SKF W 6010-2RS1 50x80x16 mm

SKF W 6010-2RS1 50x80x16 mm - Stainless Steel Deep Groove Ball Bearing

SKF W 6010-2RS1 is a single-row stainless steel deep groove ball bearing with dimensions of 50x80x16 mm and contact seals on both sides. The W prefix identifies the stainless steel execution, while 2RS1 indicates two contact seals designed to retain lubricant and restrict contamination. This bearing belongs to the 6010 series and is intended for applications requiring improved corrosion resistance compared with conventional bearing steel.

Technical Specifications - SKF W 6010-2RS1

The numerical ratings above refer to the SKF W 6010-2RS1 catalogue execution. They should not be applied automatically to other stainless steel 6010 variants.

What Does SKF W 6010-2RS1 Mean?

The designation identifies the bearing material, basic dimensions and sealing arrangement.

W - Stainless Steel Bearing Execution

The W prefix identifies a stainless steel execution in this SKF bearing family.

Compared with conventional bearing steel, stainless steel offers improved resistance to corrosion in suitable environments.

However, stainless steel is not completely resistant to all chemicals, chlorides, cleaning agents or corrosive liquids.

The actual corrosion resistance depends on the material, operating temperature, chemical concentration and exposure conditions.

6010 - Bearing Series and Bore Size

The basic designation identifies the bearing type and dimensions.

• 6 - Single-row deep groove ball bearing.

• 0 - Dimensional series 60.

• 10 - Bore code corresponding to a 50 mm bore diameter.

The complete bearing dimensions are 50x80x16 mm.

2RS1 - Contact Seals on Both Sides

The SKF suffix 2RS1 identifies two contact seals, one on each side of the bearing.

These seals help retain the factory-applied lubricant and restrict the entry of contaminants.

Contact seals generate friction because they operate against the corresponding sealing surfaces.

The 2RS1 arrangement should not be confused with non-contact metal shields or low-friction sealing designs.

Stainless Steel Bearing Construction

Inner and Outer Rings

SKF W 6010-2RS1 incorporates stainless steel inner and outer rings.

The rings contain deep raceway grooves designed to guide the rolling elements and transmit loads between the shaft and housing.

The stainless steel construction is particularly relevant where conventional bearing steel may be exposed to conditions that increase the risk of corrosion.

Stainless Steel Rolling Elements

The bearing contains one row of stainless steel balls.

The rolling elements transmit radial loads between the inner and outer rings while allowing rotation with rolling contact.

The deep groove geometry also permits axial loading in both directions within the bearing's operating limits.

Contact Sealing System

The 2RS1 seals protect the lubricated interior of the bearing.

Their main functions are to help retain grease and reduce the entry of contaminants.

However, contact seals do not make the bearing completely waterproof or suitable for unrestricted immersion.

For applications involving pressure washing, aggressive cleaning chemicals or prolonged liquid exposure, the complete sealing arrangement must be evaluated.

Corrosion Resistance - What Stainless Steel Does and Does Not Provide

The most important distinction between SKF W 6010-2RS1 and a conventional 6010 bearing is the stainless steel construction.

Stainless steel improves resistance to corrosion in environments where moisture or other corrosive influences may be present.

However, corrosion resistance is not an absolute property.

Its effectiveness depends on:

• Chemical composition of the surrounding medium.

• Chloride concentration.

• Operating temperature.

• Exposure duration.

• Cleaning procedures.

• Surface condition.

• Compatibility of surrounding components.

The stainless steel designation does not independently establish suitability for seawater, concentrated cleaning chemicals or highly aggressive industrial processes.

It also does not establish food-contact approval.

For such applications, material compatibility and the requirements of the complete assembly must be verified.

Alternative Designations and Search References

The bearing may be identified in purchasing documents using the following variations:

• SKF W 6010-2RS1

• W 6010-2RS1 SKF

• W6010-2RS1 SKF

• SKF W6010-2RS1

• W6010 2RS SKF

The complete catalogue designation is W 6010-2RS1.

The commercial reference W6010 2RS should be checked against the actual bearing marking or packaging before an order is confirmed.

The suffixes 2RS, 2RS1 and 2RSH should not automatically be treated as identical SKF executions.

SKF W 6010-2RS1 vs Other Bearing Variants

Bearings with the same dimensions may differ in material, sealing design and operating performance.

SKF W 6010-2RS1 vs W 6010-2Z

Both executions have the same basic dimensions of 50x80x16 mm.

The principal difference is the sealing arrangement.

W 6010-2RS1 incorporates contact seals, while W 6010-2Z uses metal shields.

The SKF catalogue specifies a limiting speed of 5,000 r/min for W 6010-2RS1 and 9,000 r/min for W 6010-2Z.

The difference reflects the different sealing arrangements and associated operating characteristics.

