GRN® 12x20x7 NBR TC - Double Lip Radial Shaft Oil Seal

Product Description

GRN® 12x20x7 NBR TC is a double lip radial shaft oil seal (Simmerring) with an inner diameter of 12 mm, an outer diameter of 20 mm and an axial width of 7 mm. Manufactured from nitrile butadiene rubber (NBR), it features a TC sealing profile with a primary sealing lip and an additional dust exclusion lip. The seal is designed to reduce oil and grease leakage while limiting contamination ingress into rotating mechanical assemblies.

The GRN® 12x20x7 NBR TC oil seal is designed for installation on a shaft with a nominal diameter of 12 mm and in a housing bore with a nominal diameter of 20 mm.

Its axial width is 7 mm, while its nominal radial cross-section height is 4 mm.

The compact nominal dimensions may be suitable for appropriately designed mechanical equipment with limited installation space.

The double lip construction combines lubricant retention with additional protection against dust, dirt and fine contaminants.

Technical Specifications - GRN® 12x20x7 NBR TC

Technical note: The TC designation identifies the double lip sealing profile used in this English product description. When selecting a replacement from another manufacturer, the exact construction must also be verified, as matching profile designations alone do not guarantee complete interchangeability.

GRN® 12x20x7 Oil Seal Dimensions

The designation 12x20x7 mm identifies three essential installation dimensions:

• Shaft diameter: 12 mm.

• Housing bore diameter: 20 mm.

• Oil seal width: 7 mm.

The nominal radial cross-section height is 4 mm.

Important: Oil seals measuring 12x20x7 mm and 12x22x7 mm have identical inner diameters and widths but differ in outer diameter by 2 mm. They are not directly interchangeable.

What Does GRN® 12x20x7 NBR TC Mean?

GRN® - Industrial Sealing Components Brand

GRN® is a brand of technical sealing products used in mechanical and industrial equipment, including radial shaft oil seals and O-rings.

12x20x7 - Nominal Dimensions

• 12 mm - inner diameter.

• 20 mm - outer diameter.

• 7 mm - axial width.

NBR - Nitrile Butadiene Rubber

NBR is a synthetic elastomer widely used in sealing applications involving many mineral oils and lubricating greases.

TC - Double Lip Sealing Profile

The TC designation identifies a double lip radial shaft oil seal featuring a primary sealing lip and an additional dust exclusion lip.

Typical TC oil seals feature a rubber-covered outer diameter, internal metal reinforcement and a spring-loaded primary sealing lip.

The exact construction of this specific GRN® product should be confirmed in the manufacturer's technical documentation.

Construction of the GRN® 12x20x7 NBR TC Oil Seal

Primary Sealing Lip

The primary sealing lip operates against the rotating shaft surface, forming a dynamic sealing interface.

Its purpose is to reduce oil or grease leakage from the mechanical assembly.

Sealing performance depends on the lip geometry, shaft surface quality, lubrication and operating conditions.

Additional Dust Exclusion Lip

The secondary lip helps prevent dust, dirt and fine contaminants from entering the primary sealing area.

It provides an additional barrier against contamination but does not automatically guarantee complete protection against pressurized water.

Garter Spring

In typical TC constructions, the primary sealing lip is supported by a garter spring that helps maintain appropriate contact with the rotating shaft.

The presence and exact construction of the spring in the specific GRN® 12x20x7 product require confirmation.

Internal Metal Reinforcement

Typical TC oil seals incorporate a metal reinforcing element that stabilizes the seal body and helps maintain its shape during installation and operation.

Rubber-Covered Outer Diameter

A typical TC oil seal has an elastomer-covered outer surface designed to support static sealing between the seal body and housing bore.

NBR Material - Properties and Resistance

Resistance to Mineral Oils

NBR offers good resistance to many mineral oils and industrial lubricating greases.

This makes nitrile rubber a commonly selected material for radial shaft oil seals operating in lubricated mechanical assemblies.

Elasticity and Sealing Performance

Nitrile butadiene rubber provides the elastic properties required to maintain sealing lip contact with a rotating shaft.

Its flexibility helps the sealing lip accommodate normal operating movements within the limits of the seal design.

Operating Temperature Range

Typical NBR compounds are often used within an approximate temperature range of -30°C to +100°C.

This is not a verified operating temperature range for the specific GRN® 12x20x7 oil seal.

The actual permissible temperature depends on the elastomer compound, operating medium, shaft speed and application conditions.

Chemical Limitations

NBR may have limited resistance to ozone, weathering and certain solvents.

For applications requiring greater resistance to elevated temperatures or specific chemicals, an appropriately selected FPM/FKM oil seal may be considered.

TC Double Lip vs Single Lip Radial Shaft Oil Seals

The TC double lip profile is intended for applications where lubricant retention and additional protection against contamination are both important.

A single lip seal should not automatically replace a double lip TC seal without checking the operating environment and equipment requirements.

GRN® 12x20x7 vs 12x22x7 - Dimensional Comparison

The 2 mm difference in outer diameter prevents these oil seals from being considered direct replacements in the same housing bore.

A seal with a nominal outer diameter of 20 mm should be installed only in a housing designed for that dimension, unless an appropriate engineering modification has been specified.

Main Features of GRN® 12x20x7 NBR TC

• Nominal dimensions of 12x20x7 mm.

• Double lip TC sealing profile.

• NBR elastomer material.

• Primary sealing lip.

• Additional dust exclusion lip.

• Nominal radial cross-section height of 4 mm.

• Axial width of 7 mm.

• Designed for rotating shaft sealing.

