

Normal Internal Clearance - Not C3

The designation:

608 ZZ MGK

should not automatically be supplemented with:

C3

The:

608 ZZ C3 MGK

is available as a separate variant with greater-than-normal internal clearance.

Therefore:

608 ZZ MGK

and:

608 ZZ C3 MGK

are not technically identical versions.

If C3 is not specified on the bearing, packaging or product documentation, increased C3 clearance should not be assumed.

Steel Cage

Available product data for the 608 ZZ MGK indicates a:

steel cage

guided by the rolling elements.

The bearing rings and rolling elements are made from bearing steel.

Applications of 608 ZZ Bearings

The 608 bearing size is widely used in compact rotating mechanisms.

Typical applications for this bearing size may include:

• small electric motors

• fans

• rollers

• power tools

• compact drive mechanisms

• technical equipment

• light mechanical assemblies

• skate wheels

• skateboard wheels

• selected scooter wheels

Suitability for a specific machine or device should always be determined according to the technical requirements of the bearing arrangement.

Alternative Search Terms

The product can also be searched as:

• 608 ZZ MGK

• MGK 608 ZZ

• 608ZZ MGK

• 608 ZZ MGK 8x22x7

• MGK 608 8x22x7

• 608 ZZ 8x22x7

• 608 2Z MGK

• 608 2Z 8x22x7

• 608 bearing

• 608 ZZ bearing

• 608ZZ bearing

• 608 2Z bearing

• 608 shielded bearing

• 608 double shielded bearing

• 608 deep groove ball bearing

• MGK 608 bearing

• bearing 8x22x7

• 8x22x7 bearing

• 8x22x7 shielded bearing

Selecting a Replacement for 608 ZZ MGK

Before selecting an alternative, verify:

1. 608 bearing designation.

2. Bore diameter 8 mm.

3. Outside diameter 22 mm.

4. Width 7 mm.

5. Metal shields on both sides.

6. Required internal clearance.

7. Cage construction.

8. Required load capacity.

9. Operating speed.

10. Environmental conditions.

Matching the 8x22x7 mm dimensions alone is not sufficient to confirm full interchangeability.

FAQ

What are the dimensions of 608 ZZ MGK?

The bearing has dimensions of 8x22x7 mm: 8 mm bore diameter, 22 mm outside diameter and 7 mm width.

What type of bearing is MGK 608 ZZ?

It is a single-row deep groove ball bearing.

What does ZZ mean?

ZZ indicates metal shields on both sides of the bearing.

Are ZZ and 2Z similar designations?

Yes. Both designations are commonly used for bearings with metal shields on both sides, although exact suffix terminology can vary between manufacturers.

Does 608 ZZ MGK have C3 clearance?

C3 should not be assumed. The 608 ZZ MGK version is specified with normal internal clearance. 608 ZZ C3 MGK is a separate version with increased internal clearance.

What type of cage does 608 ZZ MGK use?

Available product data indicates a steel cage guided by the rolling elements.

Do 608 ZZ and 608 2RS have the same dimensions?

Yes. Standard 608 ZZ and 608 2RS bearings have dimensions of 8x22x7 mm, but they differ in their closure design.

Is 608 ZZ used in skates and skateboards?

The 608 bearing size is widely used in skate and skateboard wheels. Suitability of a specific bearing should still be checked against the required clearance, closure type, load, speed and operating conditions.

Is every 8x22x7 bearing the same?

No. Bearings with identical dimensions may differ in closure type, internal clearance, cage design, precision and other technical characteristics.

608 ZZ MGK - Quick Technical Answer

608 ZZ MGK is a single-row deep groove ball bearing with dimensions 8x22x7 mm and metal shields on both sides. Available product data indicates a steel cage, cylindrical 8 mm bore and normal internal clearance. The 608 ZZ C3 MGK version with greater-than-normal internal clearance is a separate bearing variant.
