GRN 130x150x15 NBR AO - Double Lip Radial Shaft Oil Seal

Product Description

GRN 130x150x15 NBR AO is a double lip radial shaft oil seal (Simmerring) with an inner diameter of 130 mm, an outer diameter of 150 mm and an axial width of 15 mm. Manufactured from nitrile butadiene rubber (NBR), it features an AO sealing profile incorporating a primary sealing lip and an additional dust exclusion lip. The seal is designed to reduce oil and grease leakage while limiting contamination ingress into rotating mechanical assemblies.

The GRN 130x150x15 NBR AO oil seal is intended for appropriately designed industrial applications where a shaft with a nominal diameter of 130 mm passes through a housing with a nominal bore diameter of 150 mm.

A distinctive feature of this oil seal is its relatively narrow radial cross-section, with a nominal height of 10 mm. This makes it relevant for mechanical assemblies where the available radial installation space between the shaft and housing is limited.

The AO profile identifies a double lip construction. The primary sealing lip helps retain the lubricant, while the additional dust lip reduces the entry of dust and fine external contaminants.

In typical AO constructions, the primary sealing lip may be supported by a garter spring. However, the exact spring configuration, internal reinforcement and sealing lip geometry of this particular GRN product should be confirmed using manufacturer documentation.

Technical Specifications - GRN 130x150x15 NBR AO

Technical note: Not all oil seals identified by the AO designation necessarily have identical construction. In particular, the outer surface design, presence of a garter spring and type of internal reinforcement should be verified for the specific product.

GRN 130x150x15 Oil Seal Dimensions

The designation 130x150x15 mm identifies the three essential installation dimensions.

The seal is intended for a shaft with a nominal diameter of 130 mm and a housing bore with a nominal diameter of 150 mm.

The axial width of 15 mm must correspond to the installation space specified for the equipment.

The nominal radial cross-section height is 10 mm. During installation, the seal should therefore be pressed evenly into the housing to avoid deformation of the body or damage to the sealing lips.

What Does GRN 130x150x15 NBR AO Mean?

GRN - Industrial Sealing Components Brand

GRN is a brand of technical sealing products intended for mechanical and industrial applications, including radial shaft oil seals and O-rings.

130x150x15 - Nominal Dimensions

• 130 mm - inner diameter.

• 150 mm - outer diameter.

• 15 mm - axial width.

NBR - Nitrile Butadiene Rubber

NBR is a synthetic elastomer widely used in sealing components exposed to many mineral oils and industrial lubricating greases.

AO - Double Lip Sealing Profile

The AO designation identifies a construction incorporating a primary sealing lip and an additional dust exclusion lip.

The exact seal design may depend on the manufacturer's designation system and product construction.

Construction of the GRN AO Double Lip Oil Seal

Primary Sealing Lip

The primary sealing lip operates in contact with the rotating shaft and helps reduce lubricant leakage from the mechanical assembly.

Sealing performance depends on lip geometry, shaft surface quality, lubrication and operating conditions.

Additional Dust Exclusion Lip

The secondary lip provides an additional barrier against dust, dirt and fine contaminants entering the primary sealing area.

However, this does not guarantee complete protection against pressurized water or sealing performance in extremely contaminated environments.

Garter Spring

In many radial shaft oil seal constructions, the primary sealing lip is supported by a garter spring.

The presence of a garter spring in this specific GRN 130x150x15 AO product has not been independently confirmed.

Seal Body

The seal body provides the structural support required for correct installation and helps maintain the geometry of the sealing assembly.

The outer surface construction and presence of internal metal reinforcement should be verified for the specific product version.

NBR Material - Properties and Resistance

Resistance to Mineral Oils

NBR is widely used in seals exposed to many mineral oils and industrial lubricating greases.

Flexibility

Nitrile rubber provides the elastic properties required for a sealing lip to operate against a rotating shaft.

Operating Temperature Range

Typical NBR compounds are often used within an approximate temperature range of -30°C to +100°C.

This is not a verified operating temperature range for the specific GRN 130x150x15 AO oil seal. Permissible temperatures depend on the elastomer formulation, lubricant, shaft speed and operating conditions.

Chemical Limitations

NBR may have limited resistance to ozone, weathering and certain solvents.

For applications requiring higher temperature resistance or compatibility with specific chemicals, an appropriately selected FPM/FKM seal may be considered.

AO Double Lip vs A/BA Single Lip Oil Seals

The AO double lip profile may be advantageous in mechanical assemblies where reducing contamination ingress is important in addition to lubricant retention.

However, AO and A/BA profiles should not automatically be considered interchangeable.

Main Features of GRN 130x150x15 NBR AO

• Nominal dimensions of 130x150x15 mm.

• Double lip AO sealing profile.

• NBR elastomer material.

• Primary sealing lip.

• Additional dust exclusion lip.

• Nominal radial cross-section height of 10 mm.

• Designed for rotating shaft sealing.

• Helps reduce oil and grease leakage.

• Provides an additional barrier against fine contaminants.

