Bearing Ball 13.000 mm

Technical Specifications

The dimension 13.000 mm identifies the nominal diameter. Three decimal places do not automatically establish a manufacturing tolerance of 0.001 mm.

Product Designation and Identification

The designation identifies the rolling element type and nominal diameter but does not specify the material, hardness, or precision grade.

These parameters must be verified before using the ball in applications requiring controlled dimensional accuracy.

Construction and Operating Principle

Bearing Ball 13.000 mm has a spherical geometry that enables rolling contact between appropriately designed mating surfaces.

In ball bearings, rolling elements transmit loads between the inner and outer ring raceways while allowing relative rotational movement.

The direction and magnitude of transmitted loads depend on the bearing design, raceway geometry, and operating conditions.

The technical performance of a bearing ball depends on:

• Actual diameter and dimensional tolerance.

• Sphericity and geometric accuracy.

• Surface roughness and finish.

• Material composition.

• Hardness and wear resistance.

• Operating loads and lubrication conditions.

Identical nominal diameters do not automatically guarantee complete interchangeability between rolling elements.

Bearing Ball 13.000 mm vs Imperial Dimensions

The nominal diameter of 13.000 mm corresponds to approximately 0.51181 inch.

It is not dimensionally identical to a 1/2-inch bearing ball.

The difference of 0.300 mm may significantly affect bearing internal clearance, contact geometry, and load distribution.

Bearing balls measuring 13.000 mm and 1/2 inch are not direct dimensional substitutes.

Material and Manufacturing Accuracy

The material of this bearing ball has not been specified.

Depending on the application, bearing balls may be manufactured from bearing steel, stainless steel, or engineering ceramics.

A particular material, steel grade, hardness, or precision classification must not be assigned without supporting product documentation.

For precision applications, verify:

• Material composition.

• Diameter tolerance.

• Deviation from spherical form.

• Surface roughness.

• Hardness.

• Dimensional consistency within the supplied batch.

The required characteristics depend on the mechanical assembly and its operating conditions.

Bearing Selection and Interchangeability

Before purchasing Bearing Ball 13.000 mm, verify the technical requirements of the application.

Important selection criteria include:

• Nominal diameter: 13.000 mm.

• Diameter tolerance: Compliance with the required specification.

• Material: Compatibility with operating conditions.

• Precision grade: Appropriate dimensional and geometric accuracy.

• Hardness: Suitability for contact loads and mating surfaces.

• Surface quality: Absence of scratches, dents, corrosion, and other defects.

• Operating loads: Compatibility with the mechanical assembly.

• Operating temperature: Suitability for the application.

• Lubrication: Appropriate for the bearing or mechanism.

When replacing balls in an existing bearing, assess the condition of the raceways, cage, and remaining rolling elements.

Replacing an individual ball without checking the complete assembly may result in uneven load distribution.

Applications of Bearing Ball 13.000 mm

Bearing balls with a nominal diameter of 13 mm may be used in mechanical assemblies specifically designed for spherical rolling elements of this size.

Typical application categories include:

• Ball bearings designed for 13 mm rolling elements.

• Industrial rolling mechanisms.

• Mechanical guiding systems.

• Ball-based positioning mechanisms.

• Other engineered assemblies incorporating spherical rolling elements.

These are general application categories based on the geometry and function of bearing balls.

They do not establish confirmed compatibility with a particular bearing model, machine, gearbox, or OEM assembly.

Suitability must be verified against the technical requirements of the application.

Alternative Designations and Reference Formats

Natural reference formats include:

• Bearing Ball 13.000 mm

• 13 mm Bearing Ball

• Ball for Bearings 13 mm

• Bearing Ball 13.000 mm - 100 pcs.

These are alternative descriptive formats, not confirmed manufacturer or OEM part numbers.

No unverified manufacturer references, material grades, or precision classifications have been assigned.

Handling, Installation and Storage

Before installation, inspect the bearing ball and all mating surfaces for contamination, damage, or corrosion.

Do not use balls with visible dents, scratches, deformation, or surface defects.

Protect the rolling elements against moisture, abrasive particles, and mechanical damage.

When assembling a bearing, ensure that all balls meet the required dimensional and material specifications.

Use the lubricant recommended for the complete mechanical assembly.

Store the balls in clean, dry conditions, preferably in their original packaging.

Frequently Asked Questions - FAQ

What is the diameter of Bearing Ball 13.000 mm?

The nominal diameter is 13 mm. The actual diameter and permissible deviations depend on the specified manufacturing tolerance.

Is a 13 mm bearing ball equivalent to 1/2 inch?

No. A 1/2-inch bearing ball has a nominal diameter of 12.700 mm. The difference is 0.300 mm.

What material is the bearing ball made from?

The material has not been specified. It must be confirmed against the technical specification of the particular product.

Does 13.000 mm mean the ball is accurate to 0.001 mm?

No. The number of decimal places in the nominal dimension does not establish the manufacturing tolerance.

Does the ball have a specified precision grade?

No precision grade has been provided. It must be verified before using the ball in a precision mechanical assembly.

Can a 13 mm bearing ball be used to repair an existing bearing?

Only if its diameter, material, hardness, precision grade, and other characteristics match the bearing requirements.

Can a 13 mm ball replace a 12.7 mm ball?

Not automatically. The nominal diameter difference is 0.300 mm and may prevent correct operation of the mechanical assembly.

How many bearing balls are included in one package?

Each package contains 100 bearing balls with a nominal diameter of 13.000 mm.

Bearing Ball 13.000 mm - Key Technical Information

Bearing Ball 13.000 mm is a spherical rolling element with a nominal diameter of 13 mm, supplied in packages of 100 pieces. It is intended for compatible ball bearings and mechanical rolling assemblies. It is not dimensionally identical to a 1/2-inch ball. Correct selection requires verification of material, precision grade, hardness, and dimensional tolerance.
