GRN® 12x26x7 NBR AO/TC - Double Lip Radial Shaft Oil Seal

Product Description

GRN® 12x26x7 NBR AO/TC is a double lip radial shaft oil seal (Simmerring) with an inner diameter of 12 mm, an outer diameter of 26 mm and an axial width of 7 mm. Manufactured from nitrile butadiene rubber (NBR), it features an AO/TC sealing profile with a primary sealing lip and an additional dust exclusion lip. The seal is designed to reduce oil and grease leakage while limiting contamination ingress into rotating mechanical assemblies.

The GRN® 12x26x7 NBR AO/TC oil seal is intended for a shaft with a nominal diameter of 12 mm and a housing bore with a nominal diameter of 26 mm.

Its axial width is 7 mm, while its nominal radial cross-section height is 7 mm.

The double lip construction combines dynamic shaft sealing with additional protection against dust, dirt and fine contaminants.

The TC profile is a widely used designation for a double lip radial shaft oil seal, typically featuring a rubber-covered outer diameter, internal metal reinforcement and a spring-loaded primary sealing lip.

The exact construction of this specific GRN® product should be confirmed in the manufacturer's technical documentation.

Technical Specifications - GRN® 12x26x7 NBR AO/TC

Technical note: AO and TC designations may refer to similar double lip constructions, but their exact specifications can vary between manufacturers. When selecting a replacement, the dimensions, material, seal body construction and sealing lip arrangement must be verified.

GRN® 12x26x7 Oil Seal Dimensions

The designation 12x26x7 mm identifies the essential installation dimensions:

• Shaft diameter: 12 mm.

• Housing bore diameter: 26 mm.

• Oil seal width: 7 mm.

The nominal radial cross-section height is 7 mm.

Important: Oil seals measuring 12x26x7 mm and 12x27x7 mm have identical inner diameters and widths but differ in outer diameter by 1 mm. They should not automatically be considered interchangeable.

What Does GRN® 12x26x7 NBR AO/TC Mean?

GRN® - Industrial Sealing Components Brand

GRN® is a brand of technical sealing products used in mechanical and industrial equipment, including radial shaft oil seals and O-rings.

12x26x7 - Nominal Dimensions

• 12 mm - inner diameter.

• 26 mm - outer diameter.

• 7 mm - axial width.

NBR - Nitrile Butadiene Rubber

NBR is a synthetic elastomer commonly used in seals exposed to many mineral oils and lubricating greases.

AO - Double Lip Sealing Profile

AO identifies a construction featuring a primary sealing lip and an additional dust exclusion lip.

TC - Double Lip Radial Shaft Oil Seal

TC is a common designation for a double lip radial shaft oil seal, typically featuring a rubber-covered outer diameter and a spring-loaded primary sealing lip.

AO and TC may describe similar sealing arrangements, but full interchangeability requires verification.

Construction of the GRN® AO/TC Oil Seal

Primary Sealing Lip

The primary sealing lip operates against the rotating shaft surface and is responsible for reducing oil or grease leakage.

Sealing performance depends on sealing lip geometry, shaft surface quality, lubrication and operating conditions.

Additional Dust Exclusion Lip

The secondary lip limits dust, dirt and fine contaminants from entering the primary sealing area.

However, it does not automatically guarantee complete protection against pressurized water or extremely contaminated environments.

Garter Spring

In typical TC constructions, the primary sealing lip is supported by a garter spring that helps maintain appropriate contact with the shaft surface.

The presence of a spring in the specific GRN® 12x26x7 oil seal requires confirmation.

Internal Metal Reinforcement

Typical TC oil seals incorporate an internal metal reinforcing element that stabilizes the seal body and helps ensure correct positioning within the housing.

Rubber-Covered Outer Diameter

In a typical TC profile, the outer surface is covered with elastomer to help provide static sealing between the seal body and housing bore.

NBR Material - Properties and Resistance

Resistance to Mineral Oils

NBR is widely used in seals operating with many mineral oils and industrial lubricating greases.

Flexibility

Nitrile rubber provides the elastic properties required to maintain contact between the sealing lip and the rotating shaft.

Operating Temperature Range

Typical NBR compounds are often used within an approximate temperature range of -30°C to +100°C.

This is not a verified operating temperature range for the specific GRN® 12x26x7 product. Permissible conditions depend on the elastomer compound, operating medium, speed and application.

Chemical Limitations

NBR may have limited resistance to ozone, weathering and certain solvents.

For applications involving elevated temperatures or specific chemical requirements, an appropriately selected FPM/FKM oil seal may be considered.

AO/TC vs A/BA - Construction Comparison

The AO/TC profile may be suitable for mechanical assemblies where both lubricant retention and protection against contamination are important.

GRN® 12x26x7 vs GRN® 12x27x7 - Differences

The 1 mm difference in outer diameter is important for correct installation within the housing bore.

An oil seal with a 26 mm outer diameter should not be installed in a housing designed for a 27 mm seal without an appropriate engineering solution.

Likewise, a 27 mm oil seal should not be forced into a housing designed for a nominal outer diameter of 26 mm.

Main Features of GRN® 12x26x7 NBR AO/TC

• Nominal dimensions of 12x26x7 mm.

• Double lip AO/TC sealing profile.

• NBR elastomer material.

• Primary sealing lip.

• Additional dust exclusion lip.

• Garter spring typical of TC construction.

• Typically rubber-covered outer diameter.