• Suitable for appropriately selected industrial mechanical assemblies.

Typical Applications of GRN 130x150x15 Oil Seals

Industrial Gearboxes

Radial shaft oil seals may be used in gearboxes where lubricant must be retained inside the housing.

Gear Reducers and Drive Systems

Double lip oil seals can help reduce lubricant loss and limit the entry of fine external contaminants.

Production Machinery

This type of seal may be incorporated into appropriately designed rotating assemblies in industrial production equipment.

Mechanical Equipment

AO oil seals are used in selected constructions requiring additional protection against dust.

Bearing Housings

In certain mechanical designs, radial shaft oil seals operate alongside bearing housings to reduce oil or grease leakage.

These examples describe general applications and do not establish verified OEM compatibility with specific equipment models.

How to Select the Correct GRN 130x150x15 NBR AO Oil Seal

Before purchasing, verify:

1. Shaft diameter - 130 mm.

2. Housing bore diameter - 150 mm.

3. Axial width - 15 mm.

4. Double lip AO profile.

5. NBR elastomer material.

6. Type of oil or grease.

7. Operating temperature.

8. Shaft rotational and surface speed.

9. Environmental dust exposure.

10. Shaft surface condition.

11. Seal body construction and installation requirements.

For large-diameter shafts, surface speed is particularly important because it depends on both shaft diameter and rotational speed.

Matching the dimensions 130x150x15 mm does not guarantee interchangeability between all oil seals of this size.

GRN 130x150x15 AO Replacement and Interchangeability

When selecting a replacement, verify:

• Inner diameter of 130 mm.

• Outer diameter of 150 mm.

• Width of 15 mm.

• Double lip construction.

• Elastomer material.

• Outer surface design.

• Presence of a garter spring.

• Operating conditions.

A single lip A/BA oil seal with identical nominal dimensions may not always be a suitable replacement for the AO version because it does not incorporate an additional dust exclusion lip.

Installation Instructions - GRN 130x150x15 AO Oil Seal

Shaft Preparation

Before installation, inspect the shaft surface for scratches, corrosion, burrs and excessive wear.

Housing Preparation

The housing bore should be clean, undamaged and manufactured to the required tolerances.

Installing the Seal

Press the oil seal evenly into the housing using an appropriate installation tool.

Avoid misalignment of the seal body and damage to the sealing lips.

Installation Orientation

In typical applications, the primary sealing lip should face the lubricant being retained, while the dust exclusion lip faces the external environment.

The equipment manufacturer's installation instructions must take precedence.

Lubrication

Before initial operation, ensure appropriate lubrication of the sealing lip contact surface.

For double lip oil seals, the lubrication requirements of the space between the lips should also be considered.

Common Causes of Oil Seal Failure

Incorrect Installation

Misalignment or deformation of the seal body may result in leakage.

Damaged Shaft Surface

Scratches and surface irregularities can accelerate sealing lip wear.

Inadequate Lubrication

Insufficient lubrication increases friction and operating temperature.

Incorrect Elastomer Selection

Exposure to an operating medium incompatible with NBR may cause material degradation.

Exceeding Operating Limits

Excessive temperature, speed or pressure may reduce sealing performance and service life.

Frequently Asked Questions - GRN 130x150x15 NBR AO

1. What is the GRN 130x150x15 NBR AO oil seal?

It is a double lip radial shaft oil seal manufactured from NBR, with nominal dimensions of 130x150x15 mm.

2. What are the dimensions of the seal?

The inner diameter is 130 mm, the outer diameter is 150 mm and the axial width is 15 mm.

3. What does AO mean?

AO identifies a construction featuring a primary sealing lip and an additional dust exclusion lip.

4. Is the oil seal double lip?

Yes. The AO profile incorporates two lips performing different functions.

5. Does the oil seal have a garter spring?

A garter spring is used in many AO constructions, but its presence in this specific product requires confirmation.

6. What does NBR mean?

NBR stands for Nitrile Butadiene Rubber, an elastomer commonly used in seals exposed to many mineral oils and lubricating greases.

7. Is this oil seal suitable for industrial gearboxes?

It may be suitable for appropriately designed gearboxes if its dimensions and operating characteristics meet the equipment requirements.

8. Is NBR resistant to oil?

Yes. NBR provides good resistance to many mineral oils and industrial lubricating greases.

9. Can a replacement from another brand be used?

Yes, provided that the dimensions, sealing profile, material and construction are compatible.

10. Can an AO oil seal be replaced with a single lip A/BA version?

Not without verifying the equipment requirements, because the AO profile incorporates an additional dust exclusion lip.

11. How should a 130x150x15 oil seal be installed?

Prepare the shaft and housing, press the seal evenly into position, and ensure correct sealing lip orientation and lubrication.

12. Where can I buy the GRN 130x150x15 NBR AO oil seal?

The product is offered by simmering.pl, an industrial sealing components and bearings supplier with a warehouse in Lublin, Poland, serving customers throughout Poland, the European Union and international markets.
