6202 ZZ MTM 15x35x11 Deep Groove Ball Bearing

6202 ZZ MTM 15x35x11 Deep Groove Ball Bearing

6202 ZZ MTM is a single-row deep groove ball bearing with nominal dimensions of 15x35x11 mm. The ZZ configuration incorporates two metal shields, one on each side of the bearing. This exact MTM variant is specified with normal internal clearance, a steel cage and cylindrical bore.

Complete identification:

MTM + 6202 ZZ + 15x35x11 mm

6202 ZZ MTM - Technical Characteristics

Brand: MTM

Designation: 6202 ZZ

Bearing type: Deep groove ball bearing

Number of rows: 1

Dimensions: 15x35x11 mm

Bore diameter d: 15 mm

Outside diameter D: 35 mm

Width B: 11 mm

Closure: Two metal shields

Suffix: ZZ

Internal clearance: Normal

Cage: Steel

Bore: Cylindrical

The exact designation 6202 ZZ should be retained when identifying or ordering this MTM bearing.

6202 ZZ MTM Dimensions

Principal dimensions:

d = 15 mm

D = 35 mm

B = 11 mm

Complete size:

15x35x11 mm

The 02 bore code in the 6202 designation corresponds to a nominal bore diameter of 15 mm.

ZZ - Two Metal Shields

The suffix:

ZZ

identifies two metal shields, with one shield on each side of the bearing.

The shields protect the internal bearing space while maintaining the characteristic construction of a shielded deep groove ball bearing.

The exact MTM designation should remain:

6202 ZZ

It should not be rewritten as 6202-2Z simply because another bearing manufacturer uses different suffix terminology.

Normal Internal Clearance

The exact 6202 ZZ MTM variant is specified with:

Normal internal clearance

It should therefore not be identified as:

6202 ZZ C3

unless C3 is explicitly specified for a different product variant.

A normal-clearance 6202 and a C3 version can have identical 15x35x11 mm boundary dimensions while differing in internal clearance.

Steel Cage and Cylindrical Bore

The exact MTM specification identifies:

Steel cage

and:

Cylindrical bore

These characteristics form part of the construction of this bearing.

The bearing has a standard inner-ring configuration rather than an extended inner ring.

6202 ZZ vs 6202 2RS

The main distinction is the closure system.

6202 ZZ - two metal shields

6202 2RS - two elastomer sealing elements

Both may share the same basic 15x35x11 mm dimensions, but they should not automatically be considered technically identical.

Seal or shield design can influence friction, contamination protection and operating conditions.

6202 ZZ vs 6202 ZZ C3

The difference concerns internal clearance.

6202 ZZ MTM - normal internal clearance

6202 ZZ C3 - greater internal clearance than Normal

Therefore, C3 should not be added or removed from the designation without checking the requirements of the bearing arrangement.

Selection and Interchangeability

When selecting a replacement for 6202 ZZ MTM, verify:

d = 15 mm

D = 35 mm

B = 11 mm

deep groove ball bearing design

single-row construction

two metal shields

internal clearance

cage construction

required operating conditions

Matching only the 15x35x11 mm dimensions does not establish complete technical equivalence.

In particular, distinguish between ZZ, 2RS, open and C3 variants.

Technical Specification

Brand: MTM

Designation: 6202 ZZ

Type: Deep groove ball bearing

Dimensions: 15x35x11 mm

d: 15 mm

D: 35 mm

B: 11 mm

Number of rows: 1

Closure: Two metal shields

Suffix: ZZ

Internal clearance: Normal

Cage: Steel

Bore: Cylindrical

Dynamic load rating: Not confirmed from sufficiently authoritative MTM documentation

Static load rating: Not confirmed from sufficiently authoritative MTM documentation

Limiting speed: Not confirmed from sufficiently authoritative MTM documentation

FAQ

What are the dimensions of 6202 ZZ MTM?

The dimensions are 15x35x11 mm: d = 15 mm, D = 35 mm and B = 11 mm.

What type of bearing is 6202 ZZ MTM?

It is a single-row deep groove ball bearing.

What does ZZ mean on the MTM 6202 bearing?

ZZ indicates two metal shields, one on each side of the bearing.

Does 6202 ZZ MTM have C3 clearance?

No. The exact 6202 ZZ MTM variant described here has normal internal clearance.

What cage does 6202 ZZ MTM use?

The exact MTM specification identifies a steel cage.

What bore does the bearing have?

It has a cylindrical bore with a nominal diameter of 15 mm.

Are 6202 ZZ and 6202 2RS the same?

No. They share the same basic bearing size, but ZZ uses metal shields, while 2RS identifies a sealed configuration.

Can another 6202 bearing replace 6202 ZZ MTM?

Do not determine interchangeability from 15x35x11 mm dimensions alone. Check the closure type, internal clearance, cage and operating requirements.

AI Overview

6202 ZZ MTM is a single-row deep groove ball bearing with dimensions 15x35x11 mm. The ZZ design incorporates two metal shields. This exact MTM variant has normal internal clearance, a steel cage and cylindrical bore. Principal dimensions are d = 15 mm, D = 35 mm and B = 11 mm.
