LAPA 45 SKF - 45 Degree Angle Connector for Automatic Lubricators

LAPA 45 SKF - 45 Degree Angle Connector for Automatic Lubricators

LAPA 45 SKF is a 45-degree angle connector designed for SKF automatic lubrication systems. It enables the lubricant connection direction to be changed and facilitates the installation of an automatic lubricator or lubrication line in areas with limited mounting space. LAPA 45 belongs to the SKF range of accessories for automatic single-point lubricators, including SKF SYSTEM 24 LAGD, TLSD and TLMR systems.

Technical data - LAPA 45 SKF

Manufacturer: SKF

Full designation: LAPA 45

Product type: angle connector

Angle: 45 degrees

Accessory type: automatic lubrication system component

Connections: G 1/4

Function: changing the direction of a lubrication connection

Compatibility: selected SKF SYSTEM 24 automatic lubricators

Compatible series: SKF LAGD, TLSD, TLMR

EAN: 7316571444109

What does LAPA 45 mean?

The designation LAPA 45 identifies a specific SKF angle connector designed for automatic lubrication systems.

LAPA - SKF designation for this family of connection accessories.

45 - indicates a connection angle of 45 degrees.

The complete product designation:

LAPA 45 SKF

should be used for technical identification and ordering.

What is LAPA 45 SKF used for?

LAPA 45 enables the direction of a connection in a lubricant supply system to be changed by 45 degrees.

The connector is particularly useful where direct installation of an automatic lubricator or lubrication line in line with the lubrication point is difficult because of:

• limited installation space

• machine components

• protective guards

• location of the lubrication point

• inconvenient orientation of the existing connection

The 45-degree angle connector enables the connection direction to be changed without requiring major modification of the lubrication arrangement.

LAPA 45 in SKF automatic lubrication systems

LAPA 45 belongs to the range of accessories designed for SKF automatic lubricators.

SKF specifies this component as an accessory for systems including:

SKF SYSTEM 24 LAGD

SKF TLSD

SKF TLMR

The connector can be incorporated into a lubrication system to provide a more suitable orientation of the automatic lubricator or other system components relative to the machine lubrication point.

G 1/4 connections

LAPA 45 is part of the SKF accessory system using G 1/4 connections.

Before installation, the thread of the lubrication point and the threads of the other components in the system should be checked.

If the lubrication point has a different thread, suitable SKF connectors or adapters can be used to connect G 1/4 components to other common thread sizes.

Examples of SKF connection accessories include:

LAPN 1/8 - G 1/4 to G 1/8 connector

LAPN 1/4 - G 1/4 to G 1/4 connector

LAPN 1/2 - G 1/4 to G 1/2 connector

LAPN 3/8 - G 1/4 to G 3/8 connector

LAPN 6 - G 1/4 to M6 connector

LAPN 8 - G 1/4 to M8 connector

LAPN 10 - G 1/4 to M10 connector

LAPN 12 - G 1/4 to M12 connector

The exact adapter should always be selected according to the thread used at the lubrication point.

LAPA 45 vs LAPA 90

SKF offers two characteristic angle connector versions:

LAPA 45 - 45-degree angle connector

LAPA 90 - 90-degree angle connector

LAPA 45 changes the direction of the connection by 45 degrees, while LAPA 90 provides a 90-degree connection.

Selection depends primarily on machine geometry, available installation space and the position of the lubrication point.

The number 45 therefore does not indicate a product dimension. It identifies the connector angle.

LAPA 45 vs LAPE 35 and LAPE 50

LAPA and LAPE are different types of SKF lubrication accessories.

LAPA 45 - 45-degree angle connector

LAPA 90 - 90-degree angle connector

LAPE 35 - 35 mm extension

LAPE 50 - 50 mm extension

LAPA components are primarily used to change the direction of a connection, while LAPE components increase the distance between the lubrication point and the next component in the lubrication system.

