Bosch Rexroth R165322420 KWD-025-FLS-C2-N-1 Linear Guide Block
Processing time: 2-3 days
€111.14
(net)
Price for: 1pcs.
Available from simmering.pl
The product is available from the simmering.pl Warehouse & Store:
Poland
- Fast 24-hour dispatch
- Personal collection available
- Professional technical support
- Shipping throughout Poland and the European Union
PrestaShop Product Summary
The Bosch Rexroth R165322420 KWD-025-FLS-C2-N-1 is a precision size 25 ball runner block for profiled linear guide rail systems. Its long flanged FLS design, C2 preload and N accuracy class provide high rigidity, smooth motion and repeatable positioning. Standard seals protect the internal ball circuits, while factory lubrication simplifies installation. Suitable for CNC machines, industrial automation, robotics, production equipment and OEM machine building. Available from the simmering.pl.
Precision Ball Runner Block for Profiled Rail Systems
The Bosch Rexroth R165322420, designated KWD-025-FLS-C2-N-1, is a precision ball runner block designed for size 25 profiled rail systems. Its FLS flanged, long, standard-height design provides high rigidity, load capacity and accurate linear guidance. The runner block features C2 preload, N accuracy class, standard sealing and factory lubrication, making it suitable for CNC machinery, industrial automation and production equipment requiring stable, repeatable linear motion.
Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | Bosch Rexroth |
| Part Number | R165322420 |
| Designation | KWD-025-FLS-C2-N-1 |
| Product Type | Ball runner block / linear guide carriage |
| Guide System | Profiled rail system |
| Size | 25 |
| Design | FLS - flanged, long, standard height |
| Preload Class | C2 |
| Accuracy Class | N |
| Sealing | Standard seals |
| Lubrication | Factory lubricated |
| Width | 70 mm |
| Length | 107.9 mm |
| Assembly Height with Rail | 36 mm |
| Approximate Weight | 0.94 kg |
Product Description
The Bosch Rexroth R165322420 linear guide block is engineered to provide smooth, precise and repeatable linear motion in demanding machine-building applications. Recirculating precision balls reduce friction and enable accurate travel while supporting loads from different directions.
The long flanged FLS design offers an extended load-bearing zone and convenient mounting options. Its flange allows secure installation from above and supports stable integration into machine tables, slides and moving assemblies.
The C2 preload class reduces internal clearance and increases system rigidity. This supports more accurate positioning and improves resistance to deformation under changing loads. The N accuracy class is intended for standard industrial applications that require dependable precision and consistent running quality.
Standard seals help protect the internal ball circuits against dust and contaminants, while factory lubrication allows the carriage to be installed without initial lubrication preparation.
Key Features
- Original Bosch Rexroth linear motion component
- Size 25 profiled rail carriage
- Long flanged FLS design
- C2 preload for increased rigidity
- N accuracy class
- Smooth recirculating ball motion
- Standard sealing system
- Factory lubricated
- High load capacity
- Precise and repeatable guidance
- Suitable for OEM and MRO applications
Typical Applications
The Bosch Rexroth R165322420 runner block is commonly used in:
- CNC machining centres
- CNC milling machines
- CNC lathes
- Industrial robots
- Automated production lines
- Assembly machinery
- Packaging equipment
- Cutting machines
- Linear positioning systems
- Material-handling equipment
- Special-purpose machinery
- OEM machine building
The runner block should be matched with a compatible Bosch Rexroth profiled rail of the correct size and specification.
Why Choose a Bosch Rexroth Ball Runner Block?
Bosch Rexroth profiled rail systems are designed for applications requiring high rigidity, accurate positioning and low-friction linear motion. The recirculating ball system provides efficient movement, while the profiled rail geometry allows the assembly to support loads and moments in multiple directions.
The R165322420 version combines a long flanged body with C2 preload, providing a stable solution for machine axes and moving assemblies exposed to changing loads.
FAQ
What is Bosch Rexroth R165322420?
It is a size 25 ball runner block for Bosch Rexroth profiled linear guide rail systems.
What does KWD-025-FLS-C2-N-1 mean?
The designation identifies a size 25 ball runner block with a long flanged standard-height design, C2 preload and N accuracy class.
What does FLS mean?
FLS refers to a flanged, long runner block with standard assembly height.
What does C2 preload mean?
C2 indicates a medium preload level that reduces internal clearance and increases the rigidity of the guide system.
What does accuracy class N mean?
N is the normal accuracy class intended for standard industrial machine-building and automation applications.
Is the runner block supplied lubricated?
Yes. It is factory lubricated, although maintenance intervals should follow Bosch Rexroth recommendations and the operating conditions of the machine.
Which rail size is compatible with this block?
It is designed for compatible Bosch Rexroth profiled rails in size 25.
Where is this runner block commonly used?
Typical uses include CNC machinery, automation systems, robotics, production equipment and precision linear positioning assemblies.
