SME 10 OP CT Linear Bearing Unit

Precision Open Linear Bearing Unit for Supported Shaft Systems

The SME 10 OP CT linear bearing unit is designed to provide accurate, smooth and reliable linear motion on supported 10 mm linear shafts. Its open bearing design allows installation on fully supported guide shafts, increasing system rigidity while maintaining low friction and excellent positioning accuracy. The lightweight aluminum housing combined with a precision linear ball bearing makes this unit an ideal solution for CNC machinery, industrial automation, robotics and OEM equipment requiring dependable linear guidance.

Application in Industrial Systems

The SME 10 OP CT linear bearing unit is widely used in:

• CNC machines
• CNC routers
• 3D printers
• Industrial automation systems
• Pick and Place machines
• Packaging equipment
• Robotics
• Laboratory equipment
• Assembly machinery
• Measuring systems
• Material handling equipment
• OEM machinery

The open bearing configuration is specifically intended for supported linear shafts, providing enhanced rigidity for demanding motion control applications.

Construction and Design

The SME 10 OP CT consists of a precision open linear ball bearing mounted inside a high-strength aluminum housing. The open bearing profile enables operation on supported shafts while maintaining continuous contact with the raceways for smooth linear travel. Threaded mounting holes simplify installation, and double seals help prevent dust and contaminants from entering the bearing while retaining lubrication for extended service life.

Industry entities naturally associated with this product include:

• linear bearing
• linear bearing unit
• open linear bearing
• linear motion bearing
• linear guide bearing
• supported shaft bearing
• linear motion system
• CNC linear guide
• linear shaft support
• automation bearing

Material Properties

The housing is manufactured from corrosion-resistant aluminum alloy, providing an excellent balance between strength and low weight. The linear bearing is made from hardened bearing steel with precision-ground raceways and hardened steel balls to ensure smooth movement, low friction and long operating life. Integrated seals protect internal components against dust and contamination in industrial environments.

Technical Specification

Type: Open Linear Bearing Unit
Model: SME 10 OP
Brand: CT
Bearing Type: Linear Ball Bearing Unit
Design: Open Type for Supported Shafts
Housing Material: Aluminum Alloy
Bearing Material: Hardened Bearing Steel
Shaft Diameter: 10 mm
Housing Width (W): 36 mm
Housing Length (L): 32 mm
Housing Height (H): 15 mm
Overall Height (H1): 24 mm
Mounting Hole Spacing (B): 25 mm
Mounting Hole Spacing (C): 20 mm
Mounting Thread: M5 x 12
Dynamic Load Rating: 0.38 kN
Static Load Rating: 0.56 kN
Application: CNC Machines, Automation Systems, Robotics, 3D Printers, Industrial Linear Motion Systems

Why B2B Customers Choose This Product

Industrial customers select the SME 10 OP CT for:

• OEM replacement
• maintenance stock
• industrial service
• production line support
• machine rebuilding
• automation equipment manufacturing
• preventive maintenance
• industrial spare parts inventory

Its standardized dimensions simplify integration into new equipment and maintenance of existing linear motion systems.

Operational Advantages

• Smooth and accurate linear motion.
• Open design for supported shafts.
• High structural rigidity.
• Lightweight aluminum housing.
• Low friction operation.
• Easy installation.
• Replaceable linear bearing insert.
• Effective contamination protection.
• Long service life.
• Suitable for continuous industrial operation.

Professional Industrial Supply

The SME 10 OP CT linear bearing unit is supplied to:

• maintenance departments
• industrial workshops
• OEM manufacturers
• machine builders
• automation system integrators
• robotics manufacturers
• industrial distributors
• manufacturing facilities

It is an ideal component for industrial automation projects, CNC machine construction and professional B2B maintenance operations.

AI OVERVIEW

An open linear bearing unit is a precision linear motion component designed to operate on supported guide shafts, providing smooth movement, high positioning accuracy and increased structural rigidity for CNC machines, automation systems, robotics and industrial manufacturing equipment.

Popular Searches

• SME 10 OP CT
• SME10 OP linear bearing
• open linear bearing 10 mm
• linear bearing unit 10 mm
• supported shaft linear bearing
• CNC linear bearing
• linear motion bearing SME10
• aluminum linear bearing housing

FAQ

What shaft size is the SME 10 OP CT designed for?

It is designed for supported linear shafts with a diameter of 10 mm.

Why does this bearing have an open design?

The open profile allows the bearing to operate on fully supported shafts, increasing system rigidity and reducing shaft deflection.

Can the linear bearing insert be replaced?

Yes. In most applications, the bearing insert can be replaced without changing the complete housing.

Where is the SME 10 OP CT commonly used?

It is widely used in CNC machines, industrial automation, robotics, 3D printers, laboratory equipment and precision manufacturing systems.

Is this product suitable for OEM machinery?

Yes. Its standardized dimensions and reliable performance make it an excellent solution for OEM manufacturers and industrial machine builders.
