TKDM12-WG2/100-10/10 - Precision Linear Guide Rail

Application of TKDM12-WG2/100-10/10 Linear Guide Rail

The TKDM12-WG2/100-10/10 is a precision linear guide rail designed for advanced linear motion systems used in demanding industrial applications. Its primary function is to provide accurate, stable and repeatable linear guidance for linear carriages operating under dynamic and static loads.

This linear guide rail is commonly used in industrial automation, CNC machines, assembly lines, robotics, positioning systems and compact mechanical assemblies. It can be installed horizontally or vertically and integrated into single-axis or multi-axis linear motion systems.

Design Advantages and Performance Features

• Precision linear guide rail for use with linear guide carriages

• High durability thanks to hardened raceway surfaces

• Stable operation under continuous and dynamic loads

• Accurate linear guidance for high-precision applications

• Compatible with ball recirculation carriages operating similarly to a ball bearing system

• Easy integration into machine frames, bearing housings and linear motion units

Technical Data - TKDM12-WG2/100-10/10

• Product type: linear guide rail

• Designation: TKDM12-WG2/100-10/10

• Rail size: 12

• Length: 100 mm

• Mounting hole pattern: 10/10

• Application: linear motion systems

• Characteristics: precision, stability, low wear

• Typical use: industrial automation, CNC, machinery

Main Description

The TKDM12-WG2/100-10/10 linear guide rail is engineered to meet the requirements of professional linear motion systems where precision, reliability and long service life are essential. When combined with a compatible linear carriage, the rail forms a stable guiding system that enables smooth and controlled linear movement with high positioning accuracy.

The hardened raceway surface ensures high durability and resistance to wear, even under intensive operating conditions. The rail design allows uniform load distribution and reduced vibration, directly improving machine performance and operational accuracy.

This model is particularly suitable for compact automation systems and precision machinery where space efficiency and reliable guidance are critical. It integrates easily with other mechanical components such as linear carriages, bearing units and drive systems, creating a robust and efficient linear motion solution.

Thanks to its standardized mounting pattern and precise manufacturing, the TKDM12-WG2/100-10/10 linear guide rail allows fast installation and straightforward replacement, which is especially valuable in B2B environments focused on uptime and maintenance efficiency.

FAQ - Frequently Asked Questions

What is TKDM12-WG2/100-10/10?
It is a precision linear guide rail used in linear motion systems with linear guide carriages.

Where is this linear guide rail used?
It is used in industrial automation, CNC machines, robotics, assembly lines and positioning systems.

Does the rail work with ball recirculation carriages?
Yes. It is designed to work with linear carriages using ball recirculation, similar in principle to a ball bearing.

Is the rail suitable for continuous operation?
Yes. The hardened raceway ensures high durability and long service life in industrial environments.

Is installation complicated?
No. The standard mounting hole pattern allows fast and precise installation.
