16017 ABEG 85x130x14 mm - Deep Groove Ball Bearing

16017 ABEG 85x130x14 mm - Deep Groove Ball Bearing

16017 ABEG is a single-row deep groove ball bearing with dimensions of 85x130x14 mm. It belongs to the thin-section 16000 dimensional series, combining a relatively large 85 mm bore with a compact 130 mm outside diameter and a width of only 14 mm. The deep groove design is primarily suitable for radial loads and can also accommodate axial loads in both directions within the limits of the bearing design.

Technical data - 16017 ABEG

What does 16017 mean?

16017 is the dimensional designation of a single-row deep groove ball bearing.

The principal dimensions of this bearing size are:

• d = 85 mm

• D = 130 mm

• B = 14 mm

The 16000 series is characterized by a relatively small radial cross-section and narrow width compared with its bore diameter.

16017 ABEG dimensions

The bearing measures:

85x130x14 mm

where:

• 85 mm - bore diameter

• 130 mm - outside diameter

• 14 mm - bearing width

The combination of an 85 mm bore and a width of only 14 mm is one of the key dimensional characteristics of the 16017 bearing.

Thin-section 16000 series

16017 belongs to the 16000 series of deep groove ball bearings with a relatively small cross-section.

Compared with heavier dimensional series having the same bore diameter, the 16017 design can help reduce:

• outside diameter

• axial installation width

• radial installation space

• overall size of the bearing arrangement

This makes the series useful where a relatively large shaft diameter must be accommodated within limited installation space.

However, this does not mean that another bearing with an 85 mm bore can automatically replace a 16017.

Bearing construction

16017 ABEG is a single-row deep groove ball bearing.

Its basic construction consists of:

• inner ring

• outer ring

• one row of balls

• cage separating the rolling elements

• deep raceway grooves

Deep groove ball bearings are non-separable and are among the most versatile rolling bearing designs.

What loads can a 16017 bearing accommodate?

Deep groove ball bearings are primarily designed to accommodate radial loads.

Their raceway geometry also enables them to accommodate axial loads acting in both directions.

The actual permissible load depends on the specific bearing execution and the manufacturer's technical data.

For this reason, load ratings from another manufacturer's 16017 bearing should not automatically be assigned to the ABEG product.

Open bearing design

The basic designation 16017, without an additional sealing or shielding suffix, identifies an open bearing design.

The rolling elements are therefore not enclosed on both sides by shields or seals.

When selecting the bearing, determine whether the application requires:

• an open bearing

• metal shields

• contact or non-contact seals

• external protection provided by the machine design

The closure arrangement affects contamination protection, lubrication conditions, friction and permissible operating conditions.

16017 vs 6017 - what is the difference?

16017 and 6017 should not be confused.

Both bearings have an 85 mm bore, but they belong to different dimensional series.

16017:

85x130x14 mm

The 6017 belongs to a different dimensional series and has a different outside diameter and width.

They are therefore not direct dimensional replacements.

This is particularly important during product identification because omitting the initial digit 1 changes the bearing designation.

16017 vs 61817 and 61917

16017, 61817 and 61917 are different bearing designations representing different dimensional series.

They should not be selected solely on the basis of:

d = 85 mm

When comparing these bearings, verify:

• outside diameter D

• width B

• dimensional series

• closure

• radial internal clearance

• precision class

• cage execution

• operating requirements

The same bore diameter does not establish interchangeability.

16017 replacement bearings

The basic designation 16017 is used by multiple bearing manufacturers.

A 16017 from another manufacturer may therefore be considered as a potential alternative when the principal dimensions are 85x130x14 mm.

However, matching the designation and dimensions alone is not sufficient to confirm complete interchangeability.

Compare:

• complete designation

• principal dimensions

• open, shielded or sealed execution

• radial internal clearance

• precision class

• cage construction

• dynamic and static load ratings

• permissible speeds

• lubrication requirements

• operating conditions

Alternative designations and search references

This bearing may also be searched for as:

• 16017 ABEG

• ABEG 16017

• 16017 85x130x14

• ABEG 16017 85x130x14

• 16017 bearing

• ABEG 16017 bearing

• 16017 ball bearing

• 16017 deep groove ball bearing

• 16017 thin-section bearing

• bearing 85x130x14

• deep groove ball bearing 85x130x14

• thin-section bearing 85x130x14

How to select a replacement for 16017 ABEG

When selecting an alternative bearing, verify the following characteristics.

1. Dimensions

The principal dimensions must be:

85x130x14 mm

2. Bearing type

Single-row deep groove ball bearing.

3. Closure

Determine whether the application requires an open, shielded or sealed bearing.

4. Radial internal clearance

Do not assume Normal, C3 or another clearance class unless it is confirmed by the complete bearing designation.

5. Precision

Applications with specific running accuracy requirements may require a defined bearing tolerance class.

6. Cage

Cage material and construction should be checked when they are relevant to the application.

7. Operating parameters

Load capacity, rotational speed, temperature, lubrication and environmental conditions should be compared.

Matching dimensions of 85x130x14 mm alone do not guarantee complete interchangeability.

Typical applications of 16000 series bearings

Thin-section deep groove ball bearings from the 16000 series can be used in designs where a relatively large shaft diameter must be supported while radial and axial installation space remains limited.

Typical application groups for this bearing type can include:

• industrial machinery

• drive systems

• rotating mechanisms

• production equipment

• compact mechanical assemblies

• machinery with restricted bearing installation space

These are general applications of the bearing type and do not confirm compatibility of 16017 ABEG with a particular machine.

Mounting 16017 ABEG

Before installation, carefully clean:

• shaft

• housing

• bearing seats

• surrounding installation area

Correct shaft and housing fits should be verified before mounting.

When an interference fit is used, mounting force should be applied directly to the ring being fitted.

Mounting force should never be transmitted through the balls and raceways, as this can damage the bearing's working surfaces.

Because the bearing is only 14 mm wide, correct alignment during installation is particularly important.

FAQ

What are the dimensions of 16017 ABEG?

The bearing measures 85x130x14 mm: 85 mm bore, 130 mm outside diameter and 14 mm width.

What type of bearing is 16017?

16017 is a single-row deep groove ball bearing.

Is 16017 a thin-section bearing?

It belongs to the thin-section 16000 dimensional series, characterized by a relatively small cross-section and narrow width compared with the bore diameter.

Is 16017 an open bearing?

The basic 16017 designation without an additional closure suffix identifies an open bearing execution.

Are 16017 and 6017 the same bearing?

No. They belong to different dimensional series. Although both have an 85 mm bore, their remaining principal dimensions differ.

Can 16017 accommodate axial loads?

As a deep groove ball bearing, it can accommodate radial loads and axial loads in both directions within the permissible limits of its design.

Can another manufacturer's 16017 replace ABEG 16017?

It may be a potential replacement if the dimensions and construction correspond, but complete designation, clearance, precision, cage, load ratings, speed limits and operating requirements should also be checked.

Are dimensions 85x130x14 mm enough to identify a replacement?

No. Matching dimensions are an essential starting point but do not by themselves guarantee full technical interchangeability.

16017 ABEG - key information

16017 ABEG is an open, single-row deep groove ball bearing measuring 85x130x14 mm. It belongs to the thin-section 16000 series and combines an 85 mm bore with a width of only 14 mm. When selecting a replacement, verify the complete bearing execution rather than relying solely on dimensional compatibility.

Available from simmering.pl with stock in Poland. We also assist with bearing identification and selection of technically suitable alternatives from different manufacturers.
