THK GSR20 TSS Linear Guide Block

Premium THK Linear Motion Carriage for Precision Applications

The THK GSR20 TSS is a premium LM Guide linear carriage designed for high-precision linear motion in industrial automation and machine-building applications. Manufactured by THK, it combines compact dimensions, excellent rigidity and smooth linear travel to deliver reliable long-term performance in demanding operating environments.

The GSR Series features a unique self-aligning circular-arc contact structure, allowing the carriage to compensate for minor mounting inaccuracies while maintaining excellent motion accuracy and service life. This makes it particularly suitable for general industrial machinery where perfect installation accuracy is difficult to achieve.

Applications

The THK GSR20 TSS is widely used in:

• CNC machining centers
• CNC milling machines
• Industrial automation
• Robotic systems
• Assembly machines
• Packaging equipment
• Semiconductor machinery
• Measuring equipment
• Medical devices
• Production lines
• OEM machinery
• Precision linear motion systems

Its compact size and high rigidity make it ideal for machines requiring accurate positioning and reliable continuous operation.

GSR Series Features

The THK GSR Series offers:

• Compact low-profile design
• Two-row recirculating ball system
• Self-aligning capability
• Circular-arc raceway technology
• Equal load capacity in multiple directions
• High rigidity
• Smooth linear motion
• Long service life

The circular-arc contact design allows the guide block to absorb installation errors while maintaining excellent running performance and durability.

Advantages of the GSR20 TSS

The GSR20 TSS provides:

• Slim carriage design
• Standard block length
• High positioning accuracy
• Smooth linear travel
• Low friction
• Reduced vibration
• High rigidity
• Long maintenance intervals

Its optimized construction ensures reliable performance while minimizing wear and extending operational life.

Technical Specification

Product Type: Linear Guide Block (LM Guide Carriage)

Manufacturer: THK

Series: GSR

Model: GSR20 TSS

Guide Size: 20

Construction: Slim, Standard Length

Rolling Elements: Recirculating Balls

Ball Rows: Double-row

Accuracy Class: Normal

Preload: Normal

Width: Slim

Lubrication: Relubrication via grease nipple

Operating Temperature: -20°C to +80°C

Sealing: End seals, inner seals and sealing strips

Application: CNC machinery, robotics, industrial automation, measuring systems and OEM equipment.