• Typically internal metal reinforcement.

• Nominal radial cross-section height of 7 mm.

• Axial width of 7 mm.

• Designed for rotating shaft sealing.

• Helps reduce oil and grease leakage.

• Provides additional protection against dust and fine contaminants.

Typical Applications of GRN® 12x26x7 Oil Seals

Small Mechanical Gearboxes

Radial shaft oil seals may be used in appropriately designed gearboxes requiring oil retention.

Gear Reducers and Drive Systems

Double lip oil seals help reduce lubricant leakage and contamination ingress into mechanical assemblies.

Industrial Machinery

This type of seal may be used in selected rotating assemblies of production machinery.

Mechanical Equipment

The AO/TC profile may be used in constructions requiring an additional dust exclusion barrier.

Bearing Housings

In certain designs, radial shaft oil seals operate alongside bearing housings to reduce oil or grease leakage.

These applications are general examples and do not establish verified compatibility with any specific equipment.

How to Select the Correct GRN® 12x26x7 NBR AO/TC Oil Seal

Before purchasing, verify:

1. Shaft diameter - 12 mm.

2. Housing bore diameter - 26 mm.

3. Axial width - 7 mm.

4. Double lip AO/TC profile.

5. NBR elastomer material.

6. Type of oil or grease.

7. Operating temperature.

8. Shaft rotational and surface speed.

9. Environmental dust exposure.

10. Shaft surface condition and roughness.

11. Pressure and construction requirements.

The 26 mm outer diameter is particularly important. A 12x27x7 mm oil seal is not automatically a suitable replacement.

GRN® 12x26x7 AO/TC Replacement and Interchangeability

When selecting a replacement, confirm:

• Inner diameter of 12 mm.

• Outer diameter of 26 mm.

• Width of 7 mm.

• Double lip construction.

• NBR elastomer material.

• Outer surface design.

• Presence of a garter spring.

• Equipment operating conditions.

Oil seals from other manufacturers with dimensions of 12x26x7 mm and an appropriate double lip profile may be considered as alternatives after compatibility has been confirmed.

A 12x27x7 mm oil seal is not automatically interchangeable with the 12x26x7 mm version.

Installation Instructions - GRN® 12x26x7 Oil Seal

Shaft Preparation

Inspect the shaft surface for scratches, corrosion, burrs and wear.

Housing Preparation

The housing bore should be clean, undamaged and manufactured to the required tolerances.

Installing the Seal

Press the oil seal evenly into the housing using an appropriate installation tool.

Avoid direct impact on the sealing lips or deformation of the seal body.

Installation Orientation

In typical applications, the primary sealing lip should face the oil or grease being retained, while the dust exclusion lip faces the external environment.

Always follow the equipment manufacturer's installation instructions.

Lubrication

Before initial operation, ensure appropriate lubrication of the surface contacting the primary sealing lip.

For double lip constructions, the lubrication requirements of the space between the lips should also be considered.

Common Causes of Oil Seal Failure

Incorrect Installation

Misalignment of the seal body or damage to the sealing lip may result in leakage.

Worn Shaft Surface

Scratches, grooves and corrosion accelerate sealing lip wear.

Inadequate Lubrication

Insufficient lubrication increases friction and operating temperature.

Incorrect Material Selection

Exposure to an operating medium incompatible with NBR may cause elastomer degradation.

Exceeding Operating Limits

Excessive temperature, speed or pressure may reduce the service life of the oil seal.

Frequently Asked Questions - GRN® 12x26x7 NBR AO/TC

1. What is the GRN® 12x26x7 NBR AO/TC oil seal?

It is a double lip radial shaft oil seal manufactured from NBR, with nominal dimensions of 12x26x7 mm.

2. What are the dimensions of the GRN® 12x26x7 oil seal?

The inner diameter is 12 mm, the outer diameter is 26 mm and the axial width is 7 mm.

3. What does AO/TC mean?

AO/TC identifies a double lip construction featuring a primary sealing lip and an additional dust exclusion lip.

4. Is the GRN® 12x26x7 oil seal double lip?

Yes. It features a primary sealing lip and an additional dust exclusion lip.

5. Does the 12x26x7 oil seal have a garter spring?

A garter spring is typical of TC constructions, but its presence in this specific product requires confirmation.

6. What does NBR mean?

NBR stands for Nitrile Butadiene Rubber, a material commonly used in seals exposed to many mineral oils and lubricating greases.

7. Is the 12x26x7 oil seal suitable for gearboxes?

It may be suitable for appropriately designed gearboxes if its construction and operating characteristics meet the equipment requirements.

8. Is NBR resistant to oil?

Yes. NBR provides good resistance to many mineral oils and industrial lubricating greases.

9. Can an oil seal from another brand be used as a replacement?

Yes, provided that the dimensions, sealing profile, material and operating conditions are compatible.

10. Can a 12x27x7 oil seal replace a 12x26x7 oil seal?

Interchangeability should not be assumed. The 1 mm difference in outer diameter is important for correct installation.

11. How should a 12x26x7 oil seal be installed?

Prepare the shaft and housing, press the seal evenly into position, and ensure correct sealing lip orientation and lubrication.

12. Where can I buy the GRN® 12x26x7 NBR AO/TC oil seal?

The product is offered by simmering.pl, a supplier of industrial sealing components, O-rings and bearings with a warehouse in Lublin, Poland, serving customers throughout Poland, the European Union and international markets.
