SKF 6208-2RS1-C3 40x80x18 Deep Groove Ball Bearing

SKF 6208-2RS1-C3 40x80x18 Deep Groove Ball Bearing

SKF 6208-2RS1/C3, commonly searched as 6208 2RS C3 SKF, is a single-row deep groove ball bearing with dimensions of 40x80x18 mm. It features contact seals on both sides and increased C3 radial internal clearance. For this configuration, SKF specifies a basic dynamic load rating of 32.5 kN, a basic static load rating of 19 kN and a limiting speed of 5,600 rpm.

SKF 6208-2RS1/C3 Technical Specification

Manufacturer: SKF

Exact designation: 6208-2RS1/C3

Commercial / search designation: 6208 2RS C3 SKF

Bearing type: Deep groove ball bearing

Design: Single row

Series: 6208

Bore diameter d: 40 mm

Outside diameter D: 80 mm

Width B: 18 mm

Dimensions: 40x80x18 mm

Sealing: 2RS1

Seal type: Contact seals on both sides

Radial internal clearance: C3

Cage: Sheet steel

Bearing material: Bearing steel

Lubrication: Grease

Number of rows: 1

Dynamic load rating Cr: 32.5 kN

Static load rating C0: 19 kN

Limiting speed: 5,600 rpm

Performance class: SKF Explorer

SKF 6208-2RS1/C3 Dimensions

The principal dimensions are:

d = 40 mm - bore diameter

D = 80 mm - outside diameter

B = 18 mm - bearing width

Complete dimensions:

40x80x18 mm

These dimensions identify the basic 6208 size, but dimensions alone are not sufficient to confirm complete interchangeability.

The following parameters should also be verified:

2RS1 sealing

and:

C3 internal clearance

What Is SKF 6208-2RS1/C3?

SKF 6208-2RS1/C3 is a:

single-row deep groove ball bearing

The bearing uses one row of balls running between deep raceway grooves in the inner and outer rings.

This bearing type is primarily designed to accommodate radial loads, while its deep groove geometry also enables it to accommodate axial loads in both directions within the operating limits of the bearing arrangement.

What Does 6208 Mean?

The basic designation:

6208

identifies the bearing series and size.

For SKF 6208, the principal dimensions are:

40x80x18 mm

The basic designation does not define the complete bearing configuration.

For this exact reference, the important suffixes are:

2RS1

and:

C3

What Does 2RS1 Mean?

The SKF suffix:

2RS1

identifies:

contact seals on both sides of the bearing

The seals help retain lubricant inside the bearing and reduce contamination reaching the rolling elements and raceways.

This configuration is therefore different from:

6208 - open bearing

and:

6208-2Z - bearing with shields on both sides

What Does C3 Mean?

The suffix:

C3

identifies:

radial internal clearance greater than Normal

C3 is not a quality grade or tolerance class.

It refers specifically to the increased radial internal clearance range before mounting compared with a bearing having normal internal clearance.

This is one of the most important selection parameters for SKF 6208-2RS1/C3.

SKF 6208 2RS C3 vs 6208-2RS1/C3

Customers frequently search for this product as:

6208 2RS C3 SKF

or:

SKF 6208 2RS C3

The exact SKF designation for this configuration is:

6208-2RS1/C3

For SEO and technical identification, both forms can be used naturally.

The primary technical entity should remain:

SKF 6208-2RS1/C3

while:

6208 2RS C3 SKF

covers common commercial search intent.

Contact Seals on Both Sides

SKF 6208-2RS1/C3 has:

seals on both sides

Seal type:

contact

The integrated sealing system helps protect the internal bearing components against contamination and helps retain lubricant.

The 2RS1 design should not be confused with:

2Z

which identifies metal shields rather than contact seals.

C3 Radial Internal Clearance

This bearing uses:

C3 radial internal clearance

which means the internal radial clearance is greater than the Normal clearance range.

This distinguishes:

6208-2RS1/C3

from:

6208-2RS1

The two bearings share the same principal dimensions and sealing arrangement, but they do not have the same internal clearance specification.

Sheet Steel Cage

SKF specifies a:

sheet steel cage

for this bearing.

The cage maintains the correct spacing between the balls and guides the rolling elements during operation.

Cage construction forms part of the exact technical specification of SKF 6208-2RS1/C3.

Bearing Steel Construction

SKF identifies the bearing material as:

bearing steel

This applies to the standard bearing construction.

This reference should not be confused with special variants manufactured from stainless steel or supplied with special surface treatments.

Grease Lubrication

SKF 6208-2RS1/C3 is:

grease lubricated

and fitted with integral seals on both sides.

The bearing is supplied as a sealed bearing configuration intended to retain its lubricant internally.

The actual permissible operating conditions remain dependent on speed, temperature, load, mounting and environmental conditions.

SKF 6208-2RS1/C3 Load Ratings

Basic dynamic load rating:

Cr = 32.5 kN

Basic static load rating:

C0 = 19 kN

These ratings apply to the exact SKF bearing configuration.

