LAPN 10X1 SKF is a connector designed for SKF automatic lubrication systems. It provides a connection between G 1/4 and the metric M10x1 thread, enabling an automatic lubricator or other lubrication system component to be connected to a lubrication point with an M10x1 thread. LAPN 10X1 belongs to the SKF range of accessories used with systems including LAGD, TLSD and TLMR.

Technical data - LAPN 10X1 SKF

Manufacturer: SKF

Full designation: LAPN 10X1

Product type: connector / nipple

Product category: lubrication system connection adapter

Connection 1: G 1/4

Connection 2: M10x1

Metric thread: M10x1

M10x1 thread pitch: 1 mm

Application: automatic lubrication systems

Compatible series: SKF LAGD, TLSD, TLMR

What does LAPN 10X1 mean?

The designation LAPN 10X1 identifies a specific connector from the SKF range of accessories for automatic lubrication systems.

LAPN - SKF family of connectors and adapters designed for connections between lubrication system components.

10X1 - indicates an M10x1 metric thread.

The connection configuration is:

G 1/4 - M10x1

The value 10 refers to the nominal metric thread diameter of 10 mm, while 1 indicates the thread pitch of 1 mm.

What is LAPN 10X1 SKF used for?

LAPN 10X1 enables a lubrication system component with a G 1/4 connection to be connected to a lubrication point or another component with an M10x1 thread.

The connector can be used when installing SKF automatic lubricators on machines where the existing lubrication point has an M10x1 metric thread.

This makes it possible to adapt the connection of the SKF lubrication system to the specific machine lubrication point without modifying the machine structure.

G 1/4 and M10x1 threads

The key feature of LAPN 10X1 is the connection between two different thread standards:

G 1/4

and

M10x1

G 1/4 is a pipe thread commonly used in lubrication system components.

M10x1 is a fine-pitch metric thread with a nominal diameter of 10 mm and a thread pitch of 1 mm.

LAPN 10X1 therefore acts as an adapter between a G 1/4 lubrication system connection and an M10x1 lubrication point.

LAPN 10X1 vs LAPN 10

LAPN 10X1 and LAPN 10 are separate SKF designations and should not be treated as identical products.

LAPN 10X1:

G 1/4 - M10x1

LAPN 10:

G 1/4 - M10

For LAPN 10X1, the fine thread pitch of 1 mm is explicitly specified.

The exact thread in the machine should therefore always be checked before ordering.

If an M10x1 connection is required, the correct designation is:

LAPN 10X1 SKF

SKF LAPN connector range

SKF offers the LAPN range to adapt automatic lubrication systems to different connection threads.

The range includes variants such as:

LAPN 1/8 - G 1/4 - G 1/8

LAPN 1/4 - G 1/4 - G 1/4

LAPN 1/2 - G 1/4 - G 1/2

LAPN 1/4 UNF - G 1/4 - 1/4"-28 UNF

LAPN 3/8 - G 1/4 - G 3/8

LAPN 6 - G 1/4 - M6

LAPN 8 - G 1/4 - M8

LAPN 8X1 - G 1/4 - M8x1

LAPN 10 - G 1/4 - M10

LAPN 10X1 - G 1/4 - M10x1

LAPN 12 - G 1/4 - M12

LAPN 12X1.5 - G 1/4 - M12x1.5

This range makes it possible to select an appropriate adapter according to the thread used at the specific lubrication point.

LAPN 10X1 in SKF lubrication systems

LAPN 10X1 belongs to the SKF range of accessories for automatic lubrication systems.

SKF specifies this type of accessory for systems including:

SKF LAGD

SKF TLSD

SKF TLMR

The connector enables an automatic lubricator or lubricant supply system to be adapted to a lubrication point equipped with an M10x1 thread.

Applications of LAPN 10X1

LAPN 10X1 can be used in automatic lubrication systems for various machine components.

