LSAGF25 C1S2 IKO - Roller Linear Guide Carriage Size 25

LSAGF25 C1S2 IKO - Precision Roller Linear Guide Carriage

Industrial Applications and Motion Systems

The LSAGF25 C1S2 IKO is a precision roller linear guide carriage designed for high-load and high-rigidity linear motion systems. It is widely used in CNC machines, industrial automation, robotic systems, transfer lines and precision assembly equipment where accuracy and stability are critical. Combined with a matching guide rail, it forms a complete linear motion unit capable of handling demanding operating conditions.

This component is not a standard łożysko kulkowe (ball bearing). Instead, it is a roller-type linear guide carriage engineered for controlled, low-friction linear movement under heavy loads.

Design and Technical Advantages

The LSAGF series uses cylindrical rollers instead of balls, increasing the contact surface between rolling elements and raceways. This design provides higher rigidity, improved load capacity and better resistance to moment loads compared to conventional ball-type systems.

The hardened steel body and precision-ground raceways ensure high durability and long service life. Integrated sealing elements protect the rolling mechanism from contamination, making the carriage suitable for harsh industrial environments. The C1 preload class and S2 specification support applications requiring enhanced positioning accuracy and minimized deflection.

Technical Overview

• Type: Roller linear guide carriage
• Series: LSAGF
• Nominal size: 25
• Manufacturer: IKO
• Application: industrial motion systems, CNC, automation

Designed for demanding industrial applications where standard ball-type linear solutions are insufficient in terms of stiffness and load performance.

FAQ

Is LSAGF25 C1S2 IKO a ball bearing?
No. It is a roller linear guide carriage, not a standard ball bearing. It operates on rollers for higher rigidity.

What are typical applications?
CNC machines, robotics, precision automation systems and heavy-duty linear positioning units.

What is the advantage of a roller-type carriage?
Rollers provide higher load capacity and stiffness compared to ball-type linear guides.

Does it require a specific rail?
Yes, it must be used with the corresponding IKO linear guide rail to create a complete linear motion unit.