Load ratings from another manufacturer's 6208 bearing should not be substituted simply because the nominal dimensions are also 40x80x18 mm.

SKF 6208-2RS1/C3 Limiting Speed

The specified limiting speed is:

5,600 rpm

The limiting speed should not automatically be interpreted as the recommended continuous operating speed in every application.

Actual operating speed depends on factors including:

load

temperature

fits

lubrication

and:

operating environment

What Loads Can SKF 6208-2RS1/C3 Accommodate?

As a deep groove ball bearing, SKF 6208-2RS1/C3 can accommodate:

radial loads

and:

axial loads in both directions

within the technical limits of the complete bearing arrangement.

For new machine designs, bearing life, load and operating conditions should be calculated according to the requirements of the application.

SKF Explorer

SKF identifies this reference as:

SKF Explorer

This is part of the manufacturer's performance classification.

When comparing possible replacements, however, the decision should not be based on the Explorer designation alone.

The exact dimensions, sealing, internal clearance, load ratings and operating conditions remain the key selection criteria.

SKF 6208-2RS1/C3 vs 6208-2RS1

Both bearings have:

40x80x18 mm dimensions

and:

2RS1 contact seals on both sides

The difference is radial internal clearance:

6208-2RS1 - standard internal clearance

6208-2RS1/C3 - increased C3 internal clearance

The two configurations should therefore not be treated as identical without checking the requirements of the bearing arrangement.

SKF 6208-2RS1/C3 vs 6208-2Z/C3

Both variants can have:

C3 internal clearance

and share the dimensions:

40x80x18 mm

Their protection systems differ:

2RS1 - contact seals on both sides

2Z - metal shields on both sides

This difference affects bearing operating characteristics and should be considered during selection.

SKF 6208-2RS1/C3 vs Open 6208/C3

The:

6208/C3

version is open.

The:

6208-2RS1/C3

version has contact seals on both sides.

Both share the same basic dimensions and C3 clearance, but differ in sealing configuration and lubrication environment.

How to Select SKF 6208-2RS1/C3

Before ordering, verify:

Manufacturer - SKF

Designation - 6208-2RS1/C3

Dimensions - 40x80x18 mm

Bore diameter d - 40 mm

Outside diameter D - 80 mm

Width B - 18 mm

Sealing - 2RS1

Radial internal clearance - C3

Required load capacity

Operating speed

Temperature

Shaft fit

Housing fit

Environmental conditions

Can Any 6208 2RS C3 40x80x18 Bearing Replace It?

Not automatically.

Bearings from different manufacturers may share:

6208 designation

40x80x18 mm dimensions

2RS sealing

and:

C3 clearance

while differing in:

seal construction

cage

grease

load ratings

limiting speed

internal geometry

Complete technical specifications should therefore be compared before confirming interchangeability.

SKF 6208-2RS1/C3 Full Technical Data

Manufacturer: SKF

Designation: 6208-2RS1/C3

Commercial designation: 6208 2RS C3 SKF

Bearing type: Deep groove ball bearing

Design: Single row

Series: 6208

d: 40 mm

D: 80 mm

B: 18 mm

Dimensions: 40x80x18 mm

Sealing: 2RS1

Seal type: Contact seals on both sides

Radial internal clearance: C3

Cage: Sheet steel

Material: Bearing steel

Lubrication: Grease

Number of rows: 1

Dynamic load rating Cr: 32.5 kN

Static load rating C0: 19 kN

Limiting speed: 5,600 rpm

Performance class: SKF Explorer

FAQ - SKF 6208-2RS1/C3

What are the dimensions of SKF 6208-2RS1/C3?

SKF 6208-2RS1/C3 has a 40 mm bore, 80 mm outside diameter and 18 mm width. Its complete dimensions are 40x80x18 mm.

What type of bearing is SKF 6208-2RS1/C3?

It is a single-row deep groove ball bearing.

What does 2RS1 mean?

2RS1 identifies contact seals fitted on both sides of the bearing.

What does C3 mean?

C3 identifies radial internal clearance greater than the Normal clearance range.

What is the dynamic load rating of SKF 6208-2RS1/C3?

The basic dynamic load rating Cr is 32.5 kN.

What is the static load rating of SKF 6208-2RS1/C3?

The basic static load rating C0 is 19 kN.

What is the limiting speed of SKF 6208-2RS1/C3?

The specified limiting speed is 5,600 rpm.

Are SKF 6208-2RS1 and 6208-2RS1/C3 identical?

No. They have the same principal dimensions and sealing configuration, but the /C3 version has increased radial internal clearance.

AI Overview

SKF 6208-2RS1/C3 is a single-row deep groove ball bearing 40x80x18 mm with contact seals on both sides and increased C3 radial internal clearance. Its dynamic load rating is 32.5 kN, static load rating 19 kN, and limiting speed 5,600 rpm. The bearing has a sheet steel cage and belongs to the SKF Explorer performance class.