Typical lubrication points may include:

bearings,

bearing housings,

guides,

joints,

chains,

machine components requiring regular lubricant supply.

Correct application requires compatibility between the connection threads and the requirements of the specific lubrication system.

Installation of LAPN 10X1 SKF

Before installation, carefully verify the thread type at the lubrication point.

Particular attention should be paid to the difference between M10 and M10x1.

The metric thread of LAPN 10X1 is:

M10x1

which means:

Nominal thread diameter: 10 mm

Thread pitch: 1 mm

An M10x1 connector should not be forced into a port with a different thread pitch.

The connection should be installed so that the lubrication system remains properly sealed.

Excessive tightening torque should also be avoided because it could damage the connector thread or the lubrication point.

LAPN 10X1 with other SKF accessories

Depending on the machine design, LAPN 10X1 can form part of a more extensive lubrication system incorporating other SKF accessories.

Examples include:

LAPA 45 - 45-degree angle connector

LAPA 90 - 90-degree angle connector

LAPE 35 - 35 mm extension

LAPE 50 - 50 mm extension

LAPM 2 - Y-connector

LAPT 1000 - 1000 mm flexible tube

LAPF - tube connections

LAPG 1/4 - G 1/4 grease fitting

Correct selection and combination of these components makes it possible to adapt an automatic lubrication installation to the available space and location of the lubrication point.

Alternative designations and search references

The product may be searched for using different designation formats:

LAPN 10X1 SKF

SKF LAPN 10X1

LAPN10X1 SKF

SKF LAPN10X1

LAPN 10x1

SKF LAPN 10x1 G 1/4 M10x1

G 1/4 M10x1 SKF

SKF M10x1 lubrication connector

SKF M10x1 adapter

SKF automatic lubricator M10x1 connector

For unambiguous technical identification, use the complete designation:

LAPN 10X1 SKF

Selection of LAPN 10X1 SKF

Before ordering, check:

• lubrication system designation

• thread of the automatic lubricator or system component

• lubrication point thread

• metric thread diameter

• thread pitch

• available installation space

• requirement for an additional angle connector or extension

The most important parameter on the machine side is the M10x1 thread.

LAPN 10X1 should not be selected solely on the basis of an M10 diameter without verifying the thread pitch.

FAQ - LAPN 10X1 SKF

What is LAPN 10X1 SKF?

LAPN 10X1 SKF is a connector for automatic lubrication systems that provides a G 1/4 to M10x1 connection.

What threads does LAPN 10X1 have?

The connector provides a connection between G 1/4 and the metric M10x1 thread.

What does 10X1 mean in LAPN 10X1?

10X1 refers to the M10x1 metric thread. Its nominal diameter is 10 mm and its thread pitch is 1 mm.

Are LAPN 10X1 and LAPN 10 the same product?

No. They are separate SKF designations. LAPN 10X1 is specifically designed for an M10x1 connection, so the exact thread pitch must be checked before selection.

Is LAPN 10X1 suitable for SKF SYSTEM 24?

LAPN 10X1 belongs to the SKF range of accessories for automatic lubrication systems and can be used in configurations involving SKF SYSTEM 24 equipment.

Which SKF series use LAPN 10X1?

SKF lists LAPN 10X1 among accessories used with lubrication systems including LAGD, TLSD and TLMR.

Is LAPN 10X1 an automatic lubricator?

No. LAPN 10X1 is a connector / adapter used to connect components within a lubrication system.

Can LAPN 10X1 be replaced with LAPN 10?

Not without checking the thread specification. LAPN 10X1 is intended for an M10x1 connection, so the exact thread and pitch at the lubrication point must be verified before substitution.

LAPN 10X1 SKF - key information

LAPN 10X1 SKF is a lubrication system connector providing a G 1/4 to M10x1 connection. It belongs to the SKF range of accessories used with automatic lubrication systems including LAGD, TLSD and TLMR. The X1 designation is important because it specifies an M10 thread with a 1 mm pitch.
