O-Ring 6x2 VMQ 70 ShA Silicone

O-Ring 6x2 VMQ 70 ShA Silicone - 100 pcs

O-Ring 6x2 VMQ 70 ShA is a silicone sealing ring with an inside diameter of 6 mm and a cross-section of 2 mm, manufactured from VMQ silicone rubber with a nominal hardness of 70 Shore A. The calculated outside diameter is 10 mm. The O-ring has a round cross-section and is designed for installation in an appropriately dimensioned sealing groove. The package contains 100 pcs.

Technical data - O-Ring 6x2 VMQ 70 ShA

The exact operating temperature range, resistance to specific media and any regulatory approvals depend on the specific VMQ compound. Without a material data sheet for the exact compound, unverified values should not be assigned to this SKU.

O-Ring 6x2 mm dimensions

The designation:

6x2 mm

defines the two fundamental dimensions of the O-ring:

• 6 mm - inside diameter d1
• 2 mm - cross-section diameter d2

The calculated outside diameter is:

6 mm + 2 x 2 mm = 10 mm

Both the inside diameter and cross-section must be considered when identifying an O-ring.

The description "6 mm O-ring" alone is not sufficient because O-rings with the same 6 mm inside diameter can be manufactured with different cross-sections.

What does O-Ring 6x2 VMQ 70 ShA mean?

The complete designation describes the key product characteristics:

6 - nominal inside diameter of 6 mm.

2 - nominal cross-section diameter of 2 mm.

VMQ - silicone rubber.

70 ShA - nominal elastomer hardness of 70 Shore A.

100 pcs - number of O-rings in the package.

The complete technical identification is therefore:

O-Ring 6x2 mm VMQ 70 ShA

VMQ or MVQ?

The technical designation commonly used for this silicone rubber family is:

VMQ

Therefore, the recommended product name for simmering.pl is:

O-Ring 6x2 VMQ 70 ShA Silicone - 100 pcs

The spelling:

MVQ

may be included naturally in the content as an alternative variant sometimes used by customers when searching for silicone O-rings.

For the product name, H1 and technical specification, VMQ is the recommended designation.

VMQ silicone rubber

VMQ belongs to the silicone rubber family of elastomers used for O-rings and other sealing components.

Characteristic properties of the VMQ material family include:

• useful elastomeric properties across a broad temperature range
• very good low-temperature flexibility
• good resistance to ozone
• good resistance to UV radiation
• good resistance to weathering
• useful electrical insulation properties

These are general characteristics of the VMQ material family and should not be interpreted as guaranteed numerical performance values for this specific product.

Operating temperature of VMQ 70 ShA

A single universal operating temperature range should not be assigned to every VMQ 70 ShA O-ring.

Actual temperature limits depend on factors including:

• exact VMQ compound formulation
• exposure duration
• operating medium
• pressure
• sealing-system design
• static or dynamic operation
• other application conditions

For this reason, no unverified minimum or maximum operating temperature is stated for this specific SKU.

For applications where temperature limits are critical, the technical data sheet for the exact VMQ compound should be consulted.

What does 70 ShA mean?

70 ShA indicates a nominal material hardness of 70 on the Shore A scale.

Hardness influences how the O-ring deforms when compressed inside the sealing groove.

However, hardness alone does not define:

• operating temperature
• chemical resistance
• resistance to oils
• resistance to fuels
• abrasion resistance
• sealing service life
• food-contact approval

Two O-rings with the same nominal hardness of 70 ShA can have different properties when manufactured from different elastomers or different formulations.

Construction and operating principle

O-Ring 6x2 VMQ is a closed elastomeric ring with a circular cross-section of 2 mm.

When installed in a correctly designed sealing groove and compressed between mating components, the O-ring deforms elastically.

This deformation generates contact pressure against the mating surfaces and creates the sealing barrier.

Effective sealing depends on the complete system, including:

• O-ring dimensions
• groove geometry
• compression
• O-ring stretch
• mating surface condition
• operating medium
• temperature
• pressure
• static or dynamic operation

Dimensions alone are therefore not sufficient to determine whether an O-ring is suitable for a specific application.

O-Ring 6x2 VMQ vs NBR

O-Ring 6x2 VMQ 70 ShA and O-Ring 6x2 NBR 70 ShA may have identical dimensions and nominal hardness, but they are not materially equivalent.

VMQ is silicone rubber.

NBR is nitrile rubber.

These elastomer families have different thermal, chemical and mechanical characteristics.

Therefore, dimensional compatibility at 6x2 mm does not automatically mean complete interchangeability.

O-Ring 6x2 VMQ vs FKM

The same principle applies when comparing VMQ with FKM.

An O-Ring 6x2 VMQ and O-Ring 6x2 FKM may fit the same groove dimensionally, but their material characteristics can differ significantly.

Before changing the elastomer material, verify:

• operating medium
• temperature
• pressure
• type of movement
• environmental conditions
• application requirements

Material selection should not be based on dimensions alone.

Chemical compatibility of VMQ

VMQ should not be regarded as universally resistant to all chemicals.

