17x35x10 TC NBR Oil Seal - Double Lip

Rotary Shaft Seal 17x35x10 NBR TC Oil Seal Double Lip

The 17x35x10 TC NBR is a double-lip rotary shaft oil seal with dimensions 17x35x10 mm, manufactured from nitrile rubber (NBR). The TC design incorporates a primary sealing lip and an additional dust lip, which helps protect the sealing area against external contamination.

Technical Data

17x35x10 mm Dimensions

The designation 17x35x10 defines the principal dimensions of the oil seal:

• 17 mm - shaft diameter

• 35 mm - outside diameter / housing bore diameter

• 10 mm - seal width

Complete technical identification:

17x35x10 TC NBR

When selecting a replacement, all three dimensions as well as the material and seal design should be verified.

NBR - Nitrile Rubber

The oil seal is manufactured from NBR - nitrile butadiene rubber, one of the most commonly used elastomers for rotary shaft seals.

NBR offers good resistance to many:

• mineral oils

• lubricating greases

• mineral-oil-based fluids

For this reason, NBR is widely used in seals for machinery, gearboxes, drives, motors and other rotating-shaft applications.

Compatibility with the specific operating medium and actual working conditions should always be verified before installation.

TC - Double-Lip Oil Seal Design

The TC design is a widely recognized designation for a double-lip rotary shaft oil seal.

The construction incorporates:

• a primary sealing lip

• an additional dust lip

The primary lip provides the main sealing function around the rotating shaft.

The secondary lip helps prevent dust, dirt and other external contaminants from reaching the primary sealing area.

The product can therefore be identified as:

17x35x10 TC NBR Double-Lip Oil Seal

17x35x10 TC NBR Oil Seal

The combination of dimensions, material and construction is important for correct product identification:

17x35x10 - TC - NBR

A seal should not be selected solely because its dimensions are 17x35x10 mm. Products of the same size may differ in:

• elastomer material

• lip configuration

• outer diameter design

• sealing characteristics

• intended operating conditions

These differences can affect compatibility and service life.

NBR vs VMQ 17x35x10 Oil Seal

A 17x35x10 NBR oil seal is not materially identical to a VMQ silicone oil seal of the same dimensions.

NBR

NBR is nitrile rubber widely used with many mineral oils and greases.

VMQ

VMQ is silicone rubber with different material characteristics, particularly regarding its behaviour across a wide temperature range.

Therefore:

17x35x10 TC NBR

and:

17x35x10 TC VMQ

should not automatically be considered interchangeable.

Applications

The 17x35x10 TC NBR oil seal is designed for radial sealing of rotating shafts in appropriately designed machinery and mechanical assemblies.

The double-lip construction is particularly useful where the primary sealing function is combined with additional protection against external contamination.

Suitability for a specific application depends on:

• dimensions

• seal material

• seal design

• operating medium

• temperature

• shaft speed

• pressure

• shaft surface condition

• environmental conditions

How to Select a 17x35x10 Oil Seal

Before selecting the seal, verify:

1. Shaft diameter 17 mm.

2. Housing bore diameter 35 mm.

3. Width 10 mm.

4. NBR material.

5. TC double-lip design.

6. Required additional dust lip.

7. Operating medium.

8. Operating temperature.

9. Shaft speed.

10. Actual operating conditions.

Matching the 17x35x10 mm dimensions alone is not sufficient to confirm full interchangeability.

Alternative Search Terms

The product can also be searched as:

• 17x35x10 oil seal

• 17x35x10 NBR oil seal

• NBR oil seal 17x35x10

• 17x35x10 TC oil seal

• 17x35x10 TC NBR

• TC 17x35x10 NBR

• 17x35x10 double lip oil seal

• 17x35x10 double lip shaft seal

• 17x35x10 rotary shaft seal

• rotary shaft seal 17x35x10

• shaft seal 17x35x10

• NBR shaft seal 17x35x10

• rubber oil seal 17x35x10

• Simmerring 17x35x10

• NBR Simmerring 17x35x10

• TC Simmerring 17x35x10

Installation

Before installation:

• thoroughly clean the shaft and housing bore

• inspect the shaft sealing surface

• remove dirt, corrosion and burrs

• protect the sealing lip from sharp edges, threads and grooves

• use a suitable installation tool

• press the seal evenly into the housing

• avoid deformation of the seal body

• verify the correct installation orientation

Damage to the primary sealing lip during installation may cause leakage even when the seal has been correctly selected.

FAQ

What are the dimensions of the 17x35x10 TC NBR oil seal?

The seal is designed for a 17 mm shaft and 35 mm housing bore and has a width of 10 mm.

What material is the 17x35x10 oil seal made from?

It is manufactured from NBR - nitrile rubber.

Is the 17x35x10 TC oil seal double-lip?

Yes. The TC construction incorporates a primary sealing lip and an additional dust lip.

What does TC mean on an oil seal?

TC is a widely used designation for a double-lip rotary shaft oil seal with a primary sealing lip and an additional dust lip.

What does NBR mean?

NBR stands for nitrile butadiene rubber, an elastomer widely used for rotary shaft seals.

Is NBR resistant to oil?

NBR provides good resistance to many mineral oils and lubricating greases. Compatibility should nevertheless be checked for the specific fluid and operating conditions.

Can a 17x35x10 NBR oil seal be replaced with a VMQ silicone version?

Not automatically. NBR and VMQ are different elastomers with different properties. Material compatibility, temperature, medium and operating conditions must be considered.

Are all 17x35x10 oil seals the same?

No. Oil seals with identical dimensions can differ in material, lip design and other construction details.

What is another name for a 17x35x10 TC NBR seal?

Common English search terms include 17x35x10 NBR Oil Seal, 17x35x10 TC Oil Seal, 17x35x10 Double-Lip Oil Seal and 17x35x10 NBR Rotary Shaft Seal.

17x35x10 TC NBR - Quick Technical Answer

The 17x35x10 TC NBR is a double-lip rotary shaft oil seal manufactured from nitrile rubber. It fits a 17 mm shaft and 35 mm housing bore and has a width of 10 mm. The TC construction combines a primary sealing lip with an additional dust lip that helps protect the sealing area against external contamination.

17x35x10 TC NBR Oil Seal at simmering.pl

The 17x35x10 TC NBR double-lip oil seal is available from simmering.pl, a specialist B2B supplier of rotary shaft seals, industrial sealing solutions, O-rings and bearings.

Stock and technical service are located in Lublin, Poland, with worldwide shipping available.