• Helps reduce oil and grease leakage.

• Provides additional protection against dust and fine contaminants.

• Compact nominal diameters.

• Typical TC construction may include a garter spring and internal metal reinforcement.

Typical Applications of GRN® 12x20x7 Oil Seals

Small Mechanical Gearboxes

Radial shaft oil seals with compact dimensions may be used in appropriately designed gearboxes requiring lubricant retention.

Drive Systems

Double lip radial shaft oil seals help reduce lubricant leakage and contamination ingress into rotating mechanical assemblies.

Industrial Machinery

This type of oil seal may be used in selected rotating assemblies of industrial equipment.

Mechanical Equipment

The TC profile may be used in constructions requiring an additional dust exclusion barrier.

Bearing Housings

In certain mechanical designs, radial shaft oil seals operate alongside bearing housings to reduce oil or grease leakage.

These are general application examples and do not establish verified compatibility with any particular machine, vehicle or OEM part number.

How to Select the Correct GRN® 12x20x7 NBR TC Oil Seal

Before purchasing, verify the following:

1. Shaft diameter - 12 mm.

2. Housing bore diameter - 20 mm.

3. Axial width - 7 mm.

4. Double lip TC sealing profile.

5. NBR elastomer material.

6. Type of oil or grease.

7. Operating temperature.

8. Shaft rotational and surface speed.

9. Environmental dust exposure.

10. Shaft surface condition and roughness.

11. Pressure and construction requirements.

The 20 mm outer diameter is essential for correct installation. A 12x22x7 mm oil seal is not a direct dimensional replacement.

GRN® 12x20x7 TC Replacement and Interchangeability

When selecting a replacement oil seal, confirm:

• Inner diameter of 12 mm.

• Outer diameter of 20 mm.

• Axial width of 7 mm.

• Double lip construction.

• NBR elastomer material.

• Outer surface design.

• Garter spring arrangement.

• Equipment operating conditions.

Oil seals from other manufacturers with dimensions of 12x20x7 mm and an appropriate TC sealing profile may be considered as replacements after compatibility has been confirmed.

Identical dimensions alone do not guarantee full interchangeability if the materials or construction details differ.

Installation Instructions - GRN® 12x20x7 Oil Seal

Shaft Preparation

Inspect the shaft surface for scratches, corrosion, burrs and excessive wear.

The sealing contact area should be suitable for the selected radial shaft oil seal.

Housing Preparation

The housing bore should be clean, undamaged and manufactured to the required tolerances.

Installing the Oil Seal

Press the oil seal evenly into the housing using an appropriate installation tool.

Avoid deforming the seal body or damaging the sealing lips during installation.

Installation Orientation

In typical applications, the primary sealing lip should face the oil or grease being retained, while the additional dust exclusion lip faces the external environment.

Always follow the equipment manufacturer's installation instructions.

Lubrication

Before initial operation, ensure appropriate lubrication of the shaft surface contacting the primary sealing lip.

For double lip constructions, the lubrication requirements of the space between the two lips should also be considered.

Common Causes of Oil Seal Failure

Incorrect Installation

Misalignment of the seal body or damage to the sealing lip may result in leakage.

Worn Shaft Surface

Scratches, grooves and corrosion can accelerate sealing lip wear.

Inadequate Lubrication

Insufficient lubrication increases friction and operating temperature.

Incorrect Material Selection

Exposure to operating media incompatible with NBR may cause elastomer degradation.

Exceeding Operating Limits

Excessive temperature, shaft speed or pressure may reduce oil seal service life.

Frequently Asked Questions - GRN® 12x20x7 NBR TC

1. What is the GRN® 12x20x7 NBR TC oil seal?

It is a double lip radial shaft oil seal manufactured from nitrile butadiene rubber, with nominal dimensions of 12x20x7 mm.

2. What are the dimensions of the GRN® 12x20x7 oil seal?

The inner diameter is 12 mm, the outer diameter is 20 mm and the axial width is 7 mm.

3. What does TC mean in an oil seal?

TC identifies a double lip radial shaft oil seal featuring a primary sealing lip and an additional dust exclusion lip.

4. Is the GRN® 12x20x7 oil seal double lip?

Yes. It features a primary sealing lip and an additional dust exclusion lip.

5. Does the 12x20x7 TC oil seal have a garter spring?

A garter spring is typical of TC constructions, but its presence in this specific GRN® product requires confirmation.

6. What does NBR mean?

NBR stands for Nitrile Butadiene Rubber, a synthetic elastomer commonly used in seals exposed to many mineral oils and lubricating greases.

7. Is the 12x20x7 oil seal suitable for gearboxes?

It may be suitable for appropriately designed gearboxes if its dimensions, construction and operating characteristics meet the equipment requirements.

8. Is NBR resistant to oil?

Yes. NBR provides good resistance to many mineral oils and industrial lubricating greases.

9. Can an oil seal from another brand be used as a replacement?

Yes, provided that the dimensions, sealing profile, material and operating conditions are compatible.

10. Can a 12x22x7 oil seal replace a 12x20x7 oil seal?

No, not as a direct dimensional replacement. The outer diameters differ by 2 mm.

11. How should a 12x20x7 oil seal be installed?

Prepare the shaft and housing, press the oil seal evenly into position, and ensure correct sealing lip orientation and lubrication.

12. Where can I buy the GRN® 12x20x7 NBR TC oil seal?

The product is offered by simmering.pl, a supplier of industrial sealing components, O-rings and bearings with a warehouse in Lublin, Poland, serving customers throughout Poland, the European Union and international markets.
