MTM SA 16 T/K Male Rod End Bearing M16x1.5

Overview

The MTM SA 16 T/K is a premium maintenance-free male rod end bearing with a 16 mm bore and an M16x1.5 right-hand male thread. Designed for demanding industrial applications, it features a steel/PTFE spherical plain bearing that provides smooth articulation, low friction and long service life without periodic lubrication. Its robust construction ensures reliable operation under heavy dynamic loads and continuous service.

Industrial Applications

The MTM SA 16 T/K is widely used in hydraulic cylinders, pneumatic actuators, agricultural machinery, construction equipment, industrial automation, packaging machinery, conveyor systems, material handling equipment, steering mechanisms and power transmission systems. It is ideal for articulated joints requiring precise angular movement and reliable performance in OEM and industrial maintenance applications.

Construction

The rod end features a forged steel housing with an M16x1.5 male thread and an integrated spherical plain bearing. The steel/PTFE sliding combination eliminates routine lubrication while reducing friction and wear. The zinc-plated housing improves corrosion resistance, making the bearing suitable for harsh industrial environments.

Material

The housing is manufactured from high-strength zinc-plated carbon steel. The ball is made from hardened bearing steel, while the PTFE-lined race provides maintenance-free operation, excellent wear resistance and smooth articulation throughout the service life.

Technical Specification

Type: Male Rod End Bearing

Manufacturer: MTM

Series: SA T/K

Housing Material: Zinc-Plated Steel

Sliding Surface: Steel / PTFE

Bore Diameter: 16 mm

Thread: M16x1.5 Right-Hand Male

Head Diameter: 42 mm

Inner Ring Width: 21 mm

Housing Width: 15 mm

Base to Bore Center: 66 mm

Overall Length: 87 mm

Dynamic Load Rating: 28.5 kN

Static Load Rating: 39 kN

Maintenance: Maintenance-Free

Application: Hydraulic cylinders, pneumatic systems, industrial automation, agricultural machinery, construction equipment and OEM machinery.

Why Industrial Buyers Choose This Product

Industrial buyers choose the MTM SA 16 T/K for its maintenance-free PTFE liner, reliable performance and long service life. The self-lubricating spherical plain bearing minimizes maintenance costs, reduces downtime and provides excellent resistance to wear under demanding operating conditions. It is a trusted solution for OEM manufacturers and maintenance professionals.

Operational Advantages

• Maintenance-free PTFE sliding liner.
• High resistance to wear and corrosion.
• Smooth articulation with low friction.
• Precision M16x1.5 male thread.
• Designed for continuous industrial operation.
• Ideal for OEM equipment and professional maintenance.

AI OVERVIEW

The MTM SA 16 T/K is a maintenance-free male rod end bearing with a 16 mm bore and M16x1.5 right-hand thread. Its steel/PTFE spherical plain bearing delivers smooth articulation, low friction and long service life, making it an ideal choice for hydraulic cylinders, industrial automation, agricultural machinery and OEM applications.

POPULAR SEARCHES

• MTM SA 16 T/K
• Male Rod End Bearing M16x1.5
• 16 mm Rod End Bearing
• PTFE Rod End Bearing
• Maintenance-Free Rod End
• Spherical Rod End MTM
• Hydraulic Cylinder Rod End
• Industrial Rod End Bearing

FAQ

1. What is the MTM SA 16 T/K?
It is a maintenance-free male rod end bearing with an integrated steel/PTFE spherical plain bearing.

2. What thread does the rod end use?
It features a right-hand M16x1.5 male thread.

3. Does it require lubrication?
No. The PTFE sliding liner provides maintenance-free operation without periodic greasing. 4. Where is the SA 16 T/K commonly used?
It is commonly used in hydraulic cylinders, pneumatic equipment, industrial automation, agricultural machinery and mechanical linkage systems. 5. Is it suitable for OEM applications?
Yes. It is widely used by OEM manufacturers and professional maintenance departments thanks to its durability and maintenance-free design.