Material compatibility should be checked particularly when the O-ring is exposed to:

• oils
• fuels
• greases
• solvents
• acids
• alkalis
• alcohols
• water and steam
• gases
• industrial process fluids

Where chemical resistance is critical, compatibility data for the exact VMQ compound and operating medium should be verified.

Is a VMQ silicone O-ring food safe?

The VMQ designation alone does not confirm food-contact approval.

Special silicone compounds are available for food, pharmaceutical and medical applications, but the relevant certifications apply to a specific compound or finished product.

Without supporting documentation, this O-Ring 6x2 VMQ 70 ShA should not be described as compliant with FDA, EC 1935/2004 or medical requirements.

O-Ring 6x2 vs O-Ring 6x1.5

O-Ring 6x2 mm is not the same size as O-Ring 6x1.5 mm.

Both rings may have an inside diameter of 6 mm, but their cross-sections differ.

O-Ring 6x2 mm:

• inside diameter 6 mm
• cross-section 2 mm
• calculated outside diameter 10 mm

O-Ring 6x1.5 mm:

• inside diameter 6 mm
• cross-section 1.5 mm
• calculated outside diameter 9 mm

The difference in cross-section affects groove filling and sealing compression.

These sizes should not be interchanged without checking the groove geometry.

Selection and interchangeability

Before purchasing O-Ring 6x2 VMQ 70 ShA, verify:

• inside diameter 6 mm
• cross-section 2 mm
• material VMQ
• nominal hardness 70 ShA
• groove geometry
• required compression
• permissible stretch
• operating medium
• temperature
• pressure
• static or dynamic operating conditions

Identical dimensions do not automatically mean complete interchangeability.

O-rings measuring 6x2 mm manufactured from VMQ, NBR, FKM or EPDM can have identical geometry but significantly different material properties.

Applications

O-Ring 6x2 VMQ can be used as a sealing element in appropriately designed grooves where the properties of the specific silicone compound meet the application requirements.

O-rings as a sealing type can be used in static applications and, with appropriate sealing-system design, in selected dynamic applications.

No specific machine, vehicle, engine, gearbox or OEM application is assigned to this SKU without supporting technical documentation.

Installation and handling

Before installation, inspect the condition of the O-ring and mating surfaces.

The sealing groove should be clean and free from:

• contamination
• metal particles
• sharp edges
• burrs
• surface damage

Do not twist or excessively stretch the O-ring during installation.

Avoid sharp tools that could cut, scratch or otherwise damage the elastomer.

If an assembly lubricant is required, its compatibility with the VMQ material and operating medium should be verified beforehand.

O-rings should be stored away from excessive heat, direct UV exposure, contamination and conditions that could damage the elastomer.

Alternative designations and search references

Natural product references include:

O-Ring 6x2 VMQ 70 ShA

6x2 VMQ O-Ring

O-Ring 6x2 MVQ 70 ShA

6x2 MVQ O-Ring

Silicone O-Ring 6x2 mm

6x2 silicone O-ring

6 mm ID 2 mm CS O-ring

VMQ 70 Shore O-Ring 6x2

O-Ring 6x2 VMQ 100 pcs

6x2 silicone sealing ring

No OEM or cross-reference numbers are stated because none have been confirmed for this product.

FAQ

What are the dimensions of O-Ring 6x2 VMQ 70 ShA?

The inside diameter is 6 mm and the cross-section is 2 mm. The calculated outside diameter is 10 mm.

What does VMQ mean?

VMQ identifies a family of silicone rubber elastomers used in O-rings and other sealing components.

What does 70 ShA mean?

70 ShA indicates a nominal elastomer hardness of 70 on the Shore A scale.

VMQ or MVQ - which designation is correct?

VMQ is the recommended technical designation for this silicone rubber family. MVQ may occur as an alternative search spelling, but VMQ should be used in the technical specification.

What is the operating temperature of O-Ring 6x2 VMQ 70 ShA?

The exact operating temperature range cannot be determined from the VMQ 70 ShA designation alone. It depends on the specific compound, operating medium and application conditions.

Can O-Ring 6x2 VMQ replace O-Ring 6x2 NBR?

Not automatically. The dimensions may be identical, but VMQ and NBR have different material characteristics. Operating medium, temperature and other conditions must be checked.

Can O-Ring 6x2 be replaced with O-Ring 6x1.5?

Not without checking the sealing groove. O-Ring 6x1.5 has a smaller cross-section and a calculated outside diameter of 9 mm instead of 10 mm.

Is this O-ring approved for food contact?

This cannot be confirmed from the VMQ designation alone. Food-contact approval must be supported by documentation for the exact compound or finished product.

O-Ring 6x2 VMQ 70 ShA - key information

O-Ring 6x2 VMQ 70 ShA is a silicone sealing ring with a 6 mm inside diameter and 2 mm cross-section. Its calculated outside diameter is 10 mm. VMQ identifies silicone rubber, while 70 ShA specifies the nominal Shore A hardness. The product is supplied in a package containing 100 pieces.