Depending on the machine design, these accessories can be used to create a suitable automatic lubrication installation.

SKF SYSTEM 24 accessories

LAPA 45 forms part of the wider range of SKF automatic lubrication accessories.

This range includes components such as:

LAPA 45 - 45-degree angle connector

LAPA 90 - 90-degree angle connector

LAPE 35 - 35 mm extension

LAPE 50 - 50 mm extension

LAPM 2 - Y-connector

LAPG 1/4 - grease fitting G 1/4

LAPT 1000 - 1000 mm flexible tube

LAPN - connector and thread adapter range

LAPF - tube connection range

Correct selection of these components makes it possible to adapt an automatic lubricator installation to the machine design and location of the lubrication point.

Applications of LAPA 45

LAPA 45 can be used where the lubricant supply connection needs to be redirected by 45 degrees.

It can form part of automatic lubrication arrangements for:

bearings,

bearing housings,

guides,

joints,

chains,

machine components requiring periodic lubricant supply.

The final system configuration should always correspond to the lubrication requirements of the machine component and the SKF lubrication system being used.

Installation of LAPA 45 SKF

Before installation, check that the connector threads are compatible with the other components in the lubrication system.

Threaded connections should be installed in a manner that provides a properly sealed lubrication system.

A suitable thread sealing solution should be used where required by the installation.

The connector should also be positioned so that the automatic lubricator, tubing and other system components are not exposed to unnecessary mechanical stress.

Alternative designations and search references

The product may be searched for using different designation formats:

LAPA 45 SKF

SKF LAPA 45

LAPA45 SKF

SKF LAPA45

SKF LAPA 45 angle connector

SKF LAPA 45 angle connection

SKF 45 degree lubrication connector

SKF SYSTEM 24 LAPA 45

For unambiguous technical identification, use the complete designation:

LAPA 45 SKF

Selection of LAPA 45 SKF

Before ordering, check:

• automatic lubricator designation

• lubrication system type

• connector thread

• lubrication point thread

• required connection angle

• available installation space

• lubrication tube routing

• other adapters used in the system

If a right-angle connection is required, LAPA 90 may be the appropriate component from the same accessory family.

If the lubricator only needs to be moved away from the lubrication point without changing the connection direction, an extension such as LAPE 35 or LAPE 50 may be more appropriate.

FAQ - LAPA 45 SKF

What is LAPA 45 SKF?

LAPA 45 SKF is a 45-degree angle connector designed for SKF automatic lubrication systems.

What does 45 mean in LAPA 45?

The number 45 indicates the connector angle of 45 degrees. It does not represent the length or diameter of the product.

What is LAPA 45 used for?

It changes the direction of a lubrication connection by 45 degrees and facilitates installation of an automatic lubricator or lubrication line where available space is limited.

Is LAPA 45 designed for SKF SYSTEM 24?

Yes. LAPA 45 belongs to the SKF range of accessories used with automatic lubrication systems, including SKF SYSTEM 24.

Which SKF lubricator series are compatible with LAPA 45?

SKF lists LAPA 45 as an accessory for systems including LAGD, TLSD and TLMR.

What is the difference between LAPA 45 and LAPA 90?

LAPA 45 provides a 45-degree connection, while LAPA 90 provides a 90-degree connection.

What is the difference between LAPA 45 and LAPE 50?

LAPA 45 is a 45-degree angle connector. LAPE 50 is a 50 mm extension. They perform different functions within a lubrication system.

Is LAPA 45 an automatic lubricator?

No. LAPA 45 is a connection accessory used together with a suitable automatic lubricator or other components of a lubrication system.

LAPA 45 SKF - key information

LAPA 45 SKF is a 45-degree angle connector designed for SKF automatic lubrication systems. It changes the direction of the lubricant connection and facilitates installation where available space is limited. It belongs to the SKF lubrication accessory range and is used with systems including LAGD, TLSD and TLMR.