A shielded bearing is not necessarily preferable in contaminated or wet environments.

The correct selection depends on the required protection, operating speed and lubrication conditions.

SKF W 6010-2RS1 vs 6010-2RS1

The key difference is the bearing material.

SKF W 6010-2RS1 uses stainless steel rings and rolling elements.

The conventional SKF 6010-2RS1 uses standard bearing steel.

Although the mounting dimensions are the same, corrosion resistance and material-related operating characteristics differ.

A conventional bearing should not replace a stainless steel execution without evaluating the application environment.

Bearing Selection and Interchangeability

Before selecting SKF W 6010-2RS1, verify the complete manufacturer designation and application requirements.

The most important factors include:

• Bearing dimensions of 50x80x16 mm.

• Stainless steel material requirement.

• Contact sealing arrangement.

• Required internal clearance.

• Radial and axial operating loads.

• Shaft and housing fits.

• Operating speed.

• Temperature and surrounding environment.

• Lubrication requirements.

• Exposure to moisture or chemicals.

Dimensional compatibility alone does not establish full interchangeability.

A bearing from another manufacturer with the same dimensions may differ in steel composition, corrosion resistance, internal clearance, seals, load ratings or speed capability.

Where stainless steel is specified by the equipment manufacturer, the material requirement should be preserved unless an alternative has been technically approved.

Applications of SKF W 6010-2RS1

Stainless steel deep groove ball bearings are used in mechanical systems where improved corrosion resistance is required.

Typical application categories for this bearing design include:

• Rotating equipment operating in humid environments.

• Industrial machinery exposed to occasional moisture.

• Shaft support systems requiring improved corrosion resistance.

• Selected food-processing and process-industry machinery, subject to verification of material and hygiene requirements.

• Mechanical assemblies where conventional bearing steel may be unsuitable because of environmental conditions.

These are general applications of stainless steel deep groove ball bearings, not verified OEM applications of the exact W 6010-2RS1 part number.

Suitability for a specific machine must be established from its technical requirements.

Installation, Lubrication and Storage

Clean Installation

Keep the bearing in its original packaging until installation.

Protect the rings, rolling elements and seals against contamination.

Correct Mounting Force

When mounting the inner ring onto a shaft with an interference fit, apply the mounting force directly to the inner ring.

When pressing the outer ring into a housing, apply force directly to the outer ring.

Mounting forces must not pass through the balls and raceways.

Shaft and Housing Inspection

Check the dimensional tolerances, mounting surfaces, alignment and shoulder geometry before installation.

Correct fits are essential for maintaining the intended operating conditions.

Seal Protection

Avoid damaging or removing the 2RS1 contact seals.

Do not introduce additional lubricant or modify the factory lubrication without a justified technical requirement.

Storage

Store the bearing in a clean, dry environment, preferably in its original packaging.

Frequently Asked Questions - SKF W 6010-2RS1

What are the dimensions of SKF W 6010-2RS1?

The bearing has a 50 mm bore diameter, 80 mm outside diameter and 16 mm width. Its complete dimensions are 50x80x16 mm.

What does W mean in SKF W 6010-2RS1?

The W prefix identifies the stainless steel bearing execution, distinguishing it from a conventional bearing made from standard bearing steel.

What does 2RS1 mean?

The suffix 2RS1 indicates two contact seals, one fitted on each side of the bearing.

Is SKF W 6010-2RS1 waterproof?

No. Stainless steel provides improved corrosion resistance, and the contact seals help restrict contamination, but the bearing is not automatically suitable for immersion or pressure washing.

Can SKF W 6010-2RS1 replace a standard 6010-2RS1 bearing?

The dimensions are identical, but the bearing materials differ. Replacement suitability depends on corrosion requirements, loads, speed and other operating conditions.

What is the dynamic load rating of SKF W 6010-2RS1?

The basic dynamic load rating C is 19 kN. The basic static load rating C0 is 16.6 kN.

What is the limiting speed of SKF W 6010-2RS1?

The SKF catalogue specifies a limiting speed of 5,000 r/min. Actual permissible operating speed depends on the application conditions.

Is SKF W 6010-2RS1 suitable for food-processing machinery?

Its stainless steel construction may be useful in food-processing equipment. However, suitability depends on the sealing materials, lubricant, operating environment and applicable hygiene requirements. The W prefix alone does not establish food-contact approval.

SKF W 6010-2RS1 - Key Technical Information

SKF W 6010-2RS1 is a single-row stainless steel deep groove ball bearing with dimensions of 50x80x16 mm. The W prefix identifies its stainless steel construction, while 2RS1 indicates contact seals on both sides. Its basic dynamic load rating is 19 kN, static load rating is 16.6 kN and limiting speed is 5,000 r/min. The bearing is intended for applications requiring improved corrosion resistance.
