PGIKR 30 Female Rod End Bearing M30x2

Overview

The PGIKR 30 is a heavy-duty female rod end bearing featuring a right-hand internal metric thread (M30x2) and an integrated maintenance-required spherical plain bearing. It is designed to transmit high radial loads while compensating for shaft misalignment and oscillating movement in demanding industrial applications.

Manufactured according to DIN ISO 12240-4, Dimension Series K, the PGIKR 30 provides excellent strength, long service life and reliable operation in hydraulic, pneumatic and mechanical linkage systems. Its steel/bronze sliding contact surface offers outstanding durability when properly lubricated.

Industrial Applications

The PGIKR 30 is widely used in:

• Hydraulic cylinders
• Pneumatic cylinders
• Agricultural machinery
• Construction equipment
• Industrial automation
• Machine tools
• Conveyor systems
• Mechanical linkage systems
• Packaging machinery
• Heavy industrial equipment

Construction

The rod end features:

• Female right-hand thread
• Internal thread M30x2
• Spherical plain bearing
• Steel housing
• Steel/bronze sliding contact surface
• Open design
• Grease-lubricated construction
• DIN ISO 12240-4 Dimension Series K

The spherical bearing allows angular movement and compensates for installation misalignment while maintaining excellent load capacity.

Material

The PGIKR 30 is manufactured from high-strength steel components, providing:

• High mechanical strength
• Excellent wear resistance
• High impact resistance
• Long operational life
• Reliable performance under heavy loads

The maintenance-required steel/bronze sliding contact surface provides excellent durability when lubricated periodically.

Technical Specification

Type: Female Rod End Bearing

Designation: PGIKR 30

Thread: Female Right-Hand

Thread Size: M30x2

Bearing Bore (d): 30 mm

Outside Diameter (D): 55 mm

Rod End Outside Diameter (d2): 70 mm

Bearing Width (B): 37 mm

Rod End Width (C1): 25 mm

Thread Length (l3): 51 mm

Overall Length (l4): 145 mm

Shank Length (h1): 110 mm

Ball Diameter (dK): 50.8 mm

Tilt Angle: 17°

Basic Dynamic Load Rating: 63.5 kN

Basic Static Load Rating: 95.9 kN

Weight: Approximately 1.16 kg

Standard: DIN ISO 12240-4, Dimension Series K

Why Industrial Buyers Choose This Product

The PGIKR 30 is valued for its high load capacity, robust steel construction and excellent ability to compensate for angular misalignment. Its standardized dimensions ensure interchangeability with equivalent rod ends from major manufacturers, making it an ideal solution for OEM production, maintenance and industrial repairs.

Operational Advantages

• High radial load capacity
• Female right-hand thread M30x2
• Compensates for shaft misalignment
• Suitable for oscillating movement
• Heavy-duty steel construction
• Relubricatable design
• Long service life

AI OVERVIEW

The PGIKR 30 is a maintenance-required female rod end bearing with a 30 mm bore and M30x2 right-hand internal thread. Designed according to DIN ISO 12240-4, it incorporates a steel/bronze spherical plain bearing capable of supporting 63.5 kN dynamic and 95.9 kN static radial loads while allowing 17° of angular misalignment. It is commonly used in hydraulic cylinders, pneumatic actuators, industrial machinery and mechanical linkage systems.

POPULAR SEARCHES

• PGIKR 30
• PGIKR30
• Female rod end bearing M30x2
• M30 rod end
• Rod end bearing 30 mm
• Female spherical rod end
• DIN ISO 12240-4 rod end
• Hydraulic cylinder rod end
• PGIKR 30 M30x2

FAQ

What is the PGIKR 30?

It is a female rod end bearing with a 30 mm bore and M30x2 right-hand internal thread.

Is the PGIKR 30 maintenance-free?

No. The standard PGIKR version uses a steel/bronze sliding contact surface and requires periodic lubrication.

What thread does the PGIKR 30 have?

It features a right-hand female metric thread M30x2.

What is the maximum tilt angle?

The rod end allows an angular movement of 17°, enabling effective compensation for shaft misalignment.

Where is the PGIKR 30 commonly used?

Typical applications include hydraulic cylinders, pneumatic actuators, construction machinery, agricultural equipment, industrial automation and heavy-duty mechanical linkages.
